Viking TMS-RDMA User Manual

Technical Practice
Call Sequencer Remote Display Module
Features
• One inch LED display indicates next line to
answer
• Generates an audible, distinctive ring for
attendants
• Adjustable ringing volume
• Wall mount bracket included
• 6-wire installation
• Up to three remote display modules can be
connected to one Viking TMS-6X or TMS-12A
Call Sequencer
• Can be installed up to 1000 feet from the call
sequencer for a variety of applications
(optional PS-2 power supply allows 2000 feet)
• Bi-directional mounting
Telecommunication Peripheral Products
http://www.VikingElectronics.com
E-mail...Sales@VikingElectronics.com
The TMS-RDMA is designed to provide a remote
indication of the next line to answer for TMS-6X and
TMS-12A Call Sequencer users.
The TMS-RDMA generates audible ringing and
displays the line number of the oldest call waiting.
Attendants or agents can then answer calls in a
professional, timely manner.
Up to three remote displays can be used with one
Viking TMS-6X or TMS-12A Call Sequencer. The
TMS-RDMA has a one inch LED display and can be
wall mounted or placed on a desktop.
Applications
• For use with all Viking Call Sequencers,
including:
1. TMS-6X
2. TMS-12A
Sales...(715) 386 - 8861
Made in the U.S.A.
Specifications
Power: Call sequencer powered (20V DC/18mA minimum)
Dimensions: 75mm x 130mm x 40mm (2.9" x 5" x 1.5")
Shipping Weight: .45 kg (1 lb)
Environmental: 0 C to 32 C (32 F to 90 F) with 5% to 95% non-
condensing humidity
Connections: RJ25 jack
Maximum Cable Run: 305 m (1000 ft) (610 m (2000 ft) with
optional PS-2 power supply)
TMS-RDMA
Remote Display
Module
December 18, 1998
