- Page 1 USER MANUAL MODEL 464RC & 466RC Rack-Mounted G.703 Coax to Twisted Pair Adapters (BALUNs) SALES OFFICE Part # 07M464RC-A (301) 975-1000 Doc. # 019151U TECHNICAL SUPPORT Revised 12/06/00 (301) 975-1007 http://www.patton.com An ISO-9001 Certified Company...
- Page 2 This number may be obtained from Patton Electronics Technical Support at (301) 975-1007; http://www.patton.com: or, The Patton 464RC & 466RC G.703 balun panel matches 16 sets of support@patton.com. dual 75 ohm coax connections to 120 ohm twisted pair connections.
- Page 3 RJ-45 ports on the front of the unit. Figure 3. Model 464RC/466RC rear panel. Remove screws from sides of unit. 3.3.1 Connecting the RJ-45 Ports The number on each RJ-45 port corresponds to the BNC pair numbers on the front of the unit.
- Page 4 The 120 Ohm balanced pairs can be accessed via the 64 pin AMP Champ connector. The pins on this connector are wired directly to the PATTON ELECTRONICS MODEL 464RC & 466RC RJ-45 ports. The AMP Champ pinout is shown below.
- Page 5 APPENDIX B APPENDIX C PATTON ELECTRONICS MODEL 464RC & 466RC PATTON ELECTRONICS MODEL 464RC & 466RC FACTORY REPLACEMENT PART BLOCK DIAGRAM Model # Description 07M464RC & 466RC Model 464RC & 466RC User Manual © Copyright 2000 Patton Electronics Company All Rights Reserved...
