- Page 1 USER M A N UA L MODEL 533 ArcNet (BNC) Surge Protectors SALES OFFICE Part# 07M533-B (301) 975-1000 Doc# 074121UB TECHNICAL SUPPORT Revised 1/13/94 (301) 975-1007 http://www.patton.com...
- Page 2 LAN I/O ports. By shunting all threatening voltages to the chassis ground, the Model 533 insures the integrity of the data in your LAN and protects connected equipment from damage. Using an all solid state design and sophisticated multistage hybrid circuits, these units can handle up to 1.8 KiloWatts of electricity.
- Page 3 Connection to frame ground Response Time: Less than 5 nanoseconds Input Capacitance: 18 pF Clamp Voltage: 35 volts at 100A (8/20 µ Waveform) Model 533 ArcNet Surge Protector Coaxial input Coaxial input from Surge Current: 400A (8/20 µ Waveform) from network...
