A detailed guide to the FortiGate-5140 chassis. This FortiGate-5140-R Chassis Guide describes FortiGate-5140
hardware features, and how to install the FortiGate-5140 chassis.
The most recent versions of this and all FortiGate-5000 series documents are available from the
page of the
Fortinet Technical Documentation
Visit
http://support.fortinet.com
FortiGate-5140-R Chassis Guide
01-30000-87705-20090108
FortiGate-5140-R
13
11
9
7
5
3
1
FILTER
0
FA N TR AY
1
FAN TR AY
web site (http://docs.forticare.com).
to register your FortiGate-5140-R chassis. By registering you can receive product
updates, technical support, and FortiGuard services.
5140SAP
SERIAL 1
SERIAL 2
ALARM
5140
2
4
6
8
10
12
14
ETH0 ETH1
ETH0
Service
RESET
STATUS
Hot Swap
1 2
ETH0 ETH1
ETH0
Service
RESET
STATUS
Hot Swap
2
FAN TRAY
Chassis Guide
FortiGate-5000
Advertisement
Table of Contents
Related Manuals for Fortinet FortiGate 5140-R
Summary of Contents for Fortinet FortiGate 5140-R
- Page 1 FortiGate-5140 chassis. The most recent versions of this and all FortiGate-5000 series documents are available from the page of the Fortinet Technical Documentation Visit http://support.fortinet.com to register your FortiGate-5140-R chassis. By registering you can receive product updates, technical support, and FortiGuard services.
-
Page 2: Warnings And Cautions
ESD connector such as the ESD sockets provided on FortiGate-5000 series chassis. • Make sure all FortiGate-5000 series components have reliable grounding. Fortinet recommends direct connections to the building ground. •... -
Page 3: Table Of Contents
Turning on FortiGate-5140 chassis power ... 27 FortiGate-5140 hardware procedures ... 29 Mounting the FortiGate-5140 chassis ... 29 Air flow ... 29 Inserting 5000-series modules into a FortiGate-5140 chassis... 29 Using FortiSwitch-5003A and FortiSwitch-5003 boards for backplane communication... 30 FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... - Page 4 For more information... 31 Fortinet documentation ... 31 Fortinet Tools and Documentation CD ... 31 Fortinet Knowledge Center ... 31 Comments on Fortinet technical documentation ... 31 Customer service and technical support... 31 Register your Fortinet product ... 31 Contents...
-
Page 5: Fortigate-5140 Chassis
FortiGate-5140 chassis back panel • Physical description of the FortiGate-5140 chassis • FortiGate-5140 shelf managers • FortiGate-5140 shelf alarm panel • Shelf manager command line interface (CLI) • Air filter • Cooling fan trays FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... -
Page 6: Fortigate-5140 Chassis Front Panel
RESET shelf manager STATUS Hot Swap ETH0 ETH1 Secondary ETH0 Service shelf manager RESET STATUS Hot Swap Front accessible air filter Front cable tray Cooling fan trays 0, 1, 2 FAN TRAY “FortiGate-5140 FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... -
Page 7: Fortigate-5140 Chassis Back Panel
Figure 2 on page 7 includes two hot-swappable redundant -48V/-60 VDC power entry modules (PEMs) labelled A and B. Fortinet ships the FortiGate-5140 chassis with PEM A and B installed. The PEMs provide redundant DC power connections for the FortiGate-5140 chassis and distribute DC power to the chassis slots and to the fan trays. -
Page 8: Physical Description Of The Fortigate-5140 Chassis
Temperature: -13 to 158°F (-25 to 70°C) Relative humidity: 5 to 85% (Non-condensing) Maximum: 2,980W DC 2x redundant -37VDC to -72VDC, 30A per power feed (total 4 + 4 power feeds) FortiGate-5140 chassis 27). Use the back FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... - Page 9 ETH 0 and 1 network activity LEDs 5000SM Retention Screw Table 2: FortiGate-5140 shelf manager LEDs ETH 0 ETH 1 STATUS HOT SWAP FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback Reset Hot Swap Button 10/100 link/Act 10/100 link/Act ETH0 Status...
-
Page 10: Shelf Manager Fan And Power Control
Alarm cutoff (ACO) activated by pressing the alarm LED reset button. Amber Normal operation Amber Indicates a user-definable alarm. Blinking Alarm cutoff (ACO) activated by pressing the alarm LED reset button. Amber FortiGate-5140 chassis ALARM Telco Alarm Retention Interface Screw FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... -
Page 11: Shelf Alarm Panel Telco Alarms
The external dry relay Telco alarm interface (48VDC) provides Telco form-c relay connections for minor, major and critical power faults. The cable required to connect to the alarm interface is not supplied by Fortinet. SERIAL 2 ALARM Buffer I²C-Switch... -
Page 12: Shelf Manager Command Line Interface (Cli)
CriticalAlarm - NO CriticalAlarm - NC CriticalAlarm - COM MinorAlarm -NO MinorAlarm - NC MinorAlarm - COM MajorAlarm - NO MajorAlarm - NC MajorAlarm - COM PwrAlarm - NO PwrAlarm - COM Shelf Ground FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... - Page 13 Figure 7: Connecting to a shelf manager serial port To connect to the shelf manager CLI using a shelf alarm panel serial port 1 Connect the Fortinet console cable to the shelf alarm panel Serial 1 or Serial 2 port (see 2 Connect the Fortinet console cable to your PC or other device RS-232 console port.
-
Page 14: Air Filter
FortiGate-5140 chassis. To install a new filter, push the air filter into the guide rails at each side of the shelf until the filter locks into place. board <N> shm <N> power_supply <N> (valid in 2.x systems only) fan_tray <N> FortiGate-5140 chassis FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... -
Page 15: Cooling Fan Trays
Table 6: FortiGate-5140 fan tray LEDs and controls LED/Control OK (operate) Alarm LED HS (hot swap) HS (hot swap) button FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback FAN TR AY OK LED Alarm LED Hot swap LED Hot swap button Description Green when the fan tray is powered and operating normally. - Page 16 Cooling fan trays FortiGate-5140 chassis FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback...
-
Page 17: Power Connection And Configuration
The FortiGate-5140 chassis is designed to be installed in a data center or similar location that has available -48VDC power (also called battery power). Fortinet expects that most FortiGate-5140 customers will be installing their FortiGate equipment in a data center or similar location that is already equipped with a -48VDC power system that provides power to existing networking or telecom equipment. -
Page 18: Connecting A Fortigate-5140 Pem To Data Center Dc Power
Data Center RTN connector RTN (positive) red to Data Center RTN RETURN TERMINAL BLOCK COVER Remove terminal block cover and decable before removing PEM. RTN (positive) terminal strip connectors 1, 2, 3, 4 FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... -
Page 19: Connecting The Fortigate-5140 Chassis To Data Center Ground
An electrostatic discharge (ESD) preventive wrist or ankle strap with connection cord. • One green AWG-6 stranded wire with terminal lug with 45° angle tongue attached. FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback Power connection and configuration Figure Figure 2 on page... -
Page 20: Connecting The Fortigate-5140 Chassis To Ac Power Using The Fortigate-5053 Power Converter Tray
Connecting a FortiGate-5140 chassis to the FortiGate-5053 power converter tray • Connecting the FortiGate-5140 chassis to data center ground FortiGate-5140 Ground connector Data Center ground connector Figure 10). Figure 11) to convert AC power to DC FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... -
Page 21: Fortigate-5053 Power Converter Tray Front And Back Panel
FortiGate-5140 chassis. Each power zone supplies power to different FortiGate-5140 slots and cooling fan trays. You should always connect all 4 power zones. “Connecting a FortiGate-5140 chassis to the FortiGate-5053 power converter tray” on page 25 FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback removed Slot 3 Slot 2... -
Page 22: Selecting The Power Supplies And Power Convertor Trays That You Need For Your Fortigate-5140 Configuration
FortiGate-5140 chassis. This section provides guidelines only. Actual requirements may vary depending on your installation requirements. Contact Fortinet Technical Support if you need more information. The FortiGate-5053 power converter tray contains space for up to three FortiGate-5140 power supplies. - Page 23 3 FortiGate-5140 power supplies 2 x 1200W = 2400W 2 + 1 redundancy FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback Figure Note: If you will not be filling all of the FortiGate-5140 slots you may not need both FortiGate-5140 power supplies.
- Page 24 SERIAL 2 ALARM 5140 ETH0 ETH1 ETH0 Service RESET STATUS Hot Swap ETH0 ETH1 ETH0 Service RESET STATUS Hot Swap FILTER FA N TR AY FA N TR AY FA N T RAY FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback...
-
Page 25: Connecting A Fortigate-5140 Chassis To The Fortigate-5053 Power Converter Tray
Four red AWG-14 stranded wires with terminal lugs attached and labelled RTN • A FortiGate-5053 power converter tray containing two or three FortiGate-5140 power supplies and mounted in a rack near the FortiGate-5140 chassis. FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback FortiGate-5140 power supplies 2 FortiGate-5053 Slot 2... - Page 26 RTN (positive) -48V/-60 VDC terminal strip terminal strip connectors connectors 1, 2, 3, 4 1, 2, 3, 4 Figure 17): AC in TERMINAL BLOCK COVER Remove terminal block cover and decable before removing PEM. FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback...
-
Page 27: Connecting The Fortigate-5140 Chassis To Data Center Ground
• Green OK LED on all cooling fan trays (see are on the FortiGate-5140 front panel (see FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback Figure 18 shows how to connect four RTN (RED) and four -48V “Connecting the FortiGate-5140 chassis to to connect the FortiGate-5140 to data center ground. - Page 28 Figure 3 on page 9). None of the LEDs on the shelf alarm panel (SAP) should be Figure 4 on page 10). The shelf manager and shelf alarm panels are on the Figure 1 on page FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback...
-
Page 29: Fortigate-5140 Hardware Procedures
FortiGate-5000 series boards or with air baffle slot fillers. Air baffle slot fillers are similar to blank FortiGate-5000 boards and are required for proper cooling air flow. FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback “Power connection and configuration” on page Note: Mount the FortiGate chassis before connecting power and installing the FortiGate-5000 series modules. -
Page 30: Using Fortiswitch-5003A And Fortiswitch-5003 Boards For Backplane Communication
As well the removable PEM terminal block covers must be installed over the power connectors on the back of the chassis. FortiGate-5140 hardware procedures Guide. FortiGate-5140-R Chassis Guide 01-30000-87705-20090108 http://docs.fortinet.com/ • Feedback... -
Page 31: Comments On Fortinet Technical Documentation
Fortinet documentation is available from the Fortinet Tools and Documentation CD shipped with your Fortinet product. The documents on this CD are current for your product at shipping time. For the latest versions of all Fortinet documentation see the Fortinet Technical Documentation web site at http://docs.forticare.com. - Page 32 Register your Fortinet product © Copyright 2009 Fortinet, Inc. All rights reserved. No part of this publication including text, examples, diagrams or illustrations may be reproduced, transmitted, or translated in any form or by any means, electronic, mechanical, manual, optical or otherwise, for any purpose, without prior written permission of Fortinet, Inc.
