THE XM24 EXPANSION MODULE

The XM24 Expansion Module is an optional device that can be connected to a 6416 or 6424-type telephone to
extend the number of call appearance and feature buttons available on the telephone.
The expansion module has 24 buttons arranged in two columns. Each of these buttons has a red and green light
next to it. These buttons can be used for call appearances or features.
Figure 1 shows a top view of the expansion module.
XM24
FIGURE 1 The XM24 Expansion Module
