Patton electronics 3004 ECB Series User Manual

Ecb series miniature self-powered elastic clock buffers

Advertisement

Quick Links

USER
MANUAL
MODEL 3004
ECB Series
Miniature Self-Powered
Elastic Clock Buffers
Part# 07M3004ECB-A
Doc# 011031UA
Revised 08/22/00
An ISO-9001
Certified
Company
SALES OFFICE
(301)975-1000
TECHNICAL SUPPORT
(301)975-1007
http://www.patton.com

Advertisement

loading

Summary of Contents for Patton electronics 3004 ECB Series

  • Page 1 USER MANUAL MODEL 3004 ECB Series Miniature Self-Powered Elastic Clock Buffers SALES OFFICE Part# 07M3004ECB-A Doc# 011031UA (301)975-1000 Revised 08/22/00 TECHNICAL SUPPORT (301)975-1007 An ISO-9001 http://www.patton.com Certified Company...
  • Page 2: Table Of Contents

    1.0 WARRANTY INFORMATION TABLE OF CONTENTS Patton Electronics warrants all Model 3004-ECB components to be SECTION PAGE free from defects, and will—at our option—repair or replace the product 1.0 Warranty Information .............2 should it fail within one year from the first date of shipment. This 1.1 Radio and TV Interference warranty is limited to defects in workmanship or materials, and does not 1.2 CE Notice...
  • Page 3: General Information

    1.3 SERVICE 2.0 GENERAL INFORMATION All warranty and nonwarranty repairs must be returned freight Thank you for your purchase of this Patton Electronics product. This prepaid and insured to Patton Electronics. All returns must have a product has been thoroughly inspected and tested and is warranted for One Return Materials Authorization number on the outside of the shipping Year parts and labor.
  • Page 4: Operation

    3.0 OPERATION 4.0 INSTALLATION Installation is easy and straightforward. Simply connect each port of the 3004- The receive clock of DCE 2 clocks data into buffer A. The transmit clock of ECB to one of the DCEs. There are no jumpers or switches to configure. DCE 1 clocks data out of buffer A.
  • Page 5: Appendix A - Specifications

    APPENDIX A APPENDIX A MODEL 3004-ECB SERIES MODEL 3004-ECB SERIES TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS (continued) Connection: DCE to DCE Powering: Derived from data, clock and control signals. No external power required. Wiring: Internal "cross-over" wiring Environment: 0-60°C, 32-140°F, humidity up to 95%, non- Transmission format: Synchronous, transparent to protocol condensing Data rate:...
  • Page 6 APPENDIX B APPENDIX C PATTON ELECTRONICS MODEL 3004 ECB/V.35 PATTON ELECTRONICS MODEL 3004 ECB/530 INTERFACE PIN ASSIGNMENT INTERFACE PIN ASSIGNMENT V.35 Interface RS-530 Interface Pin Description (DB-25 Connector) Pin # Signal Pin # Signal FG (Frame Ground) A......FG (Frame Ground) TD (Transmit Data-A) B......SGND (Signal Ground) RD (Receive Data-A)
  • Page 7 APPENDIX D APPENDIX E PATTON ELECTRONICS MODEL 3004-ECB/V.36 PATTON ELECTRONICS MODEL 3004-ECB/X.21 INTERFACE PIN ASSIGNMENT INTERFACE PIN ASSIGNMENT RS-449 Interface Pin Description X.21 Interface Pin Description (DB-37 Connector) (DB-15 Connector) Pin # Signal Pin # Signal FG (Frame Ground) FG (Frame Ground) TD (Transmit Data-A) TD (Transmit Data-A) TC (Transmit Timing-A)
