- Page 1 USB ADSL Modem ADU-2120 User’s Manual...
-
Page 2: Fcc Compliance Statement
PLANET Technology. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environ- ments and applications, and makes no warranty and representation, either implied or ex- pressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose. - Page 3 Revision User’s Manual for PLANET USB ADSL Modem Model: ADU-2120A / ADU-2120B Rev: 1.0 (JAN. 2004) Part No.: EM-ADU2120...
-
Page 4: Table Of Contents
CHAPTER 1 INTRODUCTION ... 1 ... 1 EATURES ... 1 EQUIREMENT ADSLRFC1483 mode user... 1 ADSL PPPoE/PPPoA mode user ... 1 YSTEM EQUIREMENT ... 2 DEFINITION CHAPTER 2 INSTALLATION... 3 ARDWARE NSTALLATION RIVER NSTALLATION WITH RIVER NSTALLATION WITH RIVER NSTALLATION WITH RIVER NSTALLATION WITH RIVER... -
Page 5: Chapter 1 Introduction
Chapter 1 Introduction PLANET USB ADSL modem ADU-2120 is designed to provide cost-effective ac- cess to high-speed ADSL services. With our ADSL modem, surfing on Internet is just like driving a sport car on the Express Highway. Video on Demand, Videocon- ference and any high-speed Internet applications is not a dream any more. -
Page 6: System Requirement
System Requirement Mainboard with USB support Pentium II CPU and above or compatible RAM: 64M or above Windows 98SE, Windows 2000, Windows ME, Windows XP, Windows 2003 Server NOTE: For Windows XP it is recommended that your PC have at least 128 M Bytes of memory. LED definition Below is the front panel of ADU-2120 and its LEDs definition. -
Page 7: Chapter 2 Installation
Chapter 2 Installation Please refer to the following steps to complete ADU-2120 installation. Hardware Installation 1. Turn on your PC 2. Insert the rectangular end of a USB cable into the USB port of your PC. Then, insert the square end of the USB cable into the USB port of the ADU 2120. 3. - Page 8 3. Choose “Specify a location”. Then click “Browse” to find out the driver location to install. (Assume "E" is your CD-ROM drive, the driver can be found in E:\driver\ADU-2120B) then click OK. Please then click “Next” to continue.
-
Page 9: Driver Installation With Windows Me
4. The Add New Hardware Wizard will appear and indicate the PLANET ADU-2120 USB ADSL modem has been recognized and will install a new driver. Click Next 5. Please then go to Section “Driver Configuration” for further configuration. Driver Installation with Windows ME 1. -
Page 10: Driver Installation With Windows 2000
2. Please specify the path which ADSL modem connected your computer to Internet, then click OK. Please select the directory with ADU-2120 driver and then click “OK”. 3. Please then go to Section “Driver Configuration” for further configuration. Driver Installation with Windows 2000 1. - Page 11 2. Choose the “Search for a suitable driver for my device (recommended)”, and click Next. 3. Next you will be prompted for software drivers. Select Specify a location.
- Page 12 4. Insert the ADSL Driver CD into your systems CD-ROM drive and then click “Browse” to find out the driver location to install. (Assume "E" is your CD-ROM drive, the driver can be found in E:\driver\ADU-2120B) then click OK. 5. The Found New Hardware Wizard will then find the ADSL USB MODEM, click Next.
-
Page 13: Driver Installation With Windows Xp
6. The “Digital Signature Not Found” window will pop-up, Click Yes. 7. Please then go to Section “Driver Configuration” for further configuration. Driver Installation with Windows XP 1. The “Add New Hardware Wizard” will be displayed. Choose Install from a list or specific location (Advanced) and click Next. - Page 14 2. Insert the ADSL Driver CD into your systems CD-ROM drive, select “Include this location in the search” and then click “Browse” to find out the driver loca- tion to install. (Assume "E" is your CD-ROM drive, the driver can be found in E:\driver\ADU-2120B).
-
Page 15: Driver Configuration
3. The Hardware Installation window appears. Click Continue Anyway. 4. Now please go to Step 3 for driver configuration. Driver Configuration Step 3: Driver Configuration 1. The system will start to copy the driver and utility files to your PC. After com- pleting, the ADSL Modem Driver Suite installation page is shown. - Page 16 3. On this page, you need to select the operation mode (RFC 1483, PPPoA or PPPoE) and input the VPI / VCI values per your ISP’s requirement. Click “Next” to continue.
- Page 17 4. Please then select the framing type your ISP uses: LLC or VCMUX/NULL. 5. If you select RFC 1483, you will then need to specified if it is Bridged or Routed RFC 1483. Your ISP should also provide this information.
- Page 18 6. The system will then ask you to reboot your PC. Please select “Yes, I want to restart my computer now” and click OK to finish this setup procedure. 7. After reboot, the system will ask you to install the driver again. Please select “Install the software automatically“...
-
Page 19: Chapter 3 Pppoe And Pppoa Configuration
8. The Hardware Installation page is shown. Please select “Continue Anyway” or Windows XP and “OK” on Windows 2000 3. The Found New Hardware Wizard window appears and displays your newly in- stalled PLANET ADU-2120 USB ADSL Interface, then click Finish. The system may ask you to reboot again. -
Page 20: Adsl Lan Configuration
ADSL LAN Configuration To configure the connection, after you have installed the appropriate driver: Step 1. Click either the desktop icon, or the Dial-Up Networking icon to open the Connect To window. For Windows XP, please click “Start” -> “Settings” -> “Net- work Connections”... -
Page 21: Chapter 4. User Interface
Chapter 4. User Interface ACCESSING CSA The User Interface to the ADSL Modem is provided by the Control and Status Application (CSA). You can access the CSA by double-clicking on the CSA icon in the System Tray, located near the clock on the task bar. The icon, which ap- pears as two monitor screens, also changes color to indicate the status of the mo- dem (see Table 1. -
Page 22: Connection Status
Modem Performance The Modem Performance displays performance information. The primary purpose is to display the instantaneous throughput rate for both transmit and receive paths of the modem. This rate is calculated based on the poll period (generally 2 seconds) and the number of bytes passed during that time. Transmit and Receive The throughput is indicated through two bar graphs, each provides a maximum rate label indicating the transmit and receive bit rates currently in use. -
Page 23: Device Status
tion: • ADSL link connected • ADSL link disconnected Device Status The Device Status field changes to indicate the status of the modem connection: • ADSL Modem available • ADSL Modem not available Connect/ Disconnect Button The CONNECT/DISCONNECT button performs the connection/disconnection op- eration. -
Page 24: Chapter 5. Uninstall Modem
Chapter 5. Uninstall Modem USB Modem uninstallation USB MODEM To uninstall the software and hardware for the USB ASDL Modem, perform the following: Step 1. Detach the USB Modem from your computer. Step 2. At Windows Start, click on Programs > ADSL Modem Driver > Remove ADSL Modem Driver. -
Page 25: Chapter 6. Troubleshooting
Chapter 6. Troubleshooting If your internet connection is not working, the following hints may be helpful. After trying these hints, if you still can not make your connection work, it is recom- mended that you ask your service provider for assistance. To run troubleshooting on the system: Step 1. -
Page 26: Chapter 7. Abbreviations
Chapter 7. Abbreviations ATM Adaptation Layer. A function performed during ATM cell processing to adapt traditional IP or Ethernet traffic for transmission through an ATM network. ADSL Asymmetric Digital Subscriber Line. A method for modulating data to achieve high bit rates over common twisted-pair copper wire. Asynchronous Transfer Mode.
