Mantel Installation - Dimplex ELECTRALOG DF203A Owner's Manual

Fireplace Installation
Construction and electrical outlet
wiring must comply with local
building codes and other applica-
ble regulations to reduce the risk
of fire, electric shock and injury
to persons.Do not attempt to wire
your own new outlets or circuits.
to reduce the risk of fire, electric
shock or injury to persons, always
use a licensed electrician
make sure the units mAIn on/
oFF switch is switched oFF
(refer to operating instruction sec-
tion).
Figure 7
10
Plug the unit into a 15 Amp/120
VAC outlet. If the cord does not
reach, you may use a no. 14
AWG minimum size extension
cord rated for a minimum of 1875
Watts.

Mantel Installation

For use with a new or existing
mantel, insert fireplace as shown
in Figure 7 and anchor in place
with supplied screws.
x6
