Viking SA--25 Technical Practice

Viking SA--25 Technical Practice

Self amplified paging control unit with ir remote
Hide thumbs

Advertisement

Quick Links

Download this manual
TECHNICAL
TECHNICAL
T
T
E
E
L
L
E
E
Add Up to 25 Remote Controllable Self-Amplified
The SA-25 can directly drive up to 25 self amplified
speakers. Speakers can be Viking's 2 wire self ampli-
fied ceiling speaker model SA-1S, the SA-1H self
amplified paging horn, the older 4 wire legacy Valcom
and Bogen self amplified speakers, or any combina-
tion of the above. Viking self amplified speakers have
these advantages: 1) Audio and power are on the
same pair (less copper). 2) Power is 40VDC for lower
current and smaller gauge wire (less copper). 3) Non-
Polarity sensitive for easier wiring. 4) Each speaker is
infrared remote controllable so there is no need to
manage and wire "background music zones", install
volume controls on the walls, or climb up ladders to
adjust the volume. The provided SA-IR Infrared Remote controls volume, mute, and enable/disable back-
ground music at each speaker as required.
The SA-25 provides paging, loud ringing, and background music when connected to electronic or 1A2 Key
systems, PABX's, No-KSU phones, multi-line phones, as well as IP phone systems (that have an analog
FXS or FXO port). The SA-25 paging control unit can interface with a paging port or a ringing analog FXS,
CO/Centrex line, PABX/KSU station port or an FXO, unused telephone line input (trunk port).
The SA-25 will generate loud ringing from a ringing analog line or from a dry contact closure. Either a loud electronic war-
ble sound or one of three other soft chime sounds may be selected. An external "night transfer" switch (such as Viking
model NS-1) can be added to turn loud ringing on or off in night bell applications. If a music source is connected to the SA-
25, background music can be enabled or disabled at any Viking self amplified speaker using the provided SA-IR infrared
remote control. Background music is inhibited during paging. The SA-25 is easy to install and comes complete with a power
supply. The Viking model SA-X12 Expander / Adapter can be used if additional self amplified speakers are required.
F
e
a
t
u
r
e
s
F
e
a
t
u
r
e
s
• Includes (1) SA-IR Infrared Remote Control
• Easy to install
• Drive up to 25 self amplified speakers
• Separate volume controls for Auxiliary Input, Paging,
Ringing Tones and Background Music
• Choose from up to 4 loud ringing sounds:
- Electronic warble (traditional loud ringer)
- Double gong (two identical "gong" tones)
- Quadruple chime (four descending chime tones)
- Door chime (ding-dong)
• Provides loud ringing or night bell
• Night transfer switch input
• Page from a ringing C.O. line, Centrex line, paging port,
unused phone system trunk input (FXO), or ringing
analog station port (FXS)
• Can provide background music from an external source
• 600 Ohm output to cascade to additional units
• Use multiple units to drive more self amplified speakers
• Expandable 12 speakers at a time with the Viking model
SA-X12 Expander / Adapter (DOD# 529)
S
S
C
C
O
O
M
M
O
O
L
L
U
U
T
T
I
I
O
O
N
N
S
S
Paging Speakers to Any Phone System
2
1
C
2
1
C
F
F
O
O
R
R
T
T
H
H
E
E
S
S
T
T
A
p
p
l
i
A
p
p
l
i
• Amplified loud paging
• Loud ringing
• Night bell
• Background music
• Sound masking
• For unused phone system trunk input (FXO), ringing
analog station port (FXS), C.O. line, Centrex line, or
paging port
S
p
e
c
S
p
e
c
Power: 120V AC/15V AC 2.2A UL listed adapter provided
Dimensions: 210mm x 159mm x 45mm (8.25" x 6.25" x 1.75")
Shipping Weight: 1.5kg (3.2 lbs.)
Environmental: 0°C to 32°C (32°F to 90°F) with 5% to 95% non-
condensing humidity
Paging Output: Viking 40V two wire, and Valcom/Bogen 24V
four wire protocols.
Speakers: Up to 25 self amplified speakers
Talk Battery Output: 40V DC (loop current 30mA nominal)
Maximum Wire Run Length: See chart on page 3
Connections: (1) 3.5mm (1/8") audio jack, (1) 2.1mm barrel jack
(20) cage clamp screw terminals
SA-25
SA-25
Self Amplified Paging
Control Unit with
IR Remote
E
E
N
N
T
T
U
U
R
R
Y
Y
January 3, 2013
c
a
t
i
o
n
s
c
a
t
i
o
n
s
i
f
i
c
a
t
i
o
n
s
i
f
i
c
a
t
i
o
n
s

Advertisement

loading

Related Manuals for Viking SA--25

Summary of Contents for Viking SA--25

  • Page 1 The SA-25 will generate loud ringing from a ringing analog line or from a dry contact closure. Either a loud electronic war- ble sound or one of three other soft chime sounds may be selected. An external “night transfer” switch (such as Viking model NS-1) can be added to turn loud ringing on or off in night bell applications.
  • Page 2 3. Auxiliary Audio 4. Page Audio 5. Ring Trip 6. Contact Closure 7. Ringing Background Music In: Output to Viking 40V 2-wire Connect to a music source self-amplified speakers to provide background music. 600 Ohm audio for Night Transfer Input: To cascading additional units enable/disable loud ringing.
  • Page 3 Control PAGING SPEAKERS Step 3. Wire each run to pins 1 and 2. FOUR WIRE WIRE CONTACT 600 OHM CLOSURE Step 4. Adjust the volume of each speaker with the Viking AUDIO PAGE PAGE RINGING NIGHT CONTACT LINE TRANSFER SA-IR Infrared Remote Control.
  • Page 4 For example, the chart says to use #16 gauge wire for 8 speakers on a 1000 foot run; but instead use #14 gauge wire when using Valcom and Bogen legacy speakers. The SA-25 can power up to 25 Bogen or Valcom speakers (equal to 25 “Valcom Power Units”), if no Viking SA series two wire speakers are used. VIKING...
  • Page 5 19 and 20 to enable and disable loud ringing. Optional Night Transfer Switch Ringing Line or Disables loud ringing when closed PABX Station (not included). See Viking model NS-1 (DOD# 540). 2. Dry Contact (Common Audible) Closure (contacts not included) VIKING MODEL SA-25 ©...
  • Page 6 When more than (25) self-amplified paging speakers are required, a second SA-25 for (25) more speakers, or the Viking model SA-X12 Expander can be used to add (12) self-amplified paging speakers. For more information on the SA-X12, see DOD# 529.

  • Page 7: Dip Switch Programming

    G. DIP Switch Programming VIKING MODEL SA-25 © VIKING ELECTRONICS HUDSON, WI 54016 SELF AMPLIFIED PAGING CONTROL UNIT POWER 15 VAC MASTER VOLUME OUTPUT TO SELF AMPLIFIED PAGING SPEAKERS FOUR WIRE WIRE CONTACT 600 OHM CLOSURE AUDIO PAGE PAGE RINGING...
  • Page 8 Wire an external switch (such as Viking model NS-1) across screw terminals 19 & 20. When the switch is closed, loud ringing will be disabled.

  • Page 9: Master Volume

    This audio input allows any additional audio sources to be connected into the SA-25 on screw terminals 10 & 11. Possible uses are: audio from another paging system, clock controlled tones to announce work shift times (see Viking model CTG-1), emergency siren (see Viking model DNA-510 or MTG-10), digitally recorded announcements (see Viking model DVA-500A or DVA-2WA), etc.

  • Page 10: Infrared Remote Control

    For more info, see DOD# 526 Due to the dynamic nature of the product design, the information contained in this document is subject to change without notice. Viking Electronics, and its affiliates and/or subsidiaries assume no respon- sibility for errors and omissions contained in this information. Revisions of this document or new editions of it may be issued to incorporate such changes.
