OPERATOR'S MANUAL
Portable Power 950
Model No.
28.71987
Read and follow all Safety
Rules and Operating Instructions
before Every Use of this Product.
SAvE THESE INSTRUCTIONS.
Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
00-99-001001/0710

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Portable Power 950 and is the answer not in the manual?

Questions and answers

Related Manuals for DieHard Portable Power 950

Summary of Contents for DieHard Portable Power 950

  • Page 1 OPERATOR’S MANUAL Portable Power 950 Model No. 28.71987 Read and follow all Safety Rules and Operating Instructions before Every Use of this Product. SAvE THESE INSTRUCTIONS. Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A. 00-99-001001/0710...

  • Page 3: Table Of Contents

    This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Sears Brands Management Corporation, Hoffman Estates, IL 60179 fOR CUSTOMER ASSISTANCE OR REPLACEMENT PARTS, CALL TOLL-fREE fROM 7 AM TO 5 PM CT...
  • Page 4 IMPORTANT: READ AND SAvE THIS SAfETY AND INSTRUCTION MANUAL. SAvE THESE INSTRUCTIONS – Charge the jump starter internal battery immediately after purchase, after every use and every 30 days. This manual will show you how to use your jump starter safely and effectively. Please read, understand and follow these instructions and precautions carefully, as this manual contains important safety and operating instructions.

  • Page 5: Important Safety Instructions

    IMPORTANT SAfETY INSTRUCTIONS - SAvE THESE INSTRUCTIONS - This manual contains important safety and operating instructions RISK Of ELECTRIC SHOCK OR fIRE. Read the entire manual before using this product. Failure to do so could result in serious injury or death. Keep out of reach of children.

  • Page 6: Personal Precautions

    PERSONAL PRECAUTIONS RISK Of EXPLOSIvE gASES. A SPARK NEAR THE BATTERY MAY CAUSE A BATTERY EXPLOSION. TO REDUCE THE RISK Of A SPARK NEAR THE BATTERY: Working in the vicinity of a lead-acid battery is dangerous. Batteries generate explosive gases during normal battery operation. For this reason, it is of utmost importance that you follow the instructions each time you use the jump starter.

  • Page 7: Follow These Steps When Connecting To A Battery

    fOLLOW THESE STEPS WHEN CONNECTINg TO A BATTERY A SPARK NEAR THE BATTERY MAY CAUSE A BATTERY EXPLOSION. TO REDUCE THE RISK Of A SPARK NEAR THE BATTERY: NEgATIvE gROUNDED SYSTEM Attach the output cables to the battery and chassis as indicated below. Never allow the output clips to touch each other.

  • Page 8: Grounding And Ac Power Cord Connections

    gROUNDINg AND AC POWER CORD CONNECTIONS RISK Of ELECTRIC SHOCK OR fIRE. The jump starter charger is for use on a nominal 120-volt circuit. The plug must be plugged into an outlet that is properly installed and grounded in accordance with all local codes and ordinances.

  • Page 9: Charging The Internal Battery Of The Jump Starter

    CHARgINg THE INTERNAL BATTERY Of THE JUMP STARTER IMPORTANT: CHARgE IMMEDIATELY AfTER PURCHASE, AfTER EACH USE AND EvERY 30 DAYS TO KEEP THE JUMP STARTER INTERNAL BATTERY fULLY CHARgED. To check the internal battery’s charge status, toggle the Light/display switch to the dISPLAY position.
  • Page 10 Risk of Explosion. If you have connected the clips backwards, an audio alarm will sound. dO NOT turn the On/Off switch to the ON position. This could cause serious damage to the jump starter or the vehicle. Reverse the connections and the audio alarm will stop. Crank the engine.

  • Page 11: Maintenance Instructions

    Using the USB Port The USB port provides up to 500mA at 5v dC. NOTE: When using the USB port, the clips on the jump starter are live and will produce arcing or sparking if they come in contact with each other. To prevent accidental arcing, always keep the clips on the storage holders when not using it to jump start a vehicle.

  • Page 12: Troubleshooting

    10.5 IMPORTANT: • CHARgE IMMEDIATELY AfTER PURCHASE • KEEP fULLY CHARgED Charge the jump starter internal battery immediately after purchase, after every use and every 30 days. All batteries are affected by temperature. The ideal storage temperature is at 70 degrees Fahrenheit. The internal battery will gradually self-discharge (lose power) over time, especially in warm environments.

  • Page 13: Specifications

    SPECIfICATIONS Internal Battery Type dieHard Maintenance-free AgM Lead-acid Nominal voltage 12v dC Capacity 18 Ah DC Power Outlet (Max. Continuous Load) 15A (both outlets combined) Built-in Light Bulb (Replaceable) Two, 5w/12v dC (Base type BA9S) Jumper Cables 4-gauge AWg, 24 Inches Dimensions (H x W x D) 12 H x 11 x 10.5 Inches Product Weight...
