Vivotek FD8362 Specification

Technical Specifications
System
Multimedia SoC
．CPU:
．Flash: 16MB
．RAM: 256MB
．Embedded OS: Linux 2.6
Lens
．Board lens, vari-focal, f = 3 ~ 9 mm, F1.2 (wide), F2.1 (tele), auto-iris,
remote focus
．Removable IR-cut filter for day & night function
Angle of View
．31.7° ~ 93.0° (horizontal)
．23.8° ~ 68.4° (vertical)
．39.6°~118.9° (diagonal)
Shutter Time
．1/5 sec. to 1/32,000 sec
Image Sensor
．1/2.7" progressive scan CMOS sensor in 1920x1080 resolution
Minimum Illumination
．0.08 Lux @ F1.2 (Color)
．0.001 Lux @ F1.2 (B/W)
Video
．Compression: H.264, MJPEG & MPEG-4
．Streaming:
Multiple simultaneous streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
H.264/MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
．Supports activity adaptive streaming for dynamic frame rate control
．Supports video cropping for bandwidth saving
．Supports ePTZ for data efficiency
．Supports 3GPP mobile surveillance
．Frame rates:
H.264:
Up to 30 fps at 1920x1080
MPEG-4:
Up to 30 fps at 1920x1080
MJPEG:
Up to 30 fps at 1920x1080
．Interface:
Audio/Video output
NTSC/PAL video output switch
Image Settings
．Adjustable image size, quality and bit rate
．Time stamp and text caption overlay
．Flip & mirror
．Configurable brightness, contrast, saturation, sharpness,
white balance and exposure
．AGC, AWB, AES
．WDR enhanced
．Automatic, manual or scheduled day/night mode
．BLC (Backlight Compensation)
．Supports privacy masks
Audio
．Compression:
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
G.711 audio encoding, bit rate: 64 kbps, μ-Law or A-Law
mode selectable
．Interface:
External microphone input
Audio output
．Supports two-way audio
．Supports audio mute
Networking
．10/100 Mbps Ethernet, RJ-45
．Onvif support
．Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP,
SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, and
802.1X
All speci cations are subject to change without notice. Copyright © 2012 VIVOTEK INC. All rights reserved. P/N:971004500
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
|T: +886-2-82455282| F: +886-2-82455532| E: sales@vivotek.com
Alarm and Event Management
．Triple-window video motion detection
．Tamper detection
．One D/I and one D/O for external sensor and alarm
．Event notification using HTTP, SMTP or FTP
．Local recording of MP4 file
On-board Storage
．MicroSD/SDHC card slot
．Stores snapshots and video clips
Security
．Muilti-level user access with password protection
．IP address filtering
．HTTPS encrypted data transmission
．802.1X port-based authentication for network protection
Users
．Live viewing for up to 10 clients
Dimension
．Ø 173 mm x 115 mm
Weight
．Net: 1296 g
LED Indicator
．System power and status indicator
Power
．12V DC
．24V AC
．Power consumption:
．FD8362
DC 12V:
Max. 8.9W (with 400mA DO on)
AC 24V:
Max. 12.2W (with 400mA DO on)
PoE:
Max. 8.2W (with 200mA DO on)
．FD8362E
DC 12V:
Max. 13.7W (with heater and 400mA DO on)
AC 24V:
Max. 21.4W (with heater and 400mA DO on)
PoE:
Max. 11.52W (with heater on, without DO on)
．802.3af compliant Power-over-Ethernet (Class 3)
Housing
．Vandal-proof IK10-rated metal housing
．Weather-proof IP66-rated housing
Approvals
．CE, LVD, FCC, VCCI, C-Tick
Operating Environments
．Temperature:
FD8362: 0°C ~ 50°C (32°F ~ 122°F)
FD8362E: -40°C ~ 55°C (-40°F ~ 131°F)
．Humidity: 90% RH
Viewing System Requirements
．OS: Microsoft Windows 7/Vista/XP/2000
．Browser: Mozilla Firefox, Internet Explorer 6.x or above
．Cell phone: 3GPP player
．Real Player: 10.5 or above
．Quick Time: 6.5 or above
Installation, Management, and Maintenance
．Camera angle adjustment: pan 350°, tilt 80°, rotate 350°
．Installation Wizard 2
．32-CH ST7501 recording software
．Supports firmware upgrade
Applications
．SDK available for application development and system integration
Warranty
．36 months
Ø173 mm
VIVOTEK USA, INC.
2050 Ringwood Avenue, San Jose, CA 95131
Ver 1.1
|T: 408-773-8686| F: 408-773-8298| E: salesusa@vivotek.com
Fixed Dome Network Camera
FD8362/62E
2MP‧Full HD‧Smart Focus System‧Vandal-proof
VIVOTEK FD8362/62E are professional fixed dome network cameras offering 2-Megapixel or 1080p Full HD resolution with superb
image quality up to 30 fps. The cameras can capture a much more comprehensive area than a standard VGA model, significantly
reducing the number of units required. It is especially suitable for monitoring wide open outdoor such as building entrances, airports or
applications requiring accurate identification.
For installers, properly adjusting the focus of a megapixel network camera can be difficult due to the image detail. Thus VIVOTEK
introduces the Smart Focus System including Focus Assist Button and Remote Focus to make installation and adjustment easier.
VIVOTEK adopts lenses with built-in stepping motors that the installer can use to remotely control the focal length and precisely adjust
the camera focus, offering hassle-free installation and maintenance.
The IP66-rated housing is designed to help the camera body withstand rain and dust and ensures operation under a multitude of harsh
weather conditions. Its metal vandal-proof housing effectively provides robust protection from vandalism. Additionally, the wide
temperature range further enhances the FD8362E's performance and reliability in extremely cold and warm weather.
With other advanced features such as tamper detection, 802.3af compliant PoE, MicroSD/SDHC card for on-board storage, video
cropping, and e-PTZ functionality, the FD8362/62E provide the most robust solution suitable for any demanding outdoor environments.
Smart Focus System
1080P
WDR
Full HD
Remote Focus
Enhanced
