Related Manuals for Blaupunkt BRIGHTON MP35
Summary of Contents for Blaupunkt BRIGHTON MP35
- Page 1 Radio / CD / MP3 Brighton MP35 Essen MP35 Operating instructions 7 645 160 510 7 645 150 510 http://www.blaupunkt.com...
- Page 3 To activate, deactivate and ad- just the X-BASS function. Keys 1 - 6 BND•TS button Short press: Select the FM memory banks and the MW and LW wavebands (MW/LW only on the Brighton MP35). Long press: Start the Travelstore function.
-
Page 4: Table Of Contents
CONTENTS Notes and accessories ... 31 Switching on/off ... 32 Adjusting the volume ... 33 Setting the power-on volume ... 33 Quick volume reduction (mute) ... 33 Switching the confirmation beep on/off ... 34 Mute while telephoning ... 34 Radio mode ... 34 Adjusting the tuner settings ... -
Page 5: Notes And Accessories
You cannot switch the device on/off us- ing the remote control. Amplifiers You can use all Blaupunkt and Velocity amplifiers. CD changers You can connect the following Blaupunkt CD changers: CDC A 08, IDC A 09 and... -
Page 6: Switching On/Off
SWITCHING ON/OFF Switching on/off You can switch the device on/off in the following ways: Switching on/off using the vehicle ignition If the device is correctly connected to the vehicle’s ignition and it was not switched off using button 1, it will switch on/off simultaneously with the ignition. -
Page 7: Adjusting The Volume
Adjusting the volume You can adjust the volume in steps from 0 (off) to 66 (maximum). To increase the volume, turn the volume control 4 clock- wise. To decrease the volume, turn the volume control 4 anti- clockwise. Setting the power-on volume Note: The device is equipped with a time- out function. -
Page 8: Switching The Confirmation Beep On/Off
ADJUSTING THE VOLUME Switching the confirmation beep on/off The system will play a confirmation beep for some functions if you keep a button pressed down for longer than two sec- onds, for instance, when you assign a radio station to a station button. You can switch the beep on/off. -
Page 9: Switching To Radio Mode
Switching to radio mode If you are in CD/MP3, CD-changer or AUX mode, press the BND•TS button ; button 2 re- press the SRC peatedly until the memory bank (e.g. “FM1”) appears in the display. RDS functions The convenient RDS functions AF (Al- ternative Frequency) and REGIONAL extend your radio’s range of functions. -
Page 10: Setting The Sensitivity Of Station Seek Tuning
Select the memory bank that you want (FM1, FM2, FMT) or one of the wavebands (MW or LW) (MW/ LW only on the Brighton MP35). Tune into the station that you want. Press and hold down one of the station buttons 1 - 6 : for longer than two seconds to assign the sta- tion to that button. -
Page 11: Listening To Stored Stations
Note: Any stations previously stored in this memory bank are deleted in the process. Press and hold down the BND•TS button ; for longer than two sec- onds. The storing procedure begins. “FM TSTORE” appears in the display. After the process has completed, the radio will play the station that is stored in memory location 1 of the FMT memory bank. - Page 12 RADIO MODE PTY-EON If you specify the programme type and start seek tuning, the radio will switch from the current station to a station of the selected programme type. Note: If the tuner does not find a station that matches the selected pro- gramme type, you will hear a beep and “NO PTY”...
-
Page 13: Optimising Radio Reception
Optimising radio reception HICUT The HICUT function improves reception during poor radio reception (only FM). If interference occurs, the interference level is cut automatically. Switching HICUT on/off Press the MENU button 8. button 7 repeat- Press the edly until “HICUT” appears in the display. -
Page 14: Traffic Information
TRAFFIC INFORMATION Traffic information Your device is equipped with an RDS- EON receiver. EON stands for En- hanced Other Network. Whenever a traffic announcement (TA) is broadcast, the system switches au- tomatically from a station that does not provide traffic reports to the appropri- ate traffic information station within the broadcasting network that does. -
Page 15: Cd Mode
To ensure the system functions proper- ly, only use CDs labelled with the com- pact disc logo. Problems might be ex- perienced when playing copy-protect- ed CDs. Blaupunkt cannot guarantee the proper functioning of copy-protect- ed CDs! Besides being able to play audio CDs on this device, you can also play CDs containing MP3 music files. -
Page 16: Random Track Play (Mix)
CD MODE Random track play (MIX) Press the 5 MIX button :. “MIX CD” appears briefly in the display and the MIX symbol lights up. The next randomly selected track will then be played. Cancelling MIX Press the 5 MIX button : again. “MIX OFF”... -
Page 17: Displaying Cd Text
Displaying CD text Some CDs include CD text. The CD text might contain the names of the artist, album and track. You can allow the CD text to be dis- played as scrolling text every time you switch to another track. The default dis- play will appear again after the whole CD text has been shown once. -
Page 18: Mp3 Mode
MP3 MODE MP3 mode You can also use this car sound sys- tem to play CD-Rs and CD-RWs that contain MP3 music files. Preparing an MP3-CD The various combinations of CD burn- ers, CD burning software and CD blanks may lead to problems arising with the device’s ability to play certain CDs. -
Page 19: Switching To Mp3 Mode
“002”, etc.) at the beginning of each file name - you must include the leading zeros. MP3 tracks can contain additional in- formation such as the artist, album and track names (ID3 tags). This device can display ID3 tags (version 1). When creating (encoding) MP3 files from audio files, you should use bit rates up to a maximum of 256 kbits/sec. -
Page 20: Selecting A Directory
MP3 MODE Configuring the MP3 scrolling text One of the following scrolling texts is displayed once every time the track is changed. Afterwards, the configured default display is shown. The available scrolling texts are: Directory name (“DIR NAME”) Track name (“SONG NAME”) Album name (“ALBM NAME”) Artist name (“ARTIST”) File name (“FILE NAME”) -
Page 21: Scanning Tracks (Scan)
Cancelling MIX To cancel MIX, briefly press the 5 MIX button :. “MIX OFF” appears in the display and the MIX symbol disappears. Scanning tracks (SCAN) You can scan (briefly play) all the tracks on the CD. Press and hold down the MENU button 8 for longer than two sec- onds. -
Page 22: Cd-Changer Mode
CD-CHANGER MODE CD-changer mode Note: Information on handling CDs, in- serting CDs and operating the CD changer can be found in the oper- ating instructions supplied with your CD changer. Switching to CD-changer mode button 2 re- Press the SRC peatedly until “CHANGER”... -
Page 23: Random Track Play (Mix)
Cancelling REPEAT To stop the current track or current CD from being repeated, briefly press the 4 RPT button :. “RPT OFF” appears and RPT disap- pears from the display. Random track play (MIX) To play the tracks on the current CD in random order, briefly press the 5 MIX button :. -
Page 24: Clock Time
CLOCK TIME CLOCK time Displaying the clock time To display the clock time briefly, press and hold down the SRC button 2 until the clock time ap- pears in the display. Setting the clock time To set the clock time, press the MENU button 8. -
Page 25: Sound
Sound You can adjust the sound settings (bass and treble) separately for each source (radio, CD/MP3 and CD changer / AUX). The volume distribution settings (bal- ance and fader) apply to all the audio sources (except for traffic announce- ments). You can only adjust the balance and fader settings for traffic announcements whilst a traffic announcement is actu-... -
Page 26: X-Bass
SOUND Equalizer presets This device is equipped with an equal- izer that has been preset with settings for the “ROCK”, “POP” and “CLASSIC” music styles. To select an equalizer preset, press the AUDIO button 9. “BASS” appears in the display. button 7 repeatedly Press the until “POP”, “ROCK”, “CLASSIC”... -
Page 27: Configuring The Level Display
You can obtain this cable (Blau- punkt no.: 7 607 897 093) from your authorised Blaupunkt dealer. Note: If no CD changer is connected, the AUX input must be activated in the menu. -
Page 28: Specifications
SPECIFICATIONS Specifications Amplifier Output power: 4 x 25 watts sine in accordance with DIN 45 324 at 14.4 V 4 x 45 watts max. power Tuner Wavebands in Europe: FM : 87.5 - 108 MHz MW : 531 - 1 602 kHz LW : 153 - 279 kHz FM frequency response:... - Page 29 Bitte den ausgefüllten Gerätepass sicher aufbewahren! Please keep the filled-in radio pass in a safe place! Prière de conserver soigneusement la carte d’autoradio remplie ! Tenete per favore il libretto di apparecchio, debitamente riempito, in un posto sicuro! Bewaar de ingevulde apparaatpas op een veilige plaats! Vänligen förvara ifyllt apparatpass på...
- Page 30 (Mercosur) (BR) +55-19 3745 2769 Malaysia (Asia Pacific) (MAL) +604-6382 474 Gerätepass Name: Typ: Serien-Nr: Blaupunkt GmbH, Robert-Bosch-Straße 200, D-31139 Hildesheim 12/04 - CM/ASA Fax: 05121-49 4002 01-610 39 391 02-525 5263 44-898 644 09-435 99236 01-4010 7320 01-89583 8394...
- Page 31 Absatz „Programm-Typ (PTY)”. (GB) Note regarding PTY-EON reception If your Blaupunkt system switches from your chosen radio programme to another radio programme or from your chosen audio source (CD or CD changer) to a radio programme, please check whether you have activated the PTY (programme type) function.
- Page 32 "Radio". (ES) Observaciones sobre la recepción PTY-EON Si su equipo Blaupunkt cambia de la emisora de radio que está escuchando a otra, o de la fuente de sonido seleccionada (CD o cambiadiscos) a una emisora de radio, verifique si tiene activada la función PTY (tipo de programa).
- Page 33 (DK) Oplysning om PTY-EON-modtagelse Hvis din Blaupunkt radio slår fra det aktuelle radioprogram over i et andet eller fra en valgt kilde (CD eller Multi CD) over i et radioprogram, bør du tjekke om du har tændt for PTY (programtype).
- Page 34 (HU) Utasítás a PTY-EON vételhez...
- Page 35 (GR) À fi‰ÂÈÍË ÁÈ· ÙË Ï‹„Ë PTY-EON ŸÙ·Ó Ë Û˘Û΢‹ Û·˜ Blaupunkt ·ÏÏ¿˙ÂÈ · fi ¤Ó· Ú·‰ÈÔʈÓÈÎfi ÚfiÁÚ·ÌÌ· Ô˘ ·ÎÔ‡Ù Û ¤Ó· ¿ÏÏÔ Ú·‰ÈÔʈÓÈÎfi ÚfiÁÚ·ÌÌ· ‹ · fi ÌÈ·  ÈÏÂÁ̤ÓË ËÁ‹ (CD ‹ ÙÚÔÊÔ‰fiÙ˘ CD) Û ¤Ó· Ú·‰ÈÔʈÓÈÎfi ÚfiÁÚ·ÌÌ·, ÙfiÙ ÂϤÁÍÙ ·Ú·Î·ÏÒ, ¿Ó...
- Page 36 (RU) Указание по приему PTY-EON " " " "...
