AudioBahn AMPP210H Owner's Manual

AudioBahn AMPP210H Owner's Manual

Murdered out series
Hide thumbs
Table of Contents

Advertisement

Quick Links

By
AMPP210H / AMPP212H
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMPP210H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AudioBahn AMPP210H

Summary of Contents for AudioBahn AMPP210H

  • Page 1 AMPP210H / AMPP212H OWNER’S MANUAL...
  • Page 2 Judge for yourself, and remember what it’s all about, “If it’s not Bigger, Bad- der & Better, it’s not Audiobahn.” If audio is your life, Audiobahn is the brand for you! We make you look as good as you sound. People never stop trying to get the best...

  • Page 3: Table Of Contents

    Other infor- mation can be located by using the table of contents. We at Audiobahn have worked very hard to make sure that all of the information in this manual is current, but, as we are constantly finding new ways to improve our product, this information is subject to change without notice.

  • Page 4: Introduction

    Installer Training Programs. Please read your warranty, keep your receipt, and original carton for possible future use. To get a free brochure on Audiobahn products in the US call (714) 452-1476 or e-mail us at sales@audiobahn.com, if you would like an electronic version please visit us at audiobahn.

  • Page 5: Contents Of Carton

    Operations Manual 1. Make sure to carefully read and understand the instructions before attempting to install your new Audiobahn tube. 2. Before making any electrical connection, make sure that you disconnect the battery’s ground cable to prevent the possibility of short circuit or damage to your electronic equipment.

  • Page 6: Mounting & Hi-Level Inputs

    Mounting & HI LEVEL INPUTS The mounting position of your Party Pack will have a great effect on the sound perfor- mance produced. TRUNK MOUNTING Mounting the enclosure in the trunk provides a good overall performance. PASSENGER COMPARTMENT MOUNTING Mounting the enclosure in the passenger compartment provides optimum sound, but re- duces the area for passenger seating.

  • Page 7: Controls And Functions

    Controls And Functions...
  • Page 8 Controls And Functions 1. Speaker Terminals SPEAKER These chrome plated connectors can accept from 16 to 8 gauge wire. Be careful to observe proper polarity when connecting the cables 2. B - Terminal (Chassis ground) POWER BAT T To avoid unwanted ignition noise caused by ground loops, it is essential that the amplifier be grounded to a clean, bare, metal surface of the vehicles chassis.
  • Page 9 Controls And Functions 5. Input Sensitivity Adjustment This control adjusts the amplifier's sensitivity to match the signal strength coming from the source unit. Input sensitivity is variable from 200 Millivolts to 8 volts. Clockwise increases sensitivity. Counterclockwise decreases sensitivity. THE KNOB IS NOT A VOLUME CONTROL. A lower signal level will require increased sensitivity for full power.

  • Page 10: Controls And Functions

    Controls & Functions 9. Phase Shift control 10. Remote Bass Knob Port REMOTE Bass Boost Control (MIN / MAX) : Optional REMOTE BASS BOOST KNOB Mounting and Installation 1. Using the screws provided with the kit, find a location under the dash, center console, or a place that gives easy access to the remote bass boost knob. 2.

  • Page 11: Specifications

    Specifications Model Number AMPP210H AMPP212H Power RMS 600 Watts 800 Watts Achievable Power 1200 Watts 1600 Watts Frequency Response: 28Hz-1kHz 26Hz-1kHz Enclosure Dual 10” Dual 12” Enclosure Dimensions: Height: 15.25” 15.5” Width: 28.25” 31.62” Length: 15.5” 15.5” Common Features A/B Amplifier • HI -Level Inputs • Tiffany Style RCA Jacks • RCA Throughput Connections •...

  • Page 12: Troubleshooting

    Troubleshooting SYMPTOMS CHECK POINTS CURE NO SOUND Is the power Check fuses in amplifier. LED illuminated ? Be sure Turn-on lead is connected ( NO ) Check signal leads. Check gain control. Check Tuner/Deck volume level. Clean contacts on fuse holders. Is the Diagnostic Check for speaker short or LED illuminated ? ( YES )

  • Page 13: Warning And Disclaimer

    If you need to replace the power fuse, replace it only with a fuse identical to that supplied with the system. Using a fuse of a different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change without notice. For the most updated Specifications call Audiobahn, your local Authorized Audiobahn Dealer, or check the Audiobahn web site. www.audiobahn.com...

  • Page 14: Warranty

    Because of this we recommend that you have your new products installed by an Au- thorized Audiobahn Dealer. (A list of Authorized Audiobahn Dealers can be found on our web page). Warranty Period: One year from the original date of purchase.
  • Page 15 This might include having an Authorized Audiobahn Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn. Any product found to have no manufacturer defect will be returned to the sender at their cost.
  • Page 16 7050 Village Drive, Bldg G Buena Park, CA 90621 714-452-1476 o ce 888-880-8469 fax info@audiobahn.com PROUD SPONSOR OF Follow us on Facebook and Twitter...

This manual is also suitable for:

Ampp212h
