- Page 1 10/100 Fast Ethernet & 56K V.90 Fax/Modem Integrated PC Card Quick Installation Guide...
- Page 2 1. INSTALLATION The quick installation guide describes how to install your Intergared PC Card in major popular Network Operating System. And more can be found in detail manual diskette. 1.1. HARDWARE INSTALLATION Hold the card label up and insert the card into the computer's PCMCIA slot with the 68 pin connector facing the computer.
- Page 3 1.2. INSTALLING THE SOFTWARE 1.2.1 Windows 95 Installation 1.Assume that the PCMCIA card reader and drivers have been loaded and well functioning. The System Icon in the Control Panel can report on its functionality. If not, check your computer dealer for technical support. 2.Insert 10/100 Fast Ethernet + 56K Fax/Modem multifunction PC Card into PCMCIA slot.
- Page 4 3.Enter the correct path, i.e. “A:\”, then insert 10/100 Fast Ethernet + 56K Fax/Modem PC Card driver disk. The driver will be installed automatically, and system may ask for the Windows 95 installation CD/disks to update the existing files or drivers. After the update, system will reboot automatically. 4.For the first time installation, click Network icon in Control Panel to correctly add Protocols, Client and Service according to your application requirements.
- Page 5 5. Insert Fast Ethernet/Fax/Modem combo PC Card driver disk, select “Floppy disk drives”, then click Next.
- Page 6 Press Finish to complete the installation. Reboot the machine and now the Fast Ethernet/fax/modem combo PC card is ready to go. 1.2.3 NT4.0 Installation Installation in NT 4.0 1. Insert the PC Card into one of the PCMCIA Slots. 2. Start Windows NT 4.0 and login with a full access level ADMINISTRATOR 3.
- Page 7 Insert the driver disk into drive floppy disk drive, then enter the correct path. Select the only one choice for the Direct PortPC Card, then press OK and NEXT Windows NT 4.0 will grant configurations for -- TCP/IP -- NWLink IPX/SPX -- NetBEUI These configurations are unique for each network.
- Page 8 4. Press FINISH and then CLOSE to complete modem setting, and Reboot the system. 5. The installations for both LAN and Modem are completed. Note: If you have EMI (electromagnetic interference) issues. Attached the Ferrite Cores on this two cables as shows: Part No.: EMQ-3503F ISO9002...
