CIS-169
April 1995
CURRENT INFORMATION SUMMARY
Wind off
1
• Check the frame counter window.
• X's must be visible.
• If not, grip camera, press shutter button, and
turn thumbwheel untill film is fully rewound.
Open Film Door
2
• Insert special tool into end slot (as shown).
CAUTION: This camera body
contains a high voltage capacitor
and circuit board. To avoid electric
shock, do not pry apart the front and
back sections of camera. Remove
only film and battery from their
respective compartments. If sections
of the camera are separated, do not
touch the circuit board.
Opening Instructions for the
KODAK MAX Flash One-Time-Use Camera
Wear eye protection when opening all cameras.
Shutter Button
Thumbwheel
Remove Film
3
• Use tool to bend cover back and remove film.
Remove Battery
4
Opened Camera with film and battery removed.
Battery
• Repeat the same steps at opposite end of
camera to remove battery.
• Place in recycle bin.
5
• Return to Kodak for recycling.
CAUTION: To avoid injury, use tool
carefully.
Exposed Film
©Eastman Kodak Company, 1996
