WL635USB Wireless B/G
1 INTRODUCTION TO WL635USB WIRELESS B/G USB 2.0 ADAPTOR ................................3
.....................................................................................................................................3
2 INSTALLATION .................................................................................................................................5
...........................................................................................................................9
3 NETWORK CONNECTION ............................................................................................................10
98SE/ME..............................................................................................................10
2000/XP ...............................................................................................................11
4 IP ADDRESS ....................................................................................................................................12
5 CONFIGURATION UTILITY...........................................................................................................13
....................................................................................................................................14
6 EXAMPLE OF CONNECTION TO AN ACCESS POINT...........................................................21
Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage.
U
s
e
r
M
U
s
e
r
M
USB 2.0 Adaptor
User Manual
Version 1.1
CONTENTS
....................................................................................................................3
..........................................................................................................................4
..............................................................................................................5
......................................................................................5
.......................................................................................................7
...................................................................................................................9
.............................................................................................................19
......................................................................................................................20
P
a
g
e
P
a
g
e
a
n
u
a
l
a
n
u
a
l
1
o
f
2
2
1
o
f
2
2
Advertisement
Table of Contents
Related Manuals for Aztech WL635USB
Summary of Contents for Aztech WL635USB
-
Page 1: Table Of Contents
WL635USB Wireless B/G USB 2.0 Adaptor User Manual Version 1.1 CONTENTS 1 INTRODUCTION TO WL635USB WIRELESS B/G USB 2.0 ADAPTOR ........3 1.1 P ........................3 ACKAGE ONTENTS 1.2 F .............................3 EATURES 1.3 LED I ..........................4 NDICATORS 2 INSTALLATION ..........................5 2.1 S ......................5... -
Page 2: Declaration Of Conformity
Declaration of Conformity FCC Certification The United States Federal Communication Commission (FCC) and the Canadian Department of Communications have established certain rules governing the use of electronic equipment. Part15, Class B This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interface, and 2) This device must accept any interface received, including interface that may cause... -
Page 3: Introduction To Wl635Usb Wireless B/G Usb 2.0 Adaptor
USB 2.0, the adaptor connects to wireless network at incredible speeds and delivers blazing fast data rates up to 125 Mbps*. An example of 125Mbps* Wireless LAN set up will be Aztech WL635USB (TI chipset) + DSL600EW (TI chipset). -
Page 4: Led Indicators
1.3 LED Indicators Power Indicator (Green LED): The LED will light up when the device is connected to a network (an AP or Peer-to-Peer). The LED will blink when the device is scanning for all available networks. Act Indicator (Green LED): The LED will flicker when there is transmitting/receiving of wireless data. -
Page 5: Installation
2 Installation 2.1 System Requirements • Desktop PC or Notebook PC • Pentium® 233 processor or higher • 128MB RAM • 20MB hard disk space (system files and modem driver only) • A free USB Port • CD-ROM drive • Windows®... - Page 6 The below screen will be shown. Click “Next” to continue. 4. The below screen will be shown. Click “Next” to continue and the installation program will start running automatically. 5. For Windows 2000 Windows XP, you may be prompted for Digital Signature not found.
-
Page 7: Step 2: Install The Device
2.3 Step 2: Install the Device Note: Before you install the device to your computer, make sure you have installed the driver and utility as described in the previous section. 1. Locate your USB host and insert the USB 2.0 Adaptor. - Page 8 For Windows XP 4. Windows may ask to connect to Windows Update to search for software. Select “No”. When below is prompted, click “Next” to continue the installation. 5. W hen the “Hardware Installation” screen appears, click “Continue Anyway” to continue the installation.
-
Page 9: Verify Installation
Hardware Device Manager. Expand the Network Adaptors category. If the WL635USB Wireless B/G USB Adapter is listed here, it means that your device is properly installed and enabled. .5 Uninstallation . To uninstall the driver and utility, go to the Control Panel of your system. -
Page 10: Network Connection
3 Network Connection Once the device driver is well installed, a network setting described in the following should be also established. 3.1 In Windows 98SE/ME 1. Go to Start Settings Control Panel Network. Make sure that all the required components are installed. If any components are missing, click on the “Add”... -
Page 11: I Nwindows 2000/Xp
Start Control Panel Network and Internet Connections Network Connection Wireless Network Connection Enabled WL635USB Wireless B/G USB Adapter. 2. Make sure that all the required components are installed. If any components are missing, click on the “Install…” button to add them in. -
Page 12: Ip Address
4 IP Address 1. To configure a dynamic IP address check the “Obtain an IP Address Automatically” option. 2. To configure a fixed IP, check the “Use the following IP address” option. Then enter an IP address into the empty field. For example, enter 192.168.1.1 in the IP address field and 255.255.255.0 for the Subnet Mask. -
Page 13: Configuration Utility
Start Program WL635USB Wireless B+G WL635USB Wireless B+G Utility. There is also a Configuration Utility icon created on the desktop. You can also open the Configuration Utility by clicking the icon. fter you have activated the Configuration Utility icon on the desktop, there will be also a Configuration Utility icon appeared in the taskbar (as in the red circle). -
Page 14: Main Tab
5.1 Main Tab Open up the Configuration Utility and the below screen will display the current status of the WL635USB Wireless B/G USB 2.0 Adaptor. Item Description Configure External Configuration Checkbox (Windows XP only): A checkbox that using Windows enables you to disable the WLAN Station Configuration Utility Zero Config. - Page 15 Item Description Tx Rate /Rx The actual instantaneous transmit and receive rates, in Mbps. Rate Signal quality The signal strength from the network Access Point or station. The strength is displayed in three formats: a signal quality level (one of five levels, from Bad to Best), a numerical value in dBm, and a signal quality bar graph with a scale of –82 to –10.
- Page 16 Item Description Select Hexadecimal (Hex) if you are using hexadecimal numbers (0-9, or A-F). Select ASCII if you are using ASCII characters (case-sensitive). ASCII characters are: 0,1,2,...8,9 and a,b,c,d,...x,y,z. 10 Hexadecimal digits or 5 ASCII characters are needed if 64-bit WEP used;...
- Page 17 Item Description To supply a Personal Certificate: In the User Name field, type in the user name assigned to the certificate. Select a certificate by clicking Browse. The standard Windows Select Certificate window is displayed: Select a certificate from the list, and click OK. The name of the certificate is displayed in the textbox in the middle of the Personal Certificate window.
- Page 18 Item Description You are supplying a user name and password now. The utility prompts you for them each time you try to connect to a network. 2. To provide a user name and password now, enter them in the fields provided.
-
Page 19: Profile Manager Tab
5.2 Profile Manager Tab Profile Manager enables you to create, modify and delete the profiles that the station uses to connect to WLAN networks, to activate and de-activate profiles, and to raise and lower a profile’s priority. ll profiles are displayed in one of the following lists: Profiles Pool: A list of inactive profiles, that is, profiles that cannot currently be used for making a connection. -
Page 20: Information Tab
5.3 Information Tab Information tab displays information maintained by the driver, such as the number of packet errors and the total number of bytes received or transmitted. The tab also displays information about the current connection, as well as network information about the station. The statistics are for the period starting when you last connected to a network. -
Page 21: Example Of Connection To An Access Point
6 Example of connection to an Access Point 1. At the Main tab, highlight one of the devices from the list area that you wish to connect and then press the Connect button to access it. 2. The Profile Configuration window will be displayed so that you can create a profile. - Page 22 7. The WEP Configuration screen will be shown. Select Hexadecimal (Hex) if you are using hexadecimal numbers (0-9, or A-F). 10 Hexadecimal digits are needed if 64-bit WEP is used; 26 Hexadecimal digits are needed if 128-bit WEP is used; 58 Hexadecimal digits are needed if 256-bit WEP...
