- Page 1 QUALITY, RELIABILITY, & PURE BLISS INTAKE SERIES CLASS D AMPLIFIER A6005DN / A8005DN / A12005DN OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTRE USE AND REFERENCE...
- Page 2 With four levels of play, one is right for you to get started in the Audiobahn family. Our Technical Department and entire staff look to strive above and beyond the rest of the pack by going that extra mile to help you out.
-
Page 3: Table Of Contents
Table of Contents Table of Contents Introduction Features and Specifications Control and Functions High Level Input Wiring Planning / Mounting Your System Wiring Diagrams Adjustments and Tunning Trouble Shooting Warrning / Disclaimer Warranty 5-11 18-19... -
Page 4: Introduction
Installer Training Programs. Please read your warranty, keep your receipt, and original carton for possible future use. To get a free brochure on Audiobahn products in the US call (714) 988-0400 or e-mail us at sales@audiobahn.com. Continuous exposure to sound pressure levels over 100dB may cause permanent hearing loss. -
Page 5: Features And Specifications
200 watts x 1 @ 4 Ohms RMS power 400 watts x 1 @ 2 Ohms RMS power A12005DN : 1200 watts ACH Power 375 watts x 1 @ 4 Ohms RMS power 600 watts x 1 @ 2 Ohms RMS power 11 1/16"... - Page 6 Controls and Functions A6005DN A8005DN A12005DN �� Patent: DES 423,503...
-
Page 7: Controls And Functions
Note: IF YOUR RADIO DOES NOT HAVE +12 VOLT OUTPUT LEAD WHEN THE RADIO IS TURNED ON, THE "REMOTE" TERMINAL ON THE AMPLIFIER CAN BE CONNECTED TO THE VEHICLE'S ACCESSORY CIRCUIT THAT IS LIVE WHEN THE KEY (IGNITION) IS "ON". POWER RE M BAT T POWER BAT T A6005DN A8005DN A12005DN A6005DN A8005DN A12005DN A6005DN A8005DN A12005DN... - Page 8 Counterclockwise decreases sensitivity. THE KNOB IS NOT A VOLUME CONTROL. A lower signal level will require increased sensitivity for full power. A higher signal will require decreased sensitivity. POWER BAT T A6005DN A8005DN A12005DN A6005DN A8005DN A12005DN A6005DN A8005DN...
- Page 9 A6005DN A8005DN A12005DN SONIC A6005DN A8005DN A12005DN A6005DN A8005DN A12005DN...
- Page 10 11. DVM (Digital Volt Meter Input) Fig 1 Remote Control for Digital Display Voltmeter: Optional ADM100T 12. DVM (Digital Volt Meter Input) Fig 1 DVM REMOTE DVM REMOTE A6005DN A8005DN A12005DN A6005DN A8005DN A12005DN A6005DN A8005DN A12005DN...
- Page 11 If the amplifier shut down because of an input overload or short circuit, be sure to repair these conditions before attempting to power up the amplifier again. BASS BOOST +18dB Bass Boost Variable: 0dB - 18dB POWER A6005DN A8005DN A12005DN A6005DN A8005DN A12005DN...
-
Page 12: Control And Functions
Controls and Functions Control and Functions Fig 1. LINE CORD Optional Remote Digital Volt Meter : ADM-100T Fig 2. LINE CORD Optional Remote Bass Boost Control : ABR-100T DES. 423,503... -
Page 13: High Level Input Wiring
High Level Input Wiring If the HIGH LEVEL INPUTS are used, do not use the low level RCA inputs at the same time A6005DN A8005DN A12005DN ��� DES. 423,503 ���� ����� ����� ��� � ��� � � � � ��� ���... -
Page 14: Planning / Mounting Your System
Planning and Mounting Your System Planning Your System Before beginning the installation, consider the following: a. If you plan to expand your system by adding other components sometime in the future, ensure that adequate space is left, and cooling requirements are met. If your radio/source is equipped with Pre-Amp outputs, it is possible to utilize them to drive an Amplifier and connecting (amplifier) to the 2 rear speakers. -
Page 15: Wiring Diagrams
Wiring Diagrams A6005DN A8005DN A12005DN MONO MODE SUBWOOFER 2~8OHM CAPACITOR HIGH PASS FILTER INDUCTOR LOW PASS FILTER... -
Page 16: Adjusting And Tuning
Adjusting and Tuning TURNING ON THE AMPLIFIER The amplifier automatically turns on a few seconds after you turn your vehicle's ignition switch to ACC or turn on your auto sound system (depending on how you have wired the system). The POWER indicator on the top of the amplifier illuminates when the amplifier is on. -
Page 18: Warrning / Disclaimer
Using a fuse of a different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change with out notice. For the most updated Specifications call Audiobahn, your local Authorized Audiobahn Dealer, or check the Audiobahn web site. www.audiobahn.com... -
Page 19: Warranty
Audiobahn products are manufactured with the highest quality components and some of the most advanced technology available. Because of this, we recommend that you have your new products installed by an Authorized Audiobahn Dealer. (A list of Authorized Audiobahn Dealers can be found on our web page). - Page 20 Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn. Any product found to have no manufacturer defect will be returned to the sender at their cost.
