IMPORTANT SAFETY INSTRUCTIONS
WARNING:
If the instructions contained in this manual are not followed
precisely, fire or explosion may result causing property damage, personal
injury or loss of life.
- Do not store or use gasoline or other flammable vapors or liquids near this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switches.
• Do not use any telephones in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• lf you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service
agency or gas supplier.
READ AND SAVE THESE INSTRUCTIONS – Your safety and the safety of others are very important.
We have provided many important safety messages throughout this manual and on the appliance.
Read all the instructions before using the appliance and always obey all safety messages.
RECOGNIZE SAFETY INFORMATION
This is a safety alert symbol. This symbol alerts you to potential hazards that can result in severe
personal injury or loss of life.
UNDERSTAND SIGNAL WORDS
A signal word – DANGER, WARNING, or CAUTION – is used with the safety alert symbol. DANGER
denotes the most serious hazards. It means you could lose your life or be seriously injured if you do not
immediately follow the instructions. WARNING means you could lose your life or be seriously injured if
the instructions are not followed. CAUTION indicates a potentially hazardous situation which, if not
avoided, could result in minor to moderate injury.
Important Safety Instruction
3
Advertisement
Related Manuals for Smeg C6GGXU
Summary of Contents for Smeg C6GGXU
-
Page 1: Important Safety Instruction
Important Safety Instruction IMPORTANT SAFETY INSTRUCTIONS WARNING: If the instructions contained in this manual are not followed precisely, fire or explosion may result causing property damage, personal injury or loss of life. - Do not store or use gasoline or other flammable vapors or liquids near this or any other appliance. -
Page 2: Fire Hazard
Important Safety Instruction The safety messages will inform you of potential hazards, on how to avoid the risk of injury and what can occur if the instructions are not followed. IMPORTANT: Observe all governing codes and ordinances. WARNING: For your safety, the instructions contained in this manual must be followed to minimize the risk of fire or explosion and to prevent property damage, personal injury or loss of life. - Page 3 Conversion Kit Check that the main gas supply line to the range is shut off and that the power supply cord is disconnected. Remove access cap “A” by using a screwdriver or a coin, turning the access cap counterclockwise. The gas pressure regulator has two settings which are indicated on two sides of the cap. Turn the cap and reinstall it in the regulator with "LP"...
- Page 4 Conversion Kit Replacing the oven's burners nozzles (This operation does not require primary air regulation.) Oven burner 1 Open the oven door remove accessories that inside. 2 For 35” - 908mm model unscrew fastening screws before removing the oven floor. 3 Lift the oven floor and slide it out.
- Page 5 Conversion Kit 9 Screw in the burner's fastening screw. 10 Reposition oven floor making sure to insert it correctly. The floor must be perfectly level. 11 For the 35” - 908mm model screw fastening screws after having repositioned the oven floor. Broil burner 1 Unscrew burner's...
- Page 6 Conversion Kit To adjust the range for LP gas or to return to Natural Gas use, refer to the charts below. C6GGXU ” - 608 mm) Natural gas Rear left Rear right Injector Ø mm Front Right 6200 1.20 1500...
- Page 7 Conversion Kit C9GGXU ” - 908 mm) Natural gas Rear Rear left Rear right Injector center Ø mm Front Right 6200 1.20 1500 Front central 3400 0.90 1200 Front Left 6200 1.20 1500 Rear Left 3400 0.90 1200 Outer 12000 1.17 (n.2) 4000 Rear...
-
Page 8: Natural Gas
Conversion Kit FIRE HAZARD Use a soapy solution to check that it is leak-tight. WARNING Never test for gas leaks with a match or other flames. Failure to follow this instruction can result in loss of life or fire Follow these instructions to leak test the appliance: Use a brush and liquid detergent to test all gas connections for leaks.
