Vivotek IP8172 Specification

Fixed
Network Camera
IP8172/72P
5MP • Full HD • Focus Assist
VIVOTEK IP8172/72P are professional box cameras offering
5-Megapixel or 1080p Full HD resolution with superb image quality
u p t o 3 0 f p s . F e a t u r i n g 5 - M e g a p i x e l r e s o l u t i o n a n d
high-performance H.264/MPEG-4/MJPEG compression technology,
the IP8172/72P offer extra-smooth video and wide coverage.
The IP8172P comes with a P-iris lens, which controls the iris with
extreme precision with its built-in stepper motor, it maintains the iris
opening at an optimal level at all times, resulting in superior image
clarity and depth of field.
In addition, the IP8172/72P are equipped with a focus assist button
to allow users to precisely adjust the camera focus. After pushing
the focus assist button on the camera unit, an indicator will be
displayed onscreen with detailed focus information, which will
change in accordance with the manual adjustment. Moreover,
continuing to push the button will zoom in on the target area for fine
tuning, resulting in better usability and picture clarity.
The IP8172/72P can be also connected directly to an analog
monitor with a BNC connector, providing integrators with more
flexibility and hassle-free installation for a variety of applications.
Other high-end features such as WDR enhancement, multiple
streams, video cropping, ePTZ, SD/SDHC/SDXC card slot, PoE,
and the included 32-CH recording software make the IP8172/72P is
indisputably the top choice for reliable and high performance
megapixel surveillance.
Features
● 5-Megapixel CMOS Sensor
● 30 fps @ 1080p Full HD
● 2.8 ~ 12 mm Vari-focal, DC-iris Lens (IP8172)
● 3.5 ~ 10 mm Vari-focal, P-iris Lens (IP8172P)
● Removable IR-cut Filter for Day & Night Function
● Real-time H.264, MPEG-4, and MJPEG Compression
(Triple Codec)
● WDR Enhancement for Improved Clarity in
High Contrast Environments
● Built-in Focus Assist Button for
Precise Focus Adjustment
● Built-in 802.3af Compliant PoE
● Built-in SD/SDHC/SDXC Card Slot for
On-board Storage
Train Station
Hotel Lobby
Metro Station
Shopping Mall
