Recall preset #1 SysEx: CO 01
Recall preset #2 SysEx: CO 02
Example 8
Preset Recall to eight 1788A-R's. 1788A-R MIDI Channels set 1 to 8
Recall preset #1 SysEx: CO 01 C1 01 C2 01 C3 01 C4 01 C5 01 C6 01 C7 01
Recall preset #2 SysEx: CO 02 C1 02 C2 02 C3 02 C4 02 C5 02 C6 02 C7 02
Example 9
Preset Recall to eight 1788A-R's. 1788A-R MIDI Channels set 1 to 8 and Banks set 1 to eight respectively.
This is an example of a complex recall.
Bank 1 preset 1, Bank 2 preset 2, Bank 3 preset 2, Bank 4 preset 4, Bank 5 preset 1, Bank 6 preset 6, Bank 7
preset 42, Bank 8 preset 60
SysEx: CO 01 C1 02 C2 02 C3 04 C4 01 C5 06 C6 2A C7 3C
Example 10
Direct MIDI. 4 1788A's with MIDI Channels set to 01, Dev set to 01, 02, 03, and 04. Net set to 001 (this is not
important). Looped through MIDI Thru jacks.
Mute all 32 mic channels.
F0 00 00 38 00 00 00 07 01 01 07 02 01 07 03 01 07 04 01 07 05 01 07 06 01 07 07 01 07 08 01 F7 F0 00 00 38
00 01 00 07 01 01 07 02 01 07 03 01 07 04 01 07 05 01 07 06 01 07 07 01 07 08 01 F7 F0 00 00 38 00 02 00 07
01 01 07 02 01 07 03 01 07 04 01 07 05 01 07 06 01 07 07 01 07 08 01 F7 F0 00 00 38 00 03 00 07 01 01 07 02
01 07 03 01 07 04 01 07 05 01 07 06 01 07 07 01 07 08 01 F7
It's easier to it see this way:
F0 00 00 38 00 [00] 00 [07 01 01] [07 02 01] [07 03 01] [07 04 01] [07 05 01] [07 06 01] [07 07 01] [07 08 01] F7
F0 00 00 38 00 [01] 00 [07 01 01] [07 02 01] [07 03 01] [07 04 01] [07 05 01] [07 06 01] [07 07 01] [07 08 01] F7
F0 00 00 38 00 [02] 00 [07 01 01] [07 02 01] [07 03 01] [07 04 01] [07 05 01] [07 06 01] [07 07 01] [07 08 01] F7
F0 00 00 38 00 [03] 00 [07 01 01] [07 02 01] [07 03 01] [07 04 01] [07 05 01] [07 06 01] [07 07 01] [07 08 01] F7
Un-Mute all 32 mic channels:
F0 00 00 38 00 [00] 00 [07 01 00] [07 02 00] [07 03 00] [07 04 00] [07 05 00] [07 06 00] [07 07 00] [07 08 00] F7
F0 00 00 38 00 [01] 00 [07 01 00] [07 02 00] [07 03 00] [07 04 00] [07 05 00] [07 06 00] [07 07 00] [07 08 00] F7
F0 00 00 38 00 [02] 00 [07 01 00] [07 02 00] [07 03 00] [07 04 00] [07 05 00] [07 06 00] [07 07 00] [07 08 00] F7
F0 00 00 38 00 [03] 00 [07 01 00] [07 02 00] [07 03 00] [07 04 00] [07 05 00] [07 06 00] [07 07 00] [07 08 00] F7
Summary
We hope the information, references and examples in this chapter will make understanding MIDI control a lot
easier for you. A little time spent studying this material may save you many hours of frustration and grief later
on. Contact Aphex tech support should you run into any problems we haven't covered here.
