Congratulations on your Coleman® solar product purchase. This product is designed to the highest
technical specifications and standards. It will supply years of maintenance free use. Please read
these instructions thoroughly prior to installation, then store in a safe place for future reference. If at
any time you are unclear about this product, or require further assistance please do not hesitate to
contact our trained professionals operating the customer support line 1-888-478-6435 or email to
info@sunforceproducts.com
12 Volt 30 Solar Charge Controller
Maintains 12V batteries in a fully charged state.

IMPORTANT SAFETY AND OPERATION INSTRUCTIONS

SAVE THESE INSTRUCTIONS.
This manual contains important safety and operation instructions for the 12 Volt 30 Amp Solar Charge
Controller. Keep this manual with or near the controller at all times.
LED lights will indicate the battery condition, and charge cycle status.
The 12 Volt 30 Amp Solar Charge Controller is designed to protect your 12 Volt Lead Acid or Gel Cell Battery
from being overcharged by the solar array as well as prevent the reverse flow of current resulting in the
draining of the battery during the night. The controller reduces overall system maintenance and prolongs the
life of the battery. This controller is designed to work with all makes of 12 Volt Solar Panels.
WARNINGS - Working with Batteries
RISK OF EXPLOSIVE GAS – Working in the vicinity of a lead acid battery is dangerous. Lead acid batteries
contain hydrogen-oxygen gases that can cause explosion and sulfuric acid that can cause severe burns.
Always work in a well ventilated area.
DO NOT SMOKE OR ALLOW A SPARK OR A FLAME IN THE VICINITY OF A BATTERY.
Remove personal metal items such as rings, necklaces, watches, and bracelets when working with a battery.
Be extra cautious to reduce risk of dropping a metal tool on to the battery. The battery may spark or short
circuit.
NEVER CHARGE A FROZEN BATTERY.
If battery acid contacts skin or clothing, wash immediately with soap and water. If acid enters the eye,
IMMEDIATELY FLOOD EYE WITH RUNNING COLD WATER for at least 10 minutes. GET MEDICAL
ATTENTION IMMEDIATELY.
Failure to comply with above warnings may lead to explosion, and or severe injury.
BE SURE TO DISCONNECT THE CONTROLLER FROM BATTERY AND SOLAR ARRAY BEFORE
PERFORMING ANY MAINTENANCE OR CLEANING.
DO NOT DISSASSEMBLE THE CONTROLLER.
INSTALLATION SHOULD BE PERFORMED BY A QUALIFIED PERSON.
DO NOT EXCEED MAXIMUM VOLTAGE AND CURRENT RATINGS.
DO NOT DEVIATE FROM WIRING INSTRUCTIONS.

Features

Battery voltage tester
•
Overcharge and discharge protection
•
Battery type selector
•
Safety circuit protectionThermal protection
•
Terminal block
•
Panel or wall mounting option
