1.7 Unpacking and Initial Checks

Your Refrigerant Monitor was carefully inspected at the factory before shipment, and packed so as to be highly
resistant to damage while in transport. When you receive the instrument, however, please unpack it promptly
and make a visual inspection to make sure that no damage has occurred during shipment. Also check that all
the following items have been received.
Item
External Filter Assembly (gas sample)
Soft Carrying Case with Shoulder Strap
Battery Pack and Charger Kit
Probe Assembly
Stainless Steel Tube
Instruction Manual
Elbow
Tubing
Coalescing Filter
Filter Assembly (zero air sample)
If damage was found, immediately file a claim with the carrier. If an item is missing, please contact the Service
Department for assistance (refer to Service Centers on page 28).

1.8 Functional Overview

The Bacharach Refrigerant Monitor is designed to detect, measure, and display the concentration of refrigerant
gas in the area being monitored. To ensure accurate gas measurements, the monitor self-zeros every 4 minutes
using an external supply of fresh air provided by activated carbon filtering.
During normal operation the Refrigerant Monitor displays both the current gas level and the peak gas level
detected on its front panel LCD. The monitor retains a log of previous readings that can be easily accessed at a
later time for analysis.
Front panel indicators and an audible alarm are provided to signal gas alarm and instrument fault conditions.
The audible alarm can temporarily be silenced by a push of a button, but will reactivate if the gas level is still
above the alarm trip point after a user-defined time period has elapsed.
The Refrigerant Monitor requires only minor periodic maintenance such as the occasional replacement of filters.
The monitor incorporates active diagnostics that continuously check the system for proper operation. A front
panel indicator is provided to alert an operator of system malfunctions, and fault codes are generated that
enable the operator to quickly identify the cause of the fault.
