Meinberg C600RS Characteristics

C600RS: DCF77 radio clock with serial RS232 interface
Serial DCF77 radio clock with integrated power supply and free running clock in plastic housing and
integrated power supply (incl. antenna and 5m cable)

Key Features

- Integrated Power Supply
- Pulses per second and per minute
- 20mA input/output circuits
- RS232 interface
- Receiver status LEDs
- Buffered hardware clock
- DCF77 radio clock
Description
The radio remote clock C600RS has been designed for applications where only the serial interface is used to transmit
information on date and time to other devices. The clock has an enhanced LF receiver and is manufactured using
surface mounting technology (SMT). The elevtronic assembly is mounted in a plastic case with four LEDs in the front
panel which let the user monitor the clock's status.
RS232 interface and 20mA input/output circuits. Pulse per second and pulse per minute. These pulses are made
available at the DB25 connector via optocoupler outputs. The P_SEC pulse is also available with RS-232 level
(-3..12V/+3..12V).
rev 2013.0704.1632 Page 1/3
