FAX Option Type 2027
Getting Started
1
2
Faxing
3
Using Internet Fax Functions
Programming
4
Troubleshooting
5
For safe and correct use of this machine, please be sure to read the Safety Information in the
General Settings Guide before you use it.

Operating Instructions

Facsimile Reference
<Basic Features>

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2027 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Savin 2027

Summary of Contents for Savin 2027

  • Page 1: Operating Instructions

    FAX Option Type 2027 Operating Instructions Facsimile Reference <Basic Features> Getting Started Faxing Using Internet Fax Functions Programming Troubleshooting For safe and correct use of this machine, please be sure to read the Safety Information in the General Settings Guide before you use it.
  • Page 2 Other product names used herein are for identification purposes only and might be trademarks of their respective companies. We disclaim any and all rights in those marks. Instructions for the optional extra G3 interface unit (G3 Interface Unit Type 2027) are included in the Basic Features and Advanced Features manuals.

  • Page 3: Manuals For This Machine

    Manuals for This Machine The following manuals describe the operational procedures of this machine. For particular functions, see the relevant parts of the manual. Note ❒ Manuals provided are specific to machine type. ❒ Adobe Acrobat Reader is necessary to view the manuals as a PDF file. ❒...
  • Page 4 ❖ ❖ ❖ ❖ Manuals for DeskTopBinder V2 Lite DeskTopBinder V2 Lite is a utility included on the CD-ROM labeled “Scanner Driver & Document Management Utilities”. • DeskTopBinder V2 Lite Setup Guide (PDF file - CD-ROM2) Describes installation of, and the operating environment for DeskTop- Binder V2 Lite in detail.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Manuals for This Machine ..................i NOTICE ........................1 Important Safety Instructions ................3 Caution........................3 How to Read This Manual ..................4 Symbols ........................4 1. Getting Started Control Panel......................5 Reading the Display ....................7 Reading the display panel and using keys ..............7 Reading the Destination List..................
  • Page 6 Specifying a Destination ..................37 Entering a Fax Number .................... 37 Pause ........................37 Tone ........................38 Entering an E-mail Address ..................38 Using Destination Lists..................... 39 Searching for a Destination ................42 Search by Destination Name ................... 42 Search by Fax Number .................... 43 Search by E-mail Address..................

  • Page 7: Notice

    NOTICE Note to users in the United States of America - Notice: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential in- stallation.
  • Page 8 - Notice about the Telephone Consumer Protection Act (Valid in USA only). The Telephone Consumer Protection Act of 1991 makes it unlawful for any per- son to use a computer or other electronic device, including FAX machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending ma-...

  • Page 9: Important Safety Instructions

    Important Safety Instructions Caution When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, includ- ing the following: • Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 10: How To Read This Manual

    How to Read This Manual Symbols In this manual, the following symbols are used: R WARNING: This symbol indicates a potentially hazardous situation that might result in death or serious injury when you misuse the machine without following the in- structions under this symbol.

  • Page 11: Getting Started

    1. Getting Started Control Panel The actual machine control panel may differ from this illustration depending on installed optional units. This illustration has all options installed. ZLBS000N Indicators Display Panel Shows errors and machine status. This guides you through tasks and dis- plays the machine status.
  • Page 12 Getting Started On indicator Confidential file indicator This indicator lights when the operation Lights when a message is received into switch is turned on. memory with Confidential Reception or Personal Box. See p.41 “Printing Personal Important Box Messages”, Facsimile Reference <Ad- ❒...

  • Page 13: Reading The Display

    Control Panel { { { { Clear/Stop} } } } key Number keys Use to dial fax numbers, or enter the Clear: number of copies. Cancels entered numbers or characters. { { { { #} } } } key (Enter key) Stop: Interrupts the current operation (trans- Programs entered contents or settings.
  • Page 14 Getting Started Displays the entered number of a Displays Quick Operation Keys destination. When adding destina- set for often used functions. [TX File tions using the number keys, press Status] and [RX File Status] are preset. [Add]. Displays various functions for Press to display various informa- transmitting.

  • Page 15: Reading The Destination List

    Control Panel Reading the Destination List When using the facsimile function, only fax or Internet Fax destinations pro- grammed in the Address Book appears. ❖ ❖ ❖ ❖ Destination List ZLBX060E Title word keys appear. Allows Appears on Quick Dial keys pro- you to switch from one page (dis- grammed as a transfer station.

  • Page 16: Standby Display

    Getting Started Standby Display While the machine is in standby mode (immediately after the { { { { Facsimile} } } } key is pressed or after the { { { { Clear Modes} } } } key is pressed), the following display appears. ❖...

  • Page 17: Communication Display

    Control Panel Communication Display While communicating, the machine status is displayed. ❖ ❖ ❖ ❖ Memory Transmission (fax transmission) Note ❒ While e-mail is being sent, the message appears. "Sending E-mail...:" ❖ ❖ ❖ ❖ Reception Note ❒ Even when the machine is being used as a copier, printer, or scanner, the sender name or number will appear for received faxes.

  • Page 18: User Code Entry Display

    Getting Started User Code Entry Display When the following message appears on the display, User Code Management is active. Enter a user code to deactivate User Code Management. The machine can be set up so that no one can use it without entering a user code. This prevents unauthorized people from sending fax messages and helps track the activity of each user or department.

  • Page 19: Faxing

    2. Faxing Transmission Modes ❖ ❖ ❖ ❖ Immediate Transmission There are two types of transmission: Immediately dials the destination • Memory Transmission number, and while reading the • Immediate Transmission original, sends it. It is very conve- nient when you want to send an ❖...

  • Page 20: Switching Between Memory Transmission And Immediate Transmission

    Faxing Note ❒ You can use Parallel Memory Transmission that dials while the original is being scanned. See p.77 “Parallel Mem ory Transmission”, Facsimile Refer- ence <Advanced Features> . Switching between Memory Transmission and Immediate Transmission Check the display to see which mode is currently active.

  • Page 21: Placing Originals

    Placing Originals Placing Originals ❖ ❖ ❖ ❖ How to place A5 and B5 JIS size You can place the originals either in the optional ADF or on the exposure originals glass. Some types of originals are un- Where to place originals suitable for the ADF, so they must be Original Exposure glass...

  • Page 22: Placing A Single Original On The Exposure Glass

    Faxing ❒ When sending an original of irreg- Placing a Single Original on ular (i.e. custom) size or part of a large original, you can specify the the Exposure Glass scan area precisely. See p.18 “Set- ting a Scan Area”. Place originals that cannot be placed ❒...

  • Page 23: Bound Original Page Order

    Placing Originals ❒ Documents longer than 800 mm Bound original page order (32") must be sent by memory transmission (immediate transmis- When setting bound originals (books, sion is not possible). magazines, etc.), you can select to ❒ If your original is bent or folded, have either the left page or right page flatten it before you place it.

  • Page 24: Originals Unsuitable For The Optional Auto Document Feeder

    Faxing Originals unsuitable for the optional Setting a Scan Area Auto Document Feeder Normally, a placed document is Do not place the following types of scanned according to the automati- originals in the ADF because they cally detected size. If a scan area is may be damaged.
  • Page 25 Placing Originals A A A A B Press the size of the originals Place the originals, and then se- to be sent, and then press [OK]. lect any scan settings you require. Note ❒ When placing different size originals into the ADF, adjust the document guide to the larg- est original.
  • Page 26 Faxing B Press [OK]. "Area 1" or "Area 2" is shown above the highlighted [Scan Ar- ea]. Specifying Auto Detect A Make sure that [Auto Detect] is selected. Note ❒ If it is not, press [Auto Detect]. B Press [OK]. “Auto Detect”...

  • Page 27: Original Sizes Difficult To Detect

    Placing Originals Original sizes difficult to detect The machine finds it difficult to detect the size of the following kinds of origi- nals. If this happens, the receiving machine may not select print paper of the cor- rect size. • Documents placed on the exposure glass of sizes other than those listed in the table below •...

  • Page 28: Memory Transmission

    Faxing Memory Transmission In Memory Transmission mode, after Limitation you press the { { { { Start} } } } key, the machine ❒ If memory is full (0% appears on does not dial the destination until all the display), Memory Transmis- pages of your fax message have been sion is disabled.
  • Page 29 Memory Transmission ❒ You can have the machine return B B B B Place the original. to the default transmission mode (Memory Transmission or Imme- Note diate Transmission) after every ❒ You can send the first few pages transmission. You can change this from the exposure glass then so that the desired setting is main- the remaining pages from the...
  • Page 30 Faxing D D D D F F F F Specify a destination. Specify a destination. Note Note ❒ If you make a mistake, press the ❒ Press to switch the destina- { { { { Clear/Stop} } } } key, and then enter tion between fax number and e- the correct number.

  • Page 31: Broadcasting Sequence

    Memory Transmission Place the next original on the expo- After checking the settings on the display, press the { { { { Check Modes} } } } sure glass within 60 seconds after the machine has finished scanning key. The display before the { { { { Check the first original.

  • Page 32: Canceling A Memory Transmission

    Faxing Canceling a Memory Transmission Even when fax number and e-mail Note address are simultaneously specified, ❒ You can also cancel scanning by or only e-mail address is specified, pressing [Stop Scanning]. you can cancel the mode using the ❒ Scanning may be completed same procedure.

  • Page 33: Before The Transmission Is Started

    Canceling a Memory Transmission B B B B Select the file you want to cancel. Before the Transmission Is Started Use this procedure to cancel a trans- mission after the original has been scanned. A A A A Press [Change/Stop TX File]. Note ❒...
  • Page 34 Faxing Note ❒ To cancel another file, repeat steps ❒ To cancel stopping transmis- sion, press [Save]. D D D D Press [Exit]. The standby display appears.

  • Page 35: Immediate Transmission

    Immediate Transmission Immediate Transmission ❒ You can have the machine return With Immediate Transmission, when you press the { { { { Start} } } } key, the fax to the default transmission mode number is dialed immediately. The (Memory Transmission or Imme- message is scanned and transmitted diate Transmission) after every page by page without being stored in...
  • Page 36 Faxing B B B B Note Place the original. ❒ If you make a mistake, press the Note { { { { Clear/Stop} } } } key, and then enter ❒ You can scan a few pages of the correct number. your original from the exposure Reference glass and the remaining pages...

  • Page 37: Canceling An Immediate Transmission

    Canceling an Immediate Transmission Canceling an Immediate Transmission Before You Have Pressed the { { { { Start} } } } Key A A A A Press the { { { { Clear Modes} } } } key. ZLBS050N Note ❒...

  • Page 38: Scan Settings

    Faxing Scan Settings ❖ ❖ ❖ ❖ Detail (8 x 7.7 lines/mm, 200 x 200 dpi) You may want to send many different types of fax messages. Some of these Select for originals containing may be difficult to reproduce at the small characters or when you re- receiver's end.

  • Page 39: Original Type

    Scan Settings ❒ You can select the resolution type Original Type that is selected right after the ma- chine is turned on or modes are If your original contains photo- cleared with [Scan End Reset] under graphs, illustrations, or diagrams Gen.

  • Page 40: Image Density (Contrast)

    Faxing ❒ You can have the machine return ❖ ❖ ❖ ❖ Manual Image Density to the original type default setting Use manual image density to set after every transmission, with image density yourself. [Scan End Reset] under Gen. Set- You can select one of seven image tings/Adjust.

  • Page 41: Mixing Scan Settings For A Multiple

    Scan Settings A A A A Select the type of image density. Combined Auto and Manual Image Density Auto Image Density A Make sure that [Auto Image Den- A Make sure that [Auto Image Den- sity] is selected. sity] is selected. Note ❒...

  • Page 42: When Placing Originals On The Exposure Glass

    Faxing B B B B Select the image density, resolu- When placing originals on the exposure tion, and original type before the glass next page is scanned. Note ❒ While the machine is beeping, you have about 60 seconds (10 seconds for Immediate Transmission) to se- lect density, resolution, and origi- nal type.

  • Page 43: Specifying A Destination

    Specifying a Destination Specifying a Destination A A A A You can specify the destination using Enter the fax number using the one of three methods. number keys. ❖ ❖ ❖ ❖ Fax number p.37 “Entering a Fax Number” ❖ ❖ ❖ ❖ E-mail address p.38 “Entering an E-mail Address”...

  • Page 44: Tone

    Faxing Note Using the { { { { Tone} } } } key with On Hook ❒ You cannot insert a pause before Dial the first digit of a fax number. If you press the { { { { Pause/Redial} } } } key at A A A A Press the { { { { On Hook Dial} } } } key.

  • Page 45: Using Destination Lists

    Specifying a Destination A A A A Reference Make sure that is displayed in the destination display column. “Entering Text”, General Set- tings Guide The destination is specified. Note ❒ If it is not displayed, press B B B B Note Press [Manual Input].
  • Page 46 Faxing C C C C Preparation Press the title key where the de- sired destination is progammed. In the destination list, program individual fax number, e-mail ad- For example, if you want to specify dress and/or groups of destina- “ N E W Y O R K O F F I C E ” p r o - tions.
  • Page 47 Specifying a Destination ❒ To cancel the selection, press Specifying a single destination the selected Quick Dial key again. You can also press the A Press the Quick Dial key pro- { { { { Clear / Stop} } } } key to cancel the grammed with the desired des- selection.

  • Page 48: Searching For A Destination

    Faxing Searching for a Destination C C C C Use this procedure to search through Press [Search by Dest. Name]. the destination lists for a particular destination. ❖ ❖ ❖ ❖ Search by Destination Name p . 4 2 “Se arch b y D e st in at i o n Name”...

  • Page 49: Search By Fax Number

    Searching for a Destination E E E E C C C C Select a destination. Press [Search by Fax No.]. Note Note ❒ If the desired destination does ❒ If [Search by Fax No.] appears not appear, use [U U U U ] or [T T T T ] to dimmed, press [Fax] on the right scroll through the list.

  • Page 50: Search By E-Mail Address

    Faxing B B B B Note Press , the magnifier icon. ❒ A warning appears if the search returns more than 100 items. Press [OK] to proceed to step E E E E Select a destination. C C C C Press [Search by E-mail].

  • Page 51: Specifying A Registration Number

    Searching for a Destination Note Specifying a Registration ❒ If you enter a wrong e-mail ad- Number dress, press [← ← ← ← ]/[→ → → → ] and [Back- space]/[Delete All], and then Use this procedure to select a destina- enter the e-mail address again.
  • Page 52 Faxing The corresponding destination ap- pears. Note ❒ The Title word key switches to that which the specified desti- nation is programmed in. ❒ If the “ Cannot find the spec- ” ified Registration No. message appears, the specified registration number is wrong. Press [Exit], check the registra- tion number again, and then fol- low the procedure from step...

  • Page 53: Reception

    Reception Reception There are two ways you can set up Note your machine to handle incoming ❒ You can only use this function af- calls: ter programming a Quick Opera- • Manual Reception (the optional tion key as the reception mode handset or an external telephone switch with [Quick Operation Key (1 required)

  • Page 54: Receiving A Fax In Manual Reception Mode

    Faxing Receiving a Fax in Manual Reception Mode A A A A When the machine rings, pick up the optional handset or the hand- set of the external telephone. B B B B If you hear beeps, press the { { { { Start} } } } key or the { { { { Start Manual RX} } } } key.

  • Page 55: Using Internet Fax Functions

    3. Using Internet Fax Functions Internet Fax Functions The optional printer/scanner unit is required. This machine converts scanned document images to e-mail format and transmits the data over the Internet. The e-mail sent by this machine can be received by another Internet Fax ma- chine.

  • Page 56: Internet Fax Precautions

    Using Internet Fax Functions Internet Fax Precautions • Internet Fax communicates with a server over a LAN. It cannot communicate directly with other parties. • If a transmission is not successful, this machine usually receives an e-mail er- ror notification. See p.195 “Server-Generated Error E-mail”, Facsimile Refer- ence <Advanced Features>...

  • Page 57: Functions Not Supported By E-Mail Reception

    Internet Fax Functions Functions Not Supported by E-mail Reception The following functions are supported with standard fax reception, but not with Internet Faxing. • Confidential Reception • Memory Lock Reception • Polling Reception • SUB Code Reception • Authorized Reception •...

  • Page 58: Sending Internet Fax Documents

    Using Internet Fax Functions Sending Internet Fax Documents ❖ ❖ ❖ ❖ Enter Text Preparation Allows you to enter the text to be You need to make System Settings transmitted. beforehand. See “Setting to the Machine Up a Network”, Network Note Guide.
  • Page 59 Sending Internet Fax Documents A A A A Limitation When you set an e-mail option, ❒ When available memory is low, press [Sub TX Mode]. you may not be able to send Inter- net Fax documents. Note ❒ Because this machine sends docu- ments as e-mail messages with an attached TIFF-F image, viewer ap- plications are required in order to...
  • Page 60 Using Internet Fax Functions B Select the subject from the dis- D After entering the subject, played list. press [OK]. The selected subject appears in Reference the manual input column. “Entering Text”, General Set- tings Guide Entered characters appear in the manual input column.
  • Page 61 Sending Internet Fax Documents To enter the text To set BCC transmission A Press [Change] for Enter Text. A Select [Yes] or [No] for BCC TX. B Select a text, and then press C C C C Press [OK]. [OK]. D D D D Press [OK].
  • Page 62 Using Internet Fax Functions ❒ Note that you cannot place pag- G G G G Specify the e-mail address. es on the exposure glass after you have started using the ADF. ❒ The original can be placed ei- ther in the ADF or on the expo- sure glass, until the { { { { Start} } } } key is pressed.
  • Page 63 Sending Internet Fax Documents I I I I Specify the next destination. - About the E-mail Subject If no subject is specified for “Enter Subject / Text” under “E-mail Op- tions”, a subject is automatically in- se rt e d . T he su bj e c t is d if fe re nt according to the settings of Stamp Sender Name.

  • Page 64: Confirming Reception

    Using Internet Fax Functions ❒ Information regarding the last 200 messages is recorded, but only the - E-mail Text last 50 communications appear in Journal. If you do not receive a re- When Internet Fax e-mail is sent to ception notice message for one of computer, the following information the last 50 communications from is always inserted in the e-mail text.

  • Page 65: Canceling A Transmission Of An Internet Fax

    Canceling a Transmission of an Internet Fax Canceling a Transmission of an Internet When fax and Internet Fax destina- While the Original Is Being tions are specified simultaneously, you can cancel sending using the Scanned In same method. However, you cannot cancel the transmission of an Internet Use this procedure to cancel a trans- Fax document being sent.

  • Page 66: After The Original Has Been Scanned In

    Using Internet Fax Functions C C C C Press [Stop Transmission]. After the Original Has Been Scanned In Note ❒ You can not cancel the transmis- sion of an Internet Fax being sent. A A A A Press [Change/Stop TX File]. Note ❒...

  • Page 67: Receiving Internet Fax Documents

    Receiving Internet Fax Documents Receiving Internet Fax Documents You can receive e-mail documents by Auto E-mail Reception Internet Fax. There are two methods of receiving e- When this function is turned on, this mail: Auto E-mail Reception and machine periodically checks the e- Manual E-mail Reception.

  • Page 68: Received Images

    Using Internet Fax Functions B B B B Check the message, and then press [Exit]. The standby display appears. Received Images Here is an example of an Internet Fax message sent from this machine and re- ceived on a computer using Outlook e-mail software. The received image varies according to e-mail software.
  • Page 69 Receiving Internet Fax Documents Date The date and time of e-mail transmission The e-mail address of the recipient Subject Shows the subject specified in "E-mail Options" at the time of transmission. If no subject is specified, one is automatically assigned in the format shown in 1 above. From "Own Fax Number"...
  • Page 70 Using Internet Fax Functions...

  • Page 71: Programming

    4. Programming Initial Settings and Adjustments You can send information to the other Note party when transmitting or receiving ❒ You can program up to 32 char- a fax message. This information is acters in the Fax Header. shown on the display of the other ma- ❒...

  • Page 72: Programming

    Programming ❖ ❖ ❖ ❖ Own Name Programming The Own Name is sent to the other party when you send or receive a A A A A fax using a G3 line. This name Press the { { { { User Tools/Counter} } } } key. should include your name.
  • Page 73 Initial Settings and Adjustments D D D D Program the name and facsimile Programming an Own Name number. A Press [Own Name]. Programming a Fax Header A Press [First Name] or [Second Name]. B Press [Own Name]. B Enter a fax header including your Own Name and Fax Num- ber, and then press [OK].

  • Page 74: Editing

    Programming E E E E Press [Exit]. Programming an Own Fax F F F F Number Press the { { { { User Tools/Counter} } } } key. A Press [Own Fax Number]. The standby display appears. Editing Note ❒ The following procedure explains how to edit Own Name, as an ex- ample of editing.

  • Page 75: Deleting

    Initial Settings and Adjustments D D D D G G G G Press [Fax Header], [Own Name], or Press [OK]. [Own Fax Number] for editing. H H H H Press [Exit]. E E E E Press the item you want to edit. I I I I Press the { { { { User Tools/Counter} } } } key.
  • Page 76 Programming B B B B F F F F Press [Facsimile Features]. Press [Backspace] or [Delete All], and then press [OK]. C C C C Press [Program Fax Information]. Note ❒ Press [Clear] or the { { { { Clear/Stop} } } } key if you want to edit Own Fax Number.

  • Page 77: Programming Fax Number And E-Mail Addresses

    Programming Fax Number and E-mail Addresses Programming Fax Number and E-mail Addresses You can program fax destinations using Address Book Management in the Key Operator Tools menu under System Settings. You can also register the programmed fax numbers and e-mail addresses in a Group.
  • Page 78 Programming...

  • Page 79: Troubleshooting

    5. Troubleshooting Adjusting the Volume B B B B You can change the volume of the fol- Press [Facsimile Features]. lowing sounds that the machine makes. ❖ ❖ ❖ ❖ On Hook Mode Heard when the { { { { On Hook Dial} } } } key is pressed.

  • Page 80: When The { { { { Facsimile} } } } Key Is Lit In Red

    Troubleshooting When the { { { { Facsimile} } } } Key Is Lit in Red If this key is lit, press the key to enter the facsimile mode. Then, refer to the table below and take the appropriate action. ZLBS010N Problem Solutions...

  • Page 81: When Toner Runs Out

    When Toner Runs Out When Toner Runs Out B B B B When the machine has run out of ton- Press [Exit], and then perform er, the symbol appears on the display. transmission operation. Note that even if there is no toner left, The error message disappears.

  • Page 82: Error Messages And Their Meanings

    Troubleshooting Error Messages and Their Meanings If there is an error, one of the following messages may appear on the display. If other message appears, follow the message. Message Causes and solutions Original jammed during Memory Transmis- Put original back, check it and sion.
  • Page 83 Error Messages and Their Meanings Message Causes and solutions Wait with the main power switch on. The ma- Updating the destination list. chine will enter standby mode after it exits Please wait. Selected destina- from RDS mode. tions or function settings have been cleared.
  • Page 84 Troubleshooting Message Causes and solutions No POP3/IMAP4 server's address is pro- Check whether there are any grammed. network problems. • Check the host name or IP address of the [15-01] POP3/IMAP4 server is correctly pro- grammed using the Web browser. See the Web browser's Help.
  • Page 85 Error Messages and Their Meanings Message Causes and solutions Cannot log on to the POP3/IMAP4 server. Check whether there are any network problems. • Check the user name and password of the e-mail account are correctly programmed [15-12] from File Transfer under System Settings. See “Settings You Can Change with User Tools –...

  • Page 86: Solving Problems

    Troubleshooting Solving Problems This table lists some common problems and their solutions. Problem Causes and solutions Reference Image background appears Adjust scan density. p.34 “Image Density (Con- dirty when received at the trast)” other end. Images from the back page appears. Printed or sent image contains The ADF or exposure glass is “Maintaining Your Machine”,...
  • Page 87 Solving Problems Problem Causes and solutions Reference Transmission is possible, The optional terminal adaptor though receiving is impossi- setting is incorrect. Check the ble. setting. Receiving is possible, though The optional terminal adaptor transmission is impossible. setting is incorrect. Check the setting.

  • Page 88: When Things Don't Go As Expected

    Troubleshooting When Things Don't Go as Expected I Want... Operation Reference to cancel a Memory Transmis- If the original is being p.26 “Canceling a Memory sion. scanned, press [Stop Scanning] Transmission” or the { { { { Clear/Stop} } } } key. If the original is being sent or p.26 “Canceling a Memory if it is in standby, press...

  • Page 89: Index

    INDEX Adjusting The Volume , 73 Facsimile key , 6 , 74 At Dialing , 73 Fax Header , 65 At Printing , 73 Deleting , 69 At Reception , 73 Editing , 68 At Transmission , 73 Programming , 66 On Hook Mode , 73 Faxing , 13 Authorized Reception , 51...
  • Page 90 On Hook Dial , 50 Scan Settings , 32 On Hook Dial key , 6 Stamp Sender Name , 57 On indicator , 6 Standard , 32 Operation switch , 6 Start key , 7 Original Type , 32 , 33 Start Manual RX key , 6 Own Fax Number , 66 SUB Code Reception , 51...
  • Page 91 ❖ ❖ ❖ ❖ FCC Requirements 1. This equipment complies with Part 68 of the FCC rules. On the cover of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the tele- phone company.
  • Page 92 Printed in Japan EN USA B576-8607...
