- Page 1 PCMCIA Fax Modem ENW-5601 Installation Guide...
- Page 2 INTRODUCTION The ENW-5601, 56k PCMCIA Fax Modem is a credit-card-size Type II PC card that complies with the PCMCIA 2.1 standards. The ENW-5601 is Bell, ITU-T (formerly CCITT) compliant and Hayes AT command compatible, so that it can be used worldwide with today’s popular communication software programs.
- Page 3 System Requirements § A notebook or desktop computer with PCMCIA type II or III slot. § A telephone line with RJ-11 jack. § A CD-ROM drive. § Windows 95, 98 or Windows NT pre-installed.
-
Page 4: Hardware Installation
HARDWARE INSTALLATION 1. Locate the PCMCIA slot of your system. 2. Align the ENW-5601 PC Card toward the PCMCIA slot. Push evenly and steadily until it is seated. Notebook Connects to RJ-11 phone jack 3. Connect the other end of the PC Card cable to the telephone line outlet. -
Page 5: Software Installation
SOFTWARE INSTALLATION Installation for Windows 95 1. As soon as the PCMCIA Fax Modem 56K PC is inserted into the PCMCIA slot, Windows automatically detects the new hardware device and prompts the following message. 2. Insert the device driver compact disc into your CD-ROM drive. When the following dialog box appears, click the Other Locations button. - Page 6 3. Type the CD-ROM drive letter followed by driver\win95. Or you may click the Browse button to select the driver\win95 folder in your CD-ROM drive. Click OK. 4. When the following figure appears, click Finish. The Installation program will continue.
- Page 7 5. When the following figure appears, click OK to continue. 6. Repeat Step 3 as described above. 7. Follow the on-screen instruction to continue.
- Page 8 8. When finished, press Finish to complete the installation. Remember to restart Windows 95 to activate the new device.
- Page 9 Installation for Windows 98 1. As soon as the PCMCIA Fax Modem 56K PC is inserted into the PCMCIA slot, Windows automatically detects the new hardware device and the following message will be prompted. 2. Insert the device driver compact disc into your CD-ROM drive. When the following dialog box appears, click Next.
- Page 10 Next. Or you may click the Browse button to select the driver\win98 folder in your CD-ROM drive. 4. When the following figure appears, click Finish. The Installation program will continue.
- Page 11 5. Follow the on-screen instruction to proceed.
- Page 13 6. The installation program will proceed automatically. Click Finish to complete the installation.
- Page 14 Installation for Windows NT 1. Before you start Windows NT, make sure the PCMCIA Fax Modem 56K PC Card has been properly inserted into the free PCMCIA slot of your computer. 2. Load the device driver compact disk in the CD-ROM drive. 3.
- Page 15 Part No: EMQ-5601...
