A detailed guide to the FortiGate-5050 chassis. This FortiGate-5050 Chassis Guide describes FortiGate-5050
hardware features, how to install the FortiGate-5050 chassis, and how to install FortiGate-5000 boards in the chassis.
The most recent versions of this and all FortiGate-5000 series documents are available from the
of the
Fortinet Technical Documentation
Visit
http://support.fortinet.com
FortiGate-5050 Chassis Guide
01-30000-87211-20090106
USB
1
2
CONSOLE
5
PWR
ACC
USB
1
2
CONSOLE
4
PWR
ACC
USB
CONSOLE
1
2
3
PWR
ACC
2
1
ShMC
2
web site (http://docs.forticare.com).
to register your FortiGate-5050 chassis. By registering you can receive product
updates, technical support, and FortiGuard services.
FortiGate-5050
3
4
5
6
7
8
STA IPM
3
4
5
6
7
8
STA IPM
3
4
5
6
7
8
STA IPM
ShMC
Critical
Hot Swap
Major
1
Status
Minor
Alarm
Alarm
Console
Ethernet
Reset
Chassis Guide
POWER
FortiGate-5000
page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FortiGate 5050 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fortinet FortiGate 5050

  • Page 1 FortiGate-5050 chassis, and how to install FortiGate-5000 boards in the chassis. The most recent versions of this and all FortiGate-5000 series documents are available from the of the Fortinet Technical Documentation Visit http://support.fortinet.com to register your FortiGate-5050 chassis. By registering you can receive product updates, technical support, and FortiGuard services.
  • Page 2: Warnings And Cautions

    ESD connector such as the ESD sockets provided on FortiGate-5000 series chassis. • Make sure all FortiGate-5000 series components have reliable grounding. Fortinet recommends direct connections to the building ground. •...
  • Page 3: Table Of Contents

    Using FortiSwitch-5003A and FortiSwitch-5003 boards for backplane communication... 24 For more information... 25 Fortinet documentation ... 25 Fortinet Tools and Documentation CD ... 25 Fortinet Knowledge Center ... 25 Comments on Fortinet technical documentation ... 25 Customer service and technical support... 25 Register your Fortinet product ...
  • Page 4 Contents FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 5: Fortigate-5050 Chassis

    FortiGate-5020/5050 power supplies. This chapter describes the FortiGate-5050 chassis and includes the following sections: • FortiGate-5050 front panel • FortiGate-5050 back panel • Physical description of the FortiGate-5050 chassis • FortiGate-5050 shelf manager FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 6: Fortigate-5050 Front Panel

    FortiGate-5050 chassis. The back panel includes two FortiGate-5050 chassis STA IPM STA IPM STA IPM Hot-swappable cooling fan tray POWER Power LED ShMC Critical Hot Swap Major Status Minor Alarm Alarm Console Ethernet Reset ESD socket FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 7: Physical Description Of The Fortigate-5050 Chassis

    Table 1 Table 1: FortiGate-5050 chassis physical description Dimensions Weight Operating environment Storage environment Power consumption Power input FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback INPUT A -48V DC VOLTAGE RANGE -48V -48V TO -58V (-DC IN) -48V to -58V...
  • Page 8: Fortigate-5050 Shelf Manager

    The external dry relay Telco alarm interface (48VDC) provides Telco form-c relay connections for minor, major and critical power faults. Serial connection to the command line interface. Provides access to Telnet , Web or SNMP management methods. FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 9: Shelf Manager Command Line Interface (Cli)

    To connect to the shelf manager CLI using the shelf manager console port 1 Connect a standard CAT5 RJ-45 Ethernet cable to the shelf manager Console port. 2 Connect the other end of the Ethernet cable to the SMC side of the Fortinet shelf manager console adapter (see...
  • Page 10 ____ _ __| ||_| _| | | | _ ____ | || | _ \| | | |\ \/ / ___\____|_||_|_| |_|\____|\_/\_/ FortiGate-5050 chassis FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 11: Fortigate-5050 Shelf Manager Alarm Functions

    The alarm reset button activates the ACO state but does not clear the alarm completely. Figure 5: The telco alarm connector (DB-15 male) FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback board <N> shm <N> power_supply <N> (valid in 2.x systems only) fan_tray <N>...
  • Page 12: Fortigate-5050 Shelf Management Functions

    AMINC MinorAlarm - NC AMINCOM MinorAlarm - COM AMANO MajorAlarm - NO AMANC MajorAlarm - NC AMACOM MajorAlarm - COM APRCO PwrAlarm - NO APRCOM PwrAlarm - COM Shelf-GND Shelf Ground FortiGate-5050 chassis FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 13: Power Connection And Configuration

    The FortiGate-5050 chassis is designed to be installed in a data center or similar location that has available -48VDC power (also called battery power). Fortinet expects that most FortiGate-5050 customers will be installing their FortiGate equipment in a data center or similar location that is already equipped with a -48VDC power system that provides power to existing networking or telecom equipment.
  • Page 14: Connecting The Fortigate-5050 Chassis To Data Center Ground

    Data Center -48VDC connector -48V to -58V (-DC in) black to Data Center -48VDC -48V to -58V Positive (-DC in) (RTN) (black) (red) Figure 2 on page 7). This connector must be connected Figure FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 15: Connecting The Fortigate-5050 Chassis To Ac Power Using The Fortigate-5053 Power Converter Tray

    Connecting a FortiGate-5050 chassis to the FortiGate-5053 power converter tray FortiGate-5053 power converter tray front and back panel The front panel of the FortiGate-5053 power converter tray (shown in access to the FortiGate-5020/5050 power supplies. FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback FortiGate-5050 Ground connector...
  • Page 16 LED lights. RTN(RED) -48V(BL ACK) (RTN) -48V (RED) (BLACK) DC out AC Power LED DC Power Slot 1 Figure 9) includes one DC power 100-240VAC 1 AC in Figure 8. Each FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 17: Selecting The Power Supplies And Power Converter Trays That You Need For Your Fortigate-5050 Configuration

    FortiGate-5050 chassis. This section provides guidelines only. Actual requirements may vary depending on your installation requirements. Contact Fortinet Technical Support if you need more information. The FortiGate-5053 power converter tray contains space for up to three FortiGate-5020/5050 power supplies.
  • Page 18 Major Hot Swap Status Minor Alarm Alarm Console Ethernet Reset CONSOLE STA IPM CONSOLE STA IPM CONSOLE STA IPM POWER ShMC ShMC Critical Hot Swap Major Status Minor Alarm Alarm Reset Console Ethernet FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 19 Slot 3 Slot 3 2 x 800W = 1600W 2 + 1 redundancy 2 x 800W = 1600W 2 + 1 redundancy FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback 2 FortiGate-5053 Slot 2 Slot 1 power convertor trays Slot 2...
  • Page 20: Connecting A Fortigate-5050 Chassis To The Fortigate-5053 Power Converter Tray

    (the left connector) to the terminal on the FortiGate-5050 power input connector labelled RTN. Caution: The FortiGate-5053 power converter tray should not be connected to AC power until specified in the following procedure. Figure 14). FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 21 FortiGate-5050 chassis. This photograph also shows the clear back cover of the FortiGate-5053 installed. You should install this cover using the mounting hardware provided. Install the cover after connecting the power but before turning the power on. FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback converter tray (RTN)
  • Page 22: Turning On Fortigate-5050 Chassis Power

    FortiGate-5050 to data center ground. Figure 8 on page Figure 3 on page “To connect the FortiGate-5050 chassis to 16). When the FortiGate-5053 power Figure 2 on Figure 1 on FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 23: Fortigate-5050 Hardware Procedures

    FortiGate-5000 series boards or with air baffle slot fillers. Air baffle slot fillers are similar to blank FortiGate-5000 boards and are required for proper cooling air flow. FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback “Power connection and configuration” on page Note: Mount the FortiGate chassis before installing the FortiGate-5000 series boards.
  • Page 24: Using Fortiswitch-5003A And Fortiswitch-5003 Boards For Backplane Communication

    As well the removable PEM terminal block covers must be installed over the power connectors on the back of the chassis. FortiGate-5050 hardware procedures Guide. FortiGate-5050 Chassis Guide 01-30000-87211-20090106 http://docs.fortinet.com/ • Feedback...
  • Page 25: For More Information

    Fortinet documentation is available from the Fortinet Tools and Documentation CD shipped with your Fortinet product. The documents on this CD are current for your product at shipping time. For the latest versions of all Fortinet documentation see the Fortinet Technical Documentation web site at http://docs.forticare.com.
  • Page 26 Register your Fortinet product © Copyright 2009 Fortinet, Inc. All rights reserved. No part of this publication including text, examples, diagrams or illustrations may be reproduced, transmitted, or translated in any form or by any means, electronic, mechanical, manual, optical or otherwise, for any purpose, without prior written permission of Fortinet, Inc.
