Summary of Contents for Linn PRETEK

  • Page 2 The PRETEK is ideally suited for use with the Linn POWERTEK or other high quality power amplifiers. The PRETEK has six inputs, including a low noise phono input, which can be used with either moving magnet or moving coil cartridges.

  • Page 3: Installation

    CONTENTS & INSTALLATION PRETEK amplifier Owners manual and registration card Mains lead Spare fuse Unpack the amplifier, retain the packing for future use. Ensure that the amplifier INSTALLATION is grounded and that adequate ventilation is provided. Position the preamplifier far enough away from the turntable to avoid hum.

  • Page 4: Input Connections

    All the inputs on the Pretek are RCA phono. Good quality leads should be used when connecting signal sources to the preamplifier. Your dealers will be able to supply all the necessary interconnect leads.
  • Page 5 OPERATIONS & CONTROLS THE LINN PERFORMANCE ADVANTAGE. In many cases it is possible to use the Linn PRETEK preamplifier with multiple power amplifiers to increase significantly the performance of the system. For more information on the performance advantages of passive bi-amplification or tri-amplification, and AKTIV multi-amplifier systems, consult your local authorised Linn retailer.

  • Page 6: Volume And Balance

    Check the fuse and replace if necessary with the spare one provided. If another fuse blows then there is possibly a fault with the PRETEK and the complete amplifier should be returned to your Linn dealer.

  • Page 7: Maintenance

    A fuse is fitted to the power input socket on the rear of the PRETEK. Please note that the fuse holder also contains one spare fuse. The Linn PRETEK preamplifier is designed for a long life and any servicing should be carried out by an authorised dealer.

  • Page 8: Guarantee And Service

    Refer all enquiries to authorised dealers only. Unauthorised servicing or dismantling of the product invalidates the manufacturer's warranty. If you are in any doubt please contact your nearest Linn dealer. For information on your nearest Linn dealer contact the Linn factory in Scotland or your national distributor.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS For 500mV output INPUTS Moving magnet and moving coil cartridges (switch selected) MM; sensitivity - 2.1mV load – 47Kohms//80pF MC: sensitivity – 210uV load – 100ohms//4.7nF All auxiliary/tape inputs – l90mV/10Kohms Maximum 14V peak input OUTPUTS Tape outputs = auxiliary input level (unity gain) 600 ohms output impedance MAINS SUPPLY/FUSE T3.15A, all voltages...
