Scope

These instructions describe how to replace the IR bench in the AGMSZ Ammonia Gas Monitor Single Zone
shown in Figure 1.
It is assumed that the user is familiar with the operation of the AGMSZ. If necessary, refer to Instruction
3015-4286 for detailed operation and maintenance information.

Items Required:

Replacement IR Optical Bench Kit 3015-4492:
IR Bench Assembly 3015-4282
o
Cable Ties (Qty. 2) 3015-2835
o
Instruction Sheet 3015-4719
o
Medium Phillips Head Screwdriver
Small Flat Blade Screwdriver
Wire Cutter (for removing cable ties)
Replacement Kit 3015-4492
Figure 1. AGMSZ
Ammonia Gas Monitor Single Zone
AGMSZ IR Bench
Instruction 3015-4719
Rev. 0 – February 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3015-4492 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bacharach 3015-4492

  • Page 1 It is assumed that the user is familiar with the operation of the AGMSZ. If necessary, refer to Instruction 3015-4286 for detailed operation and maintenance information. Items Required: Replacement IR Optical Bench Kit 3015-4492: • IR Bench Assembly 3015-4282 Cable Ties (Qty. 2) 3015-2835...
  • Page 2 Removing the IR Bench 1. Find the AGMSZ and switch OFF its AC circuit breaker. Observe that the monitor’s front panel green MONITOR ON indicator should be OFF. 2. Use a Phillips screwdriver to remove the monitor’s two door screws, and then open the door. 3.
  • Page 3 6. Check to ensure that the new IR bench is properly secured, and that all tubing and electrical connectors are tight. 7. Turn ON the AGMSZ’s AC circuit breaker. 8. Allow the monitor to warm-up for at least ½ hour before proceeding. Adjusting the IR Bench Voltage 9.
  • Page 4 Headquarters: 621 Hunt Valley Circle, New Kensington, PA 15068 Ph: 724-334-5000 • Fax: 724-334-5001 • Toll Free: 1-800-736-4666 Website: www.bacharach-inc.com • E-mail: help@bacharach-inc.com Printed in U.S.A. ® Registered Trademark of Bacharach Inc.
