- Page 1 ArcNet Balun / Filter SALES OFFICE Part# 07M405-A (301) 975-1000 Doc# 019121UA Revised 5/2/95 TECHNICAL SUPPORT (301) 975-1007 http://www.patton.com...
- Page 2 330 feet are supported between the local Model 405 4 -----------------TIP and the remote Model 405 (one unit is required at each end of the twist- 5 -----------------RING ed pair cable). The Model 405 is compatible with ArcNet controller 6 -----------------Ground cards and active ArcNet repeaters.
- Page 3 405 SPECIFICATIONS Connectors: Male BNC for RG59 or RG62 coax connections; RJ-45 jack for twisted pair connection Environment: ArcNet baseband token-passing LAN Devices: IBM PC/XT/AT and compatible systes euipped with ArcNet LAN controller cards and Active ArcNet multiport hubs and...
