  • Page 1 Do not import other template elements such as page layout. To return to the draft version, import color def’ns from draft-colors.fm. To switch to the beta version, import color def’ns from beta-colors.fm OmniAccess 5740 Unified Services Gateway Getting Started Guide Release 3.0...
  • Page 2 The following information is for the Users of the OmniAccess 5740 Unified Services Gateway: If it is not installed in accordance with the installation instructions, it may not function exactly to the said specifications.

  • Page 3: Table Of Contents

    Package Contents........................1 Required Tools and Equipment ..................2 Connecting AC Input Power...................... 3 Connecting to the OmniAccess 5740 USG Console Port ............5 Starting the OmniAccess 5740 USG..................7 Performing Basic Configuration Tasks..................9 Accessing the OmniAccess 5740 USG Through CLI ............
  • Page 4 List of Figures Connecting the Power Cord on OmniAccess 5740 USG 3 Connecting to the OmniAccess 5740 USG System Console 5...
  • Page 5 List of Tables Console Properties 6 OmniAccess 5740 USG LED Status 8 Cable Connection 16...

  • Page 6: Package Contents

    OmniAccess 5740 Unified Services Gateway Overview OmniAccess 5740 Unified Services Gateway Overview The OmniAccess 5740 Unified Services Gateway (OmniAccess 5740 USG) is designed to provide most commonly used network services, such as routing, switching, wide area network (WAN) connectivity, network security with firewall, and related services using a non-modular platform providing Ethernet switching and a single WAN interface.

  • Page 7: Required Tools And Equipment

    Warning: Only trained and qualified personnel should be allowed to install or replace the OmniAccess 5740 USG. Refer to the warnings and safety notes that are given in the “OmniAccess 5740 Unified Services Gateway Hardware Users Guide” provided with this device.

  • Page 8: Connecting Ac Input Power

    Step 2: Verify that the power switch located on the rear panel is in OFF (O) position. Step 3: Connect the system end of the connector to the OmniAccess 5740 USG as shown in the figure above. Step 4: Identify a power source point that complies with the system specifications, and connect the power plug of the AC cable to the utility power socket.
  • Page 9 Step 5: Ensure that the cable is not left in a hazardous position that could impair movement of personnel or be frayed due to the movement of other equipment in the vicinity. Warning: Read the installation instructions before you connect the OmniAccess 5740 USG to its power source. Alcatel-Lucent...

  • Page 10: Connecting To The Omniaccess 5740 Usg Console Port

    CCESS ONSOLE The OmniAccess 5740 USG has a RJ-45 console port connector. A RJ-45 - RJ-45 “roll-over” cable along with RJ-45 to DB-9 (female) adapter is provided with the system to access the console port via a DTE (computer/terminal). For additional connector details, refer to “Pin Connector Details for OmniAccess 5740 USG”...
  • Page 11 Step 1: Connect the RJ-45 end of the console cable to the front panel console port on the OmniAccess 5740 USG and the DB-9 end to the serial port (COM) on your computer/terminal. Step 2: Start your terminal emulation software.

  • Page 12: Starting The Omniaccess 5740 Usg

    After installing your OmniAccess 5740 USG and connecting cables, follow the procedure given below to start the system: Step 1: Before you power ON the OmniAccess 5740 USG, check the following: • Ensure that the power supply tray is securely inserted into the chassis.
  • Page 13 SE card is active. Yellow Indicates transient conditions (e.g., booting). The following is an example of a bootup message on OmniAccess 5740 USG: OmniAccess 5740 USG Bootup Message Example: == Press ^C for Boot options == == Initiating startup sequence == Mounting internal storage medium...OK.

  • Page 14: Performing Basic Configuration Tasks

    ERFORMING ASIC ONFIGURATION ASKS Once you boot OmniAccess 5740 USG and connect to the console, you can start configuring your OmniAccess 5740 USG either through the Command Line Interface (CLI) or the web-based Graphical User Interface (GUI). 5740 USG T...
  • Page 15 ! SNMP Configurations snmp agent rocommunity aluro aaa services username admin password 5 21232f297a57a5a743894a0e4a801fc3 username recovery password 5 3d58967910ffdbc56565ad089182fbf4 username superadmin password 5 21232f297a57a5a743894a0e4a801fc3 enable password 5 21232f297a57a5a743894a0e4a801fc3 aaa authorization disable Alcatel-Lucent OmniAccess 5740 Unified Services Gateway Getting Started Guide Beta Beta...
  • Page 16 GigabitEthernet3/1 shutdown interface Vlan1 ip address 192.168.1.1/24 no shutdown interface switchport0/0 no shutdown interface switchport0/1 shutdown interface switchport0/2 shutdown interface switchport0/3 shutdown interface switchport0/4 shutdown interface switchport0/5 shutdown Alcatel-Lucent OmniAccess 5740 Unified Services Gateway Getting Started Guide Beta Beta...
  • Page 17 !Snort configuration firewall intrusion snort ! Firewall configuration ! IPSEC License installed ! IPSEC Policy configuration ! No client object Defined ! No client profile Defined! !QoS Configuration !DDNS configurations Alcatel-Lucent OmniAccess 5740 Unified Services Gateway Getting Started Guide Beta Beta...
  • Page 18 192.168.1.0 255.255.255.0 range 192.168.1.2 192.168.1.254 ! DHCP CLIENT Configuration ip dhcp client default_client vendor-class-identifier FDC broadband-forum.org parameter-req-list vendor-specific interface GigabitEthernet3/0 dhcp client default_client !OAM Configuration Alcatel-Lucent OmniAccess 5740 Unified Services Gateway Getting Started Guide Beta Beta...
  • Page 19 In case of reload, the system always boots up with the factory default configuration unless you explicitly save the modified configuration. For further configuration of your OmniAccess 5740 USG, refer to the “OmniAccess 5740 Unified Services Gateway CLI Configuration Guide”...

  • Page 20: Accessing The Omniaccess 5740 Usg Through Gui

    Step 3: Enter the default user name and password (superadmin/admin, admin), and press the Enter key. Step 4: This will launch a web interface to configure your OmniAccess 5740 USG. For further configuration of your OmniAccess 5740 USG, refer to the “OmniAccess 5740 Unified Services Gateway Web GUI Users Guide”.

  • Page 21: Cable Connection

    ONNECTION The connections and cables listed here are described in detail in the “OmniAccess 5740 Unified Services Gateway Hardware Users Guide”. The following table summarizes the cable connections for the OmniAccess 5740 USG: Table 3: Cable Connection Module Port Type...
