VocoPro PV-1800 Owner's Manual

World’s first active 15” vocal speaker with built in digital echo mixer

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

THE SINGER'S ULTIMATE CHOICE

World's First Active 15" Vocal Speaker

o w n e r ʼ s m a n u a l

PV-1800

With Built in Digital Echo Mixer

Table of Contents

Summary of Contents for VocoPro PV-1800

Page 1 THE SINGER'S ULTIMATE CHOICE PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800 PV-1800...
Page 2: Table Of Contents
Table of Contents FCC Information ........... Listening for a Lifetime ........Safety Instructions ..........Welcome ..............Features and Speciﬁ cations ......Features Speciﬁcations Before Getting Started Setting Up ..............Setting up the Speaker Stand Mounting the Speakers Voltage Selector Switching the Voltage Getting Connected 9 - 10 ........
Page 3: Fcc Information
FCC 1. To ensure the finest performance, please read this requirements. Modifications not expressly approved by Vocopro may void your authority, granted by the FCC, to manual carefully. Keep it in a safe place for future reference. use this product.
Page 4: Listening For A Lifetime
Listening For A Lifetime �� ...
Page 5: Safety Instructions
Safety Instructions 8. Ventilation - The appliance should be situated so its CAUTION location does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the RISK OF SHOCK ventilation slots.
Page 6: Welcome
And while you’re there don’t forget to check out our Club VocoPro for Karaoke news and events, chat rooms, club directories and even a Service directory! We look forward to hearing you sound like a PRO, with VocoPro, your ultimate choice in Karaoke entertainment. FOR YOUR RECORDS Please record the model number and serial number below, for easy reference, in case of loss or theft.
Page 7: Features And Speciﬁ Cations
Shipping weight........55 lbs. The PV-1800 200W Powered Speaker system is self-powered and does not rely on an external ampliﬁer for power. This means you can connect any mixer, player or other audio device directly to its stereo RCA Line In inputs for instant sound.
Page 8: Setting Up
CAUTION: Using the speakers while set to the wrong voltage can result in permanent damage and will void the CAUTION: Using the speakers while set to the wrong voltage can result in permanent damage and will void the CAUTION: warranty. Make sure you have set the PV-1800 to the correct voltage before using.
Page 9: Getting Connected
1. Connect one end of each RCA cable to the L/R (red & White) RCA outputs on your player or mixer 2. Connect the other ends of the RCA cables to the L/R (red & white) LINE IN RCA inputs on the PV-1800’s rear panel ��...
Page 10: Connecting To The Xlr Line In Channel
• XLR audio cable 1. Connect one end of the XLR cable to the XLR output on a mixer 2. Connect the other end of the XLR cable to the LINE IN XLR jack on PV-1800’s rear panel �� ...
Page 11: Connecting To A Second Speaker
Connecting to a Second Speaker eaker The PV-1800 can be connected to a second powered speaker using its XLR or ¼” LINE OUT channels. Connecting to the XLR LINE OUT Channel What you will need: • An powered speaker with an XLR audio input •...
Page 12: Connecting A Microphone
Connecting a Microphone The PV-1800 has one microphone channel with two available inputs, a ¼” and an XLR input. You can have a microphone connected to each at the same time. Use the MIC LEVEL control to adjust the microphone volume.
Page 13: Descriptions And Functions
13. Clip LED - Indicates if any clipping is occurring 14. Power LED - Indicates when the power is on 15. POWER switch - Turns the PV-1800 on and off 16. AC Input - Connect the included power cable here 17.
Page 14: Operations
Operations Operations Operat Adjusting the Microphone Volume Adjusting the Microphone Volume Adjusting the Microphone V Use the MIC LEVEL control to adjust the microphone volume 1. Turn the MIC LEVEL control clockwise towards MAX to raise the level 2. Turn the MIC LEVEL control counter-clockwise towards MIN to lower the level Adjusting the Line In Level Use the LINE IN LEVEL control to adjust the level for the player or mixer that is connected to the RCA or XLR LINE IN channel.
Page 15: Troubleshooting
The power is not turning on • Make sure the power cable is connected fimly to the PV-1800 and the power outlet • If you are using a surge protector / power strip, make sure it is plugged in and turned on •...
Page 16: Index
Index Symbols ¼” LINE OUT 13 ¼” MIC input 13 Descriptions and Functions 13 Power LED 13 Power rating 7 AC Input 13 POWER switch 13 Adjusting the Bass Tone 14 ECHO control 14 Adjusting the Echo Level 14 Adjusting the Line In Level 14 RCA LINE IN 13 Adjusting the Master Volume 14 Adjusting the Microphone Volume 14...
Page 17 Featured VocoPro Pr Featured VocoPro Pr Featured VocoPro P oducts Here are some of the other great VocoPro products featured in this manual. You can ﬁnd more information at our website: www.vocopro.com. DVG-777K Multi-Format USB/DVD/CD+G Karoake Player KJ-7808RV Professional KJ/DJ/VJ Mixer with...
Page 18 Notes Notes...
Page 19 Notes...
Page 20 THE SINGER'S ULTIMATE CHOICE �� ...
