Product Information

The Color Passive-Matrix mini-touch panels contain a 5.5" (13.97 cm) mini 256 color passive-
matrix liquid crystal display (LCD). The self-contained enclosures use a microprocessor to control
a wide range of multimedia equipment. Using the TPDesign3 Touch Panel design program, you
create custom pages with buttons, icons, sliders, bargraphs, time displays, logos, and drawings. The
table below lists the Mini-Color Passive LCD touch panel types and product names.
Mini-Color Passive LCD Touch Panel Types and Product Names
Panel Types
Decor-style
Rack-mount
TiltScreen

Specifications

The table below lists the AXD-MCP (/PB), AXM-MCP (/PB), and AXT-MCP (/PB) specifications.
Specifications
Dimensions (HWD):
AXD-MCP
AXT-MCP
AXM-MCP
Screen Dimensions
Display Type
Screen Resolution (HV) • 320 x 240 pixels
Visible Area
Dot Pixel Count
Contrast Ratio
Brightness
Viewing Angle
Weight:
AXD-MCP
AXT-MCP
AXM-MCP
Power
Memory
5.5" Color Passive Mini-Touch Panels
Product Names
Standard
AXD-MCP
AXM-MCP
AXT-MCP
• 5.00" x 6.98" x 2.17" (12.7 cm x 17.73 cm x 5.51 cm [low-profile Back Box])
• 4.17" x 6.98" x 2.94" (10.59 cm x 17.73 cm x 7.47 cm [CB-MTP Back Box])
• Base dimensions (WD): 8.23" x 7.51" (20.90 cm x 19.08 cm)
• Display height: 3.87" (9.83 cm) fully lowered, 5.95" (15.11 cm) fully raised
• 5.22" x 19.0" x 2.37" (13.26 cm x 48.26 cm x 6.02 cm)
• 5" diagonal viewing angle - 3.05" x 4.06" (7.75 cm x 10.31 cm)
• Color Passive-Matrix LCD
• 115.60 mm x 87.60 mm
• 0.323 mm
• 30:1
2
• 150 cd/m
• Horizontal: +35° (left/right from center)
• Vertical: +15° (up from center) and -25° (down from center)
• 3.9 lbs. (1.7 kg)
• 2.1 lbs. (0.95 kg)
• 3.6 lbs. (1.6 kg)
• 485 mA @ 12 VDC
• 512 KB (standard) (2 MB FLASH)
Pushbuttons
AXD-MCP/PB
AXM-MCP/PB
AXT-MCP/PB
