Toshiba Memory Module Replacement Manual page 14

Replacing the memory module
Only remove the keyboard brace after completing steps 1-3. Otherwise,
you may damage the keyboard brace.
4. Remove two screws securing the keyboard as shown in the illustration
Use a size 0 Phillips screwdriver.
5. Lift the back of the keyboard toward you and lay it face down on the
■
■
3-6
below.
Keyboard
brace
Removing the keyboard brace and two screws
palmrest as shown in the illustration below.
When you move the keyboard forward, do not touch the keys. Doing so
could cause misalignment. Hold the keyboard by the sides and lay it
gently on the palmrest.
The keyboard is connected to the computer by a ribbon cable. Be
careful not to apply tension to this cable when you lift the keyboard. Do
not disconnect this cable.
Lift the keyboard
Screws
User's Manual
