LEFT SLIDER=
CONTROL
LIGHTS OFF & ON
PANEL
LIGHT REPLACEMENT
a) Switch off the power to rangehood.
b) Use a small bladed screwdriver to prise off the light cover.
c) Use a cloth to remove the bulb. Do not touch the bulb with
fingers.
d) Replace with a new bulb using a cloth. Do not touch the bulb
with fingers. "Snap" the cover back in place.
e) Halogen bulb 12Volt/20Watt required.
For other accessories, parts or service, please contact your local supplier
(Refer to the Warranty Certificate).
I N S T A L L A T I O N
O P T I O N
DUCTED
UNIDUCT FLEXI DUCT KIT is
recommended.
1569 Flexi Duct Kit (150mm)
For other Accessories, Parts or Service, please contact your local supplier or approved service agent
WARNINGS
•
Care should be taken when removing filters in order to prevent the filter
falling and causing damage to the hob top.
•
This appliance is not intended for use by young children or infirm persons without
supervision.
•
Young children should be supervised to ensure that they do not play with the
appliance.
•
Upon installation the appliance must be positioned so that the plug is
accessible.
•
There should be adequate ventilation of the room when the rangehood is used at
the same time as appliances burning gas or other fuels.
•
You must read the details concerning the method and frequency of cleaning.
•
There is a fire risk if cleaning is not carried out in accordance with the instructions.
•
Do not flambé under the rangehood.
•
Exhaust air must not be discharged into an existing flue used for exhausting
fumes from appliances burning gas or other fuels.
•
The recomended minimum distance between the hob surface and the lowest part
of the rangehood is 600mm. This should be increased to at least 650mm
if installed over a gas hob. We recommend 700mm.
•
Attention should be given to ensure that any applicable regulations concerning
the discharge of exhaust air is fulfilled.
•
If the supply cord of this equipment is damaged, it must only be replaced by the
manufacturer or it's service agent, or a similarly qualified person in order to
avoid a hazard.
Australasian Distributor for Ariston Appliances
Ph: AUS (03) 9557 4044 - NZ (09) 306 10 20
RECOMMENDED UNIDUCT DUCTING
SYSTEMS FOR RANGEHOODS
RIGHT SLIDER=
FAN OFF / LOW/ MED / HIGH SPEED
CONTROL LIGHT=
A C C E S S O R I E S
RECIRCULATED
Use Manufacturer Product code:
1744 Recirculation Kit
Arisit Pty Ltd
Electrical Rating:
385W (1.60A)
Max. at 230-240V 50Hz
CANOPY RANGEHOOD
I N S T A L L A T I O N
RHB9IX
RHB8IX
BULB
PLEASE READ THE ENTIRE INSTRUCTION BEFORE INSTALLING THE CANOPY
P R O D U C T
All Dimensions are in mm
I N S T R U C T I O N
D I M E N S I O N S
318mm
900 / 800mm
277mm
500mm
104803 issue B
ECN 04179
