AOpen MX34 Online Manual

AOpen MX34 Online Manual

Hide thumbs Also See for MX34:
Table of Contents

Advertisement

Quick Links

Download this manual
M
X
3
4
O
n
l
i
n
e
M
a
n
u
a
l
M
X
3
4
O
n
l
i
n
e
M
a
n
u
a
l
MX34
DOC. NO. : MX34-OL-E0103D
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX34 and is the answer not in the manual?

Questions and answers

Related Manuals for AOpen MX34

Summary of Contents for AOpen MX34

  • Page 1: W H A T ' S I N T H I S M A N U A L Mx34

    MX34 DOC. NO. : MX34-OL-E0103D...

  • Page 2: Table Of Contents

    ’ ’ MX34......................1 What’s in this manual..........................2 Before You Start..........................8 Quick Installation Procedure ......................9 Motherboard Map ..........................10 Block Diagram........................... 11 Hardware.....................12 JP14 Clear CMOS ..........................13 CPU Socket ............................14 CPU Fan and Housing Fan Connector ....................15 CPU Jumper-less Design .........................16 JP29/JP23 FSB/PCI Clock Ratio .....................19 DIMM Socket ............................21...
  • Page 3 AC Power Auto Recovery .........................26 IDE and Floppy Connector .......................27 IrDA Connector ..........................30 WOM (Zero Voltage Wake on Modem)....................31 WOL (Wake on LAN) ........................34 4X AGP (Accelerated Graphic Port)....................36 PC99 Color Coded Back Panel......................37 Support 4 USB Ports ........................38 JP12 Enable/Disable Onboard Sound .....................39 CD Audio Connector .........................40 AUX-IN Connector ..........................41 Modem Audio Connector ........................42...
  • Page 4 Resettable Fuse..........................48 Year 2000 (Y2K) ..........................49 1500uF Low ESR Capacitor ......................51 Layout (Frequency Isolation Wall)....................53 Driver and Utility..................54 Autorun Menu from Bonus CD Disc ....................55 Installing Windows 95 ........................56 Installing Windows 98 ........................57 Installing Windows 98 SE, Windows ME & Windows2000..............58 Installing VIA 4 in 1 Driver ........................59 Installing Onboard Sound Driver ......................60 Installing Hardware Monitoring Utility....................61...
  • Page 5 Glossary Glossary AC97 ..............................80 ACPI (Advanced Configuration & Power Interface).................80 AGP (Accelerated Graphic Port) ......................80 AMR (Audio/Modem Riser) ......................81 AOpen Bonus Pack CD ........................81 APM..............................81 ATA/66 ...............................81 ATA/100.............................82 BIOS (Basic Input/Output System) ....................82 Bus Master IDE (DMA mode) ......................82 CODEC (Coding and Decoding) ......................82...
  • Page 6 DIMM (Dual In Line Memory Module) ....................83 ECC (Error Checking and Correction) .....................83 EDO (Extended Data Output) Memory ....................83 EEPROM (Electronic Erasable Programmable ROM) ..............83 EPROM (Erasable Programmable ROM) ..................84 FCC DoC (Declaration of Conformity) .....................84 FC-PGA.............................84 Flash ROM ............................84 FSB (Front Side Bus) Clock ......................85 I2C Bus .............................85 P1394 ..............................85...
  • Page 7 PnP (Plug and Play) .........................86 POST (Power-On Self Test) ......................87 RDRAM (Rambus DRAM) ........................87 RIMM ..............................87 SDRAM (Synchronous DRAM) ......................87 SIMM (Single In Line Memory Module) ...................88 SMBus (System Management Bus)....................88 SPD (Serial Presence Detect)......................88 Ultra DMA/33 ............................88 USB (Universal Serial Bus) ......................89 ZIP file ...............................89 Troubleshooting...................90 Technical Support................94...

  • Page 8: Before You Start

    This Online Manual is in format, we recommend using Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD disc or you can get free download from Adobe web site. Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy printing, you can print it by A4 paper size and set 2 pages per A4 sheet on your printer.

  • Page 9: Quick Installation Procedure

    This page gives you a quick procedure on how to install your system. Follow each step accordingly. 1 1 1 1 Installing 2 2 2 2 Installing System Memory (DIMM) 3 3 3 3 Connecting Front Panel Cable 4 4 4 4 Connecting IDE and Floppy Cable 5 5 5 5 Connecting ATX Power Cable...

  • Page 10: Motherboard Map

    Modem-CN JP12 Onboard Sound PC99 Back Panel CD-IN Resettable Fuse AUX-IN 4X AGP Expansion Slot CPU Fan Connector System Voltage & Fan Monitoring Front Audio Connector Buzzer Socket370 CPU with Voltage and Wakeup on Modem Frequency Auto-detection ® ® supports Intel Pentium Wakeup on LAN &...

  • Page 11: Block Diagram

    Clock Generator 66/100/133MHz FSB North Bridge AGP Card VIA 694X DIMM 4X mode 66/100/133 AGP Bus Memory Bus PCI Card ATA 66/100 PCI Bus IDE Bus HDD/CDROM South Bridge AC97 Link USB, Serial port, Printer and VIA 686A Audio PS2 KB/Mouse (686B for CODEC optional)

  • Page 12: Hardware

    This chapter describes jumpers, connectors and hardware devices of this motherboard. Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components. Always observe the following precautions before you install a system component. 1.Do not remove a component from its protective packaging until you are ready to install it.

  • Page 13: Jp14 Clear Cmos

    You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. 1. Turn off the system and unplug the AC power. 2. Remove ATX power cable from connector PWR2. 3. Locate JP14 and short pins 2-3 for a few seconds. 4.

  • Page 14: Cpu Socket

    This motherboard supports Celeron, and Pentium III FC-PGA Socket370 CPU. Be careful of CPU orientation when you pug it into CPU socket.

  • Page 15: Cpu Fan And Housing Fan Connector

    Plug in the CPU fan cable to the 3-pin CPUFAN connector. If you have other housing fan, you can also plug it on FAN connector. +12V +12V SENSOR Note: Some CPU fans do not have sensor pin, so that cannot support fan monitoring.

  • Page 16: Cpu Jumper-Less Design

    CPU VID signal and SMbus clock generator provide CPU voltage auto-detection and allows the user to set the CPU frequency through the BIOS setup, therefore no jumpers or switches are used. The correct CPU information is saved into the EEPROM. With these technologies, the disadvantages of the Pentium based jumper-less designs are eliminated.
  • Page 17 This motherboard is CPU jumper-less design, you can set CPU frequency through the BIOS setup, no jumpers or switches are needed. BIOS Setup > Chipset Features Setup > CPU Clock Frequency BIOS Setup > Chipset Features Setup > CPU Clock Ratio CPU Ratio 1.5x, 2x, 2.5x, 3x, 3.5x, 4x, 4.5x, 5x, 5.5x, 6x, 6.5x, 7x, 7.5x, and 8x 66.8, 75, 83.3, 100, 103, 105, 110, 112, 115, 120, 124, 133,...
  • Page 18 Core Frequency = CPU Clock * CPU Ratio CPU Core Frequency FSB Clock Ratio CELERON 300A 300MHz 66MHz 4.5x CELERON 600 600MHz 66MHz CELERON 700 700MHz 66MHz 10.5x CELERON 800 800MHz 100MHz CELERON 850 850MHz 100MHz 8.5x Pentium!!! 700E 700MHz 100MHZ Pentium!!! 750E 750MHz...

  • Page 19: Jp29/Jp23 Fsb/Pci Clock Ratio

    This jumper is used to specify the relationship of PCI and clock. Generally speaking, if you are not overclockers, we recommend to set at the default setting. For example, you must set JP29 to “5-6” and JP23 to “3-4” if you want to overclock a 66MHz FSB clock CPU to 100MHz or higher.
  • Page 20 PCI Clock = CPU FSB Clock / Clock Ratio Clock = PCI Clock x 2 Clock Ratio CPU (Host) Memory PCI x2 or x3 PCI x2 or x3 or x4 3X, overclocking 37.3 74.6 PCI x2 or x3 or x4 PCI x3 or x4 4X, overclocking 38.75...

  • Page 21: Dimm Socket

    This motherboard has three 168-pin DIMM sockets that allow you to install PC133 memory up to 1.5GB. Only SDRAM is supported. Tip: The driving capability of new generation chipset is limited due to the lack of a memory buffer (to improve performance).
  • Page 22 DIMM can be single side or double side, it has 64 bit data and 2 or 4 clock signals. We strongly recommend choosing 4-clock SDRAM for its reliability Tip: To identify 2-clock and 4-clock DIMM, you may check if there are traces connected to the golden finger pins 79 and 163 of the SDRAM.

  • Page 23: Front Panel Connector

    Keylock SPWR ACPI & IDE LED Power LED Speaker Reset SPWR KEYLOCK ACPI & PWR LED IDE LED IDE LED RESET SPEAKER...
  • Page 24 Attach the power LED, keylock, speaker, and reset switch connectors to the corresponding pins. If you enable Power Management > Suspend Mode in BIOS Setup, the ACPI & Power LED will keep flashing while the system is in suspend mode. Suspend Type ACPI LED Power on Suspend (S1)

  • Page 25: Atx Power Connector

    The ATX power supply uses 20-pin connector shown below. Make sure you plug in the right direction. PW-OK +3.3V 5VSB +3.3V +12V +3.3V -12V PS-ON...

  • Page 26: Ac Power Auto Recovery

    A traditional ATX system should remain at power off stage when AC power resumes from power failure. This design is inconvenient for a network server or workstation, without an UPS, that needs to keep power-on. This motherboard implements an AC Power Auto Recovery function to solve this problem.

  • Page 27: Ide And Floppy Connector

    Connect 34-pin floppy cable and 40-pin IDE cable to floppy connector FDC and IDE connector The blue connector is IDE1 for clear identification. Be careful of the pin1 orientation. Wrong orientation may cause system damage. Slave (4th) Master (3rd) IDE2 (Secondary) IDE1 (Primary) Pin 1 Pin 1...
  • Page 28 IDE1 is also known as the primary channel and IDE2 as the secondary channel. Each channel supports two IDE devices that make a total of four devices. In order to work together, the two devices on each channel must be set differently to master and slave mode. Either one can be the hard disk or the CDROM.
  • Page 29 This motherboard supports ATA 66 IDE (ATA/100 for optional). Following table lists the transfer rate of IDE PIO and DMA modes. The IDE bus is 16-bit, which means every transfer is two bytes. Mode Clock Period Clock Cycle Time Data Transfer Rate Count PIO mode 0 30ns...

  • Page 30: Irda Connector

    The IrDA connector can be configured to support wireless infrared module, with this module and application software such as Laplink or Windows 95 Direct Cable Connection, the user can transfer files to or from laptops, notebooks, PDA devices and printers. This connector supports HPSIR (115.2Kbps, 2 meters) and ASK-IR (56Kbps).

  • Page 31: Wom (Zero Voltage Wake On Modem)

    This motherboard implements special circuit to support Wake On Modem, both Internal modem card and external box modem are supported. Since Internal modem card consumes no power when system power is off, it is recommended to use an internal modem. To use internal modem, connect 4-pin cable from RING connector of modem card to the WOM connector on the motherboard.
  • Page 32 Traditional Green PC suspend mode does not really turn off the system power supply, it uses external box modem to trigger MB COM port and resume back to active. TEL Line Box Modem COM port Motherboard...
  • Page 33 Both an external box modem and an internal modem card can be used to support Modem Wake Up, but if you use an external modem, you have to leave your box modem Modem Card TEL Line With AOpen Motherboard plus AOpen Modem Card, the power can be totally off Motherboard...

  • Page 34: Wol (Wake On Lan)

    This feature is very similar as Wake On Modem, but it goes through local area network. To use Wake On LAN function, you must have a network card with chipset that supports this feature, and connect a cable from LAN card to motherboard WOL connector. The system identification information (probably IP address) is stored on network card and because there is a lot of traffic on the Ethernet, you need to install a network management software, such as ADM, for the checking of how to wake up the system.
  • Page 35 Ethernet LAN Card Motherboard...

  • Page 36: Agp (Accelerated Graphic Port)

    This motherboard supports 4X AGP. AGP is a bus interface designed for high-performance 3D graphic and supports only memory read/write operation. One motherboard can only have one AGP slot. 2X AGP uses both rising and falling edge of the 66MHz clock, the data transfer rate is 66MHz x 4 bytes x 2 = 528MB/s.

  • Page 37: Pc99 Color Coded Back Panel

    The onboard I/O devices are PS/2 Keyboard, PS/2 Mouse, serial ports COM1 and COM2, Printer, four USB, AC97 sound and Game port. The view angle of drawing shown here is from the back panel of the housing. MIDI/Game PS/2 Mouse Port SPP/EPP/ECP Parallel Connector...

  • Page 38: Support 4 Usb Ports

    This motherboard supports four USB ports. Two of them are on back panel connector, the other two are on the left-bottom area of this motherboard. With proper cable, you can connect them to front panel. Pin 1 9 10...

  • Page 39: Jp12 Enable/Disable Onboard Sound

    This motherboard has AC97 sound onboard. JP12 is used to enable or disable onboard AD1885 CODEC chip. If you select Disable, you can use your preferred PCI sound card. Disable Enable...

  • Page 40: Cd Audio Connector

    This CD-IN is used to connect CD Audio cable from CDROM or DVD drive to onboard sound. CD-IN...

  • Page 41: Aux-In Connector

    The AUX-IN connector is used to connect MPEG Audio cable from MPEG card to onboard AUX-IN...

  • Page 42: Modem Audio Connector

    This connector is used to connect Mono In/Mic Out cable from internal modem card to onboard sound circuit. The pin 1-2 is Mono In, and the pin 3-4 is Mic Out. Please note that there is no standard for this kind of connector yet, only some internal modem cards implement this connector. Pin 1 Mono-In (To Modem) MIC-Out (From Modem)

  • Page 43: Front Audio Connector

    If the housing has been design with an audio port on the front panel, you’ll be able to connect onboard audio to front panel through this connector. By the way, please remove the jumper cap from the Front Panel Audio Connector before you connect the cable. Do not remove this yellow jumper cap if housing without an audio port on the front panel.

  • Page 44: Battery-Less And Long Life Design

    This Motherboard implements EEPROM and a special circuit that allows you to save your current CPU and CMOS Setup configurations without the need of a battery. The RTC (real time clock) can also keep running as long as the power cord is plugged. If you lose your CMOS data by accident, you can just reload the CMOS configurations from EEPROM and the system will recover as usual.

  • Page 45: Over-Current Protection

    The Over Current Protection was very popular implemented on ATX 3.3V/5V/12V switching power supply. However, the new generation CPU uses different voltage that has regulator to transfer 5V to CPU voltage (for example, 2.0V), and makes 5V over current protection useless. This motherboard with switching regulator onboard support CPU over-current protection, in conjunction with 3.3V/5V/12V power supply provide the full line over-current protection.
  • Page 46 CPU, memory, HDD, add-on cards installed on this motherboard may be damaged because of component failure, human operating error or unknown nature reason. AOpen cannot guaranty the protection circuit will always work perfectly.

  • Page 47: Hardware Monitoring

    This motherboard implements a hardware monitoring system. As you turn on your system, this smart design will continue to monitor your system’s working voltage, fan status and CPU temperature. If any of these system’s status go wrong, there will be an alarm through the AOpen Hardware Monitoring Utility to warn the user.

  • Page 48: Resettable Fuse

    Traditional motherboard has fuse for Keyboard and port to prevent over-current or shortage. These fuses are soldered onboard that when it is broken (did the job to protect motherboard), user still cannot replace it and the motherboard is still malfunction. With expensive Resettable Fuse, the motherboard can back to normal function after fuse did the protection job.

  • Page 49: Year 2000 (Y2K)

    Y2K is basically a problem of the identification of year code. To save storage space, traditional software uses only two digits for year identification. For example, 98 for 1998 and 99 for 1999, but 00 will be confused with 1900 and 2000. There is an RTC circuit (Real Time Clock) in conjunction with 128 bytes of CMOS RAM data in the chipset of the motherboard.
  • Page 50 CMOS is a very slow device which degrades system performance. The Tick Routine of the AOpen BIOS has 4 digits for year coding, as long as applications and the operating system follow the rule to get date/time information. There will be no Y2K problem (such as NSTL’s test program).

  • Page 51: 1500Uf Low Esr Capacitor

    The quality of low ESR capacitor (Low Equivalent Series Resistance) during high frequency operation is very important for stability of CPU power. The location of where to put these capacitors is another know-how that requires experience and detail calculation. Not only that, this motherboard implements Low ESR capacitors, which is much larger than normal (1000uF) and provide better stability for CPU power.
  • Page 52 The power circuit of the CPU core voltage must be checked to ensure system stability for high speed CPUs (such as the new Pentium III, or when overclocking). A typical CPU core voltage is 2.0V, so a good design should control voltage between 1.860V and 2.140V. That is, the transient must be below 280mV.

  • Page 53: Layout (Frequency Isolation Wall)

    For high frequency operation, especially overclocking, layout is the most important factor to make sure chipset and CPU working in stable condition. The layout of this motherboard implements AOpen’s unique design called “ Frequency Isolation Wall”. Separating each critical portion of motherboard into regions where...

  • Page 54: Driver And Utility

    There are motherboard drivers and utilities included in AOpen Bonus CD disc. You don’t need to install all of them in order to boot your system. But after you finish the hardware installation, you have to install your operation system first (such as Windows 98) before you can install any drivers or utilities.

  • Page 55: Autorun Menu From Bonus Cd Disc

    You can use the autorun menu of Bonus CD disc. Choose the utility and driver and select model name.

  • Page 56: Installing Windows 95

    First, don’t install any add-on card except card. Install Windows 95 OSR2 v2.1, 1212 or 1214 version and later with USB support. Otherwise, you need to install USBSUPP.EXE. Install the VIA 4 in 1 driver, which includes VIA AGP Vxd driver, VIA ATAPI Vendor Support driver and VIA registry (INF) program.

  • Page 57: Installing Windows 98

    First, don’t install any add-on card except card. Enable USB Controller in BIOS Setup > Advanced Chipset Features > COntroller, to make BIOS fully capable of controlling IRQ assignment. Install Window 98 into your system. Install the VIA 4 in 1 driver, which includes VIA AGP Vxd driver, IRQ Routing, VIA ATAPI Vendor Support driver and VIA registry (INF) program.

  • Page 58: Installing Windows 98 Se, Windows Me & Windows2000

    & & ® ® ® If you are using Windows 98 Second Edition, Windows Millennium Edition or Windows 2000, you do not need to install the 4-in-1 driver as the IRQ Routing Driver and the ACPI Registry are ® already incorporated into the operating system. Users with Windows 98 SE may update the VIA Registry INF and AGP drivers by installing them individually.

  • Page 59: Installing Via 4 In 1 Driver

    You can install the VIA 4 in 1 driver (IDE Bus master (For Windows NT use), VIA ATAPI Vendor Support Driver, VIA AGP, IRQ Routing Driver (For Windows 98 use), VIA Registry (INF) Driver) from the Bonus Pack CD disc Autorun menu. Note: Installing this Bus Master IDE driver may cause Suspend to Hard Drive failure.

  • Page 60: Installing Onboard Sound Driver

    If this motherboard comes with an AD 1885 AC97 CODEC, you can find the audio driver from the Bonus Pack CD disc autorun menu.

  • Page 61: Installing Hardware Monitoring Utility

    You can install Hardware Monitoring Utility to monitor CPU temperature, fans and system voltage. The hardware monitoring function is automatically implemented by the BIOS and utility software, no hardware installation is needed.

  • Page 62: Acpi Suspend To Hard Drive

    ACPI Suspend to Hard Drive is basically controlled by Windows operation system. It saves your current work (system status, memory and screen image) into hard disk, and then the system can be totally power off. Next time, when power is on, you can resume your original work directly from hard disk within few seconds without go through the Windows booting process and run your application again.
  • Page 63 When go into Suspend: System Image & Hard Status Save into Disk When power-on next time: System Hard Image & Disk Status Restore within seconds...

  • Page 64: System Requirement

    System Requirement AOZVHDD.EXE 1.30b or later. Delete config.sys and autoexec.bat. Fresh installation of Windows 98 on a new system 1. Execute "Setup.exe /p j" to install Windows 98 2. After Windows 98's installation is complete, go to the Control Panel > Power Management. a.
  • Page 65 b. If you assign an individual partition for Win 98, please run "aozvhdd /c /partition". Of course, the system needs to provide unformatted an empty partition. Reboot system. You've already implemented ACPI Suspend to-Hard Drive. Click "Start > Shut Down > Standby"...
  • Page 66 Changing from APM to ACPI (Windows 98 only) 1. Run "Regedit.exe" a. Go through the following path HKEY_LOCAL_MACHINE SOFTWARE MICROSOFT WINDOWS CURRENT VERSION DETECT b. Select "ADD Binary" and name it as "ACPIOPTION". c. Right click and select Modify, add "01" after "0000" to make it "0000 01". d.
  • Page 67 Changing from ACPI to APM 1. Run "Regedit.exe" a. Go through the following path HKEY_LOCAL_MACHINE SOFTWARE MICROSOFT WINDOWS CURRENT VERSION DETECT ACPI OPTION b. Right click and select "Modify, change "01" to "00" to make it "0000 02". Tip: "02" means Windows 98 is ACPI acknowledged but the ACPI function is disabled.
  • Page 68 4. Run "Add New Hardware" again and it will find "Advanced Power Management Resource". 5. Click "OK". Tip: Currently we found only ATI 3D Rage Pro AGP card would support ACPI suspend to disk. Please refer to AOpen web site for latest update.

  • Page 69: Acpi Suspend To Ram (Str)

    This motherboard supports ACPI Suspend to RAM function. With this function, you can resume your original work directly from DRAM without going through the Windows 98 booting process and run your application again. Suspend to DRAM saves your current work in the system memory, it is faster than Suspend to Hard Drive but requires power supplied to DRAM, while Suspend to Hard Drive requires no power.
  • Page 70 To implement ACPI Suspend to DRAM, please follow the procedures as below: System Requirement An ACPI OS is required. Currently, Windows 98 is the only choice. Please refer to ACPI Suspend to Hard Drive of how to setup Windows 98 ACPI mode. The VIA 4 in 1 Driver must have been installed properly.

  • Page 71: Award Bios

    System parameters can be modified by going into BIOS Setup menu, this menu allows you to configure the system parameters and save the configuration into the 128 byte CMOS area, (normally in the RTC chip or in the main chipset). To enter to BIOS setup menu, press <Del>...

  • Page 72: How To Use Award™ Bios Setup Program

    Award™ BIOS setup program. By the way, all products of AOpen also provides a special function in the BIOS setup, you can press <F3> key selecting preferred menu language to display.
  • Page 73 Load turbo setting value from CMOS. Save changed setting and exit setup program. Note: AOpen always dedicates to give users a more friendly computer system. Now, we include all function descriptions of BIOS setup program into the BIOS Flash ROM. When you select one function of BIOS setup program, the function description will appeared at right side of screen.

  • Page 74: How To Enter Bios Setup

    After you finish the setting of jumpers and connect correct cables. Power on and enter the BIOS Setup, press <Del> during POST (Power-On Self Test). Choose "Load Setup Defaults" for recommended optimal performance. Warning: Please avoid of using "Load Turbo Defaults", unless you are sure your system components (CPU, DRAM, HDD, etc.) are good enough for turbo setting.

  • Page 75: Bios Upgrade

    Caution: AOpen Easy Flash BIOS programs are designed to be compatible with the Award BIOS. At the date of this note, AOpen Easy Flash BIOS programs are not available for AMI BIOS. AMI BIOS appears mostly only on old 486 boards and some early Pentium boards.
  • Page 76 Below are the steps for easy flashing procedures: (applies for Award BIOS ONLY) 1. Download new BIOS upgrade file from AOpen's web site. For example, MX34102.ZIP. 2. Run shareware PKUNZIP (http://www.pkware.com/) which supports miscellaneous operation systems to extract the binary BIOS file and the flash utility.

  • Page 77: Overclocking

    As a leading manufacturer in motherboard industry, AOpen always listens to what customers want and develop products to fit different user's requirements. Reliability, compatibility, leading technology and friendly features are our basic goals when designing motherboards. Other than above mentioned design criteria, there are power users who are always seeking to push the limitation of the system performance by overclocking which we call them "Overclocker".
  • Page 78 Warning: The design of this product follows CPU and chipset vendor's design guideline. Any attempts to push beyond product specification are not recommended and you are taking your own risk to damage your system or important data. Before doing overclocking, you must make sure your components are able to tolerate such abnormal setting, especially CPU, memory, hard disks, and AGP VGA cards.

  • Page 79: Vga Card & Hard Disk

    VGA and HDD is key components for overclocking, for your reference, the following list are what have been successful overclocked in our lab. Please note that AOpen can not guaranty they can be successful overclocked again. Please check the Available Vendor List (AVL) by link to our official website.

  • Page 80: Glossary

    66MHz clock, for 2X AGP, the data transfer rate is 66MHz x 4byte x 2 = 528MB/s. AGP is now moving to 4X mode, 66MHz x 4byte x 4 = 1056MB/s. AOpen is the first company to...

  • Page 81: Amr (Audio/Modem Riser)

    AC97 sound/modem solution can be put on motherboard or put on a riser card (AMR card) that connects to motherboard through AMR connector. A disc bundled with AOpen motherboard product, there are motherboard drivers, Acrobat Reader online manual and other useful utilities.

  • Page 82: Ata/100

    ATA/100 is a new IDE specification under developing. ATA/100 uses both rising edge and falling edge as ATA/66 but clock cycle time is reduced to 40ns. The data transfer rate is (1/40ns) x 2 bytes x 2 = 100MB/s. To use ATA/100, you need special 80-wire IDE cable, the same as ATA/66. BIOS is a set of assembly routine/program that reside in EPROM Flash...

  • Page 83: Dimm (Dual In Line Memory Module)

    Also known as E PROM. Both EEPROM and Flash ROM can be re-programmed by electronic signals, but the interface technology is different. Size of EEPROM is much smaller than flash ROM, AOpen motherboard uses EEPROM for jumper-less and battery-less design.

  • Page 84: Eprom (Erasable Programmable Rom)

    Because of increase of new functions, BIOS size is increased from 64KB to 256KB (2M bit). AOpen AX5T is the first board to implement 256KB (2Mbit) Flash ROM. Now flash ROM size is moving to 4M bit on AX6C (Intel 820) and MX3W (Intel...

  • Page 85: Fsb (Front Side Bus) Clock

    FSB Clock means CPU external bus clock. CPU internal clock = CPU FSB Clock x CPU Clock Ratio See SMBus. P1394 (IEEE 1394) is a standard of high-speed serial peripheral bus. Unlike low or medium speed USB, P1394 supports 50 to 1000Mbit/s and can be used for video camera, disk and LAN. The parity mode uses 1 parity bit for each byte, normally it is even parity mode, that is, each time the memory data is updated, parity bit will be adjusted to have even count "1"...

  • Page 86: Pnp (Plug And Play)

    asynchronous SRAM. PBSRAM is often used on L2 (level 2) cache of Socket 7 CPU. Slot 1 and Socket 370 CPU do not need PBSRAM. SDRAM DIMM that supports 100MHz CPU bus clock. SDRAM DIMM that supports 133MHz CPU bus clock. A file format for electronic document, PDF format is independent from platform, you can read PDF file under Windows, Unix, Linux, Mac …...

  • Page 87: Post (Power-On Self Test)

    FPM are asynchronous and do not have clock signal). It is similar as PBSRAM to use burst mode transfer. SDRAM comes in 64-bit 168-pin DIMM and operates at 3.3V. AOpen is the first company to support dual-SDRAM DIMMs onboard (AP5V), from Q1 1996...

  • Page 88: Simm (Single In Line Memory Module)

    SIMM socket is only 72-pin, and is only single side. The golden finger signals on each side of PCB are identical. That is why it was called Single In Line. SIMM is made by FPM or DRAM and supports 32-bit data. SIMM had been phased out on current motherboard design. SMBus is also called I2C bus.

  • Page 89: Usb (Universal Serial Bus)

    16.6MB/s x2 = 33MB/s USB is a 4-pin serial peripheral bus that is capable of cascading low/medium speed peripherals (less than 10Mbit/s) such as keyboard, mouse, joystick, scanner, printer and modem. With USB, the traditional complex cables from back panel of your PC can be eliminated. A compressed file format to reduce file size.

  • Page 90: Troubleshooting

    Start Turn off the power and unplug the AC power cable, then remove all of the add-on cards and cables, including VGA, IDE, FDD, COM1, COM2 and printer. Make sure if all jumper settings are correct. Clear CMOS Next...
  • Page 91 Continue Install the VGA card. Then connect your monitor and keyboard. Turn on the power and check if the power supply and CPU fan work properly. The problem is probably caused by power supply or motherboard failure. Next Please contact your reseller or local distributor for repairing.
  • Page 92 Continue Perhaps your VGA card Check if there is display? or monitor is defective. Press <Ctrl> and <Alt> key at the same time, hold them and then press <Del> to reboot the system. It is very possible that Check if the system your keyboard is reboots?
  • Page 93 Continue During system rebooting, press <Del> to enter BIOS setup. Choose “Load Setup Default”. Turn off the system and re-connect IDE cable. The problem should be Check if the system can caused by the IDE cable reboot successfully? or HDD itself.

  • Page 94: Technical Support

    Dear Customer, Thanks for choosing AOpen products. To provide the best and fastest service to our customer is our first priority. However, we receive numerous emails and phone-calls worldwide everyday, it is very hard for us to serve everyone on time. We recommend you follow the procedures below and seek help before contact us.
  • Page 95 3 3 3 3 FAQ: The latest FAQ (Frequently Asked Questions) may contain a solution to your problem. http://www.aopen.com.tw/tech/faq/default.htm 4 4 4 4 4 4 4 4 Download Software: Check out this table to get the latest updated BIOS/utility and drivers.

  • Page 96: Part Number And Serial Number

    7 7 7 7 7 7 7 7 Contact Us: Please prepare detail system configuration and error symptom before contacting us. The part number, serial number and BIOS version are also very helpful. The Part Number and Serial number are printed on bar code label. You can find this bar code label on the outside packing, on ISA/CPU slot or on component side of PCB.

  • Page 97: Model Name And Bios Version

    Model name and BIOS version can be found on upper left corner of first boot screen (POST screen). For example: MX34 R1.00 Feb.01.2001 AOpen Inc. Award Plug and Play BIOS Extension v1.0A Copyright © 1998, Award Software, Inc. MX34 is model name of motherboard, R1.00 is BIOS version.
  • Page 98 America Pacific Rim Europe AOpen America Inc. AOpen Inc. AOpen Computer b.v. Tel: 1-510-498-8928 Tel: 886-2-2696-1333 Tel: 31-73-645-9516 Fax: 1-408-922-2935, 1-408-432-0496 Fax: 886-2-8691-2233 Fax: 31-73-645-9604 Germany China AOpen Computer GmbH. 艾尔鹏国际上海(股)有限公司 Tel: 49-2102-157700 Tel: 49-2102-157700 Fax: 49-2102-157799 Fax: 49-2102-157799 Web Site: www.aopen.com...
