- Page 1 STANDARD CLEANING GAS RANGE Use & Care Guide For questions about features, operation/performance, parts, accessories or service, call: 1-800-843-0304 or visit our website at... www.amana.com Table of Contents ..........2 W10533015B...
-
Page 2: Table Of Contents
TABLE OF CONTENTS RANGE SAFETY ................3 Positioning Racks and Bakeware ..........10 The Anti-Tip Bracket ..............4 Bakeware..................10 Oven Vent ...................10 BATTERY USE ................5 Baking and Roasting ..............11 Installing/Replacing the Battery ...........5 Broiling..................11 Battery Status Indicator ...............6 RANGE CARE ................12 PARTS AND FEATURES..............7 Removing the Oven Bottom............12 COOKTOP USE ................8 General Cleaning ................12... -
Page 3: Range Safety
RANGE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 4: The Anti-Tip Bracket
The Anti-Tip Bracket The range will not tip during normal use. However, the range can tip if you apply too much force or weight to the open door without the anti-tip bracket fastened down properly. WARNING Tip Over Hazard A child or adult can tip the range and be killed. Verify the anti-tip bracket has been properly installed and engaged per installation instructions. -
Page 5: Battery Use
BATTERY USE Installing/Replacing the Battery 3. Using a Phillips screwdriver, remove the metal battery top from the bottom of the range and open the plastic battery box. A. Battery holder location 4. Remove the battery holder and insert a new 9V DC alkaline battery into it. -
Page 6: Battery Status Indicator
5. Replace the battery holder in the plastic battery box with the battery facing the bottom and the blue wires facing up, and Battery Status Indicator close the plastic battery box. The battery status indicator on the control panel will show the recommended time to replace the battery. -
Page 7: Parts And Features
PARTS AND FEATURES This manual covers several different models. The range you have purchased may have some or all of the parts and features listed. The locations and appearances of the features shown here may not match those of your model. Control Panel A. -
Page 8: Cooktop Use
COOKTOP USE To Set Oven Temperature: Cooktop/Oven Temperature Controls 1. Push in and turn oven control knob counterclockwise to LITE. 2. Look through the hole in the oven bottom to verify that the pilot inside the cavity is lit. WARNING Fire Hazard Do not let the burner flame extend beyond the edge of the pan. -
Page 9: Home Canning
Gas tube opening: Gas must flow freely throughout the gas tube opening for the burner to light properly. Keep this area free of soil Home Canning and do not allow spills, food, cleaning agents or any other When canning for long periods, alternate the use of surface material to enter the gas tube opening. -
Page 10: Oven Use
OVEN USE Odors and smoke are normal when the oven is used the first few times, or when it is heavily soiled. Bakeware IMPORTANT: The health of some birds is extremely sensitive to The bakeware material affects cooking results. Follow the fumes given off. -
Page 11: Baking And Roasting
To Broil: Baking and Roasting 1. Open the broiler door and take out the broiler pan and grid. 2. Place food on the grid so grease can drain down into the IMPORTANT: To avoid damage to the interior finish, do not place lower part of the broiler pan. -
Page 12: Range Care
RANGE CARE COOKTOP CONTROLS Removing the Oven Bottom The oven bottom can be removed for standard cleaning of the To avoid damage to the cooktop controls, do not use steel wool, oven. abrasive cleansers or oven cleaner. Before cleaning, make sure the oven is completely cool. To avoid damage, do not soak knobs. -
Page 13: Oven Door
2. Grasp the door on the sides with your fingers on the front of OVEN CAVITY the door and your thumbs on the inside surface. Food spills should be cleaned when oven cools. At high temperatures, foods react with porcelain and staining, etching, pitting or faint white spots can result. -
Page 14: Troubleshooting
TROUBLESHOOTING Try the solutions suggested here first in order to avoid the cost of an unnecessary service call. Nothing will operate Cookware not level on cooktop Is the main gas shutoff valve in the off position? Is the range level? See the Installation Instructions. -
Page 15: Assistance Or Service
® replacement parts will fit right and work right because they are Appliances with any questions or concerns at: ® made with the same precision used to build every new Amana Amana Customer Service appliance. 553 Benson Road To locate factory specified replacement parts in your area, call us Benton Harbor, MI 49022-2692 or your nearest designated service center. -
Page 16: Warranty
If you need service, first see the “Troubleshooting” section of the Use & Care Guide. After checking “Troubleshooting,” you may find additional help by checking the “Assistance or Service” section or by calling Amana. In the U.S.A., call 1-800-843-0304. In Canada, call 1-800-807-6777.
