Connections

HDMI connection

This unit has terminal boards equivalent to Dual HDMI Terminal Board (TY-FB10HMD) and BNC Component Video Terminal
Board (TY-42TM6A) as standard equipment.
[Pin assignments and signal names]
Pin No. Signal Pin No.
T.M.D.S Data2+
1
T.M.D.S Data2
2
Shield
T.M.D.S Data2-
3
T.M.D.S Data1+
4
T.M.D.S Data1
5
Shield
T.M.D.S Data1-
6
T.M.D.S Data0+
7
T.M.D.S Data0
8
Shield
T.M.D.S Data0-
9
T.M.D.S Clock+
10
19
18
Note:
Additional equipment and HDMI cables shown are not supplied
with this set.

COMPONENT / RGB connection

Example of input signal source
DVD
Digital TV-SET-TOP-BOX
(DTV-STB)
Notes:
• Change the "COMPONENT/RGB-IN SELECT" setting in the "SET UP" menu to "COMPONENT"
(when COMPONENT signal connection) or "RGB" (when RGB signal connection). (see page 40)
• Additional equipment, cables and adapter plugs shown are not supplied with this set.
• SYNC ON G signal is needed. (see page 43)
12
Signal
T.M.D.S Clock
11
Shield
T.M.D.S Clock-
12
CEC
13
Reserved
14
(N.C. on device)
SCL
15
SDA
16
DDC/CEC
17
Ground
+5V Power
18
Hot Plug Detect
19
3 1
4 2
COMPONEN T VIDEO OUT
P
R
P
B
Y , P , P ,
B R
OUT
Y
L
AUDIO
R
OUT
SLOT1 SLOT2
HDMI
AV OUT
DVD player
Computer
RGB Camcorder
or
R AUDIO L
P /C /R P /C /B Y/G
R R B B
COMPONENT/RGB IN
SLOT3
HDMI cables
HDMI
AV OUT
DVD player
RCA-BNC
adapter plug
R AUDIO L
P /C /R P /C /B Y/G
R R B B
COMPONENT/RGB IN
SLOT3
PC
