SET-UP DIAGRAMS
Fig.2 DC Terminal Panel
HIGH FREQUENCY
NEGATIVE(-) TERMINAL
LOW FREQUENCY
NEGATIVE(-) TERMINAL
Fig.3 Single Wire Mode
'EARTH' OR 'GROUND' TERMINAL
LINKS IN PLACE
HIGH FREQUENCY
POSITIVE(+) TERMINAL
LOW FREQUENCY
POSITIVE(+) TERMINAL
TO RIGHT
SPEAKER
+ - + -
L R
POWER AMPLIFIER
TO 'GROUND' OR
'EARTH' CONNECTION
ON AMPLIFIER (OPTIONAL)
