Summary of Contents for Laney IronHeart IRT15H

  • Page 2 WARNING: When using electrical products, basic cautions should always be followed, including the following: 1. Read these instructions. 2. Keep these instructions safe. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7.
  • Page 3 ATTENTION: L’utilisation de tout appareil électrique doit être soumise aux precautions d’usage incluant: 1. Lire ces instructions 2. Gardez ce manuel pour de futures références. 3. Prétez attention aux messages de précautions de ce manuel. 4. Suivez ces instructions. 5. N’utilisez pas cette unité proche de plans d’eau. 6.
  • Page 4 ACHTUNG: Beim Einsatz von Elektrogeräten müssen u.a. grundlegende Vorsichtsmaßnahmen befolgt werden: 1. Lesen Sie sich diese Anweisungen durch. 2. Bewahren Sie diese Anweisungen auf. 3. Beachten Sie alle Warnungen. 4. Befolgen Sie alle Anweisungen. 5. Setzen Sie dieses Gerät nicht in der Nähe von Wasser ein. 6.
  • Page 5 CUIDADO: Cuando use productos electrónicos, debe tomar precauciones básicas, incluyendo las siguientes: 1. Lea estas instrucciones. 2. Guarde estas instrucciones. 3. Haga caso de todos los consejos. 4. Siga todas las instrucciones. 5. No usar este aparato cerca del agua. 6.

  • Page 7: Specifications

    EQ - Passive Bass, Middle & Treble Volume Dynamics & Tone Master controls Emulated DI & Phones 3.5mm Stereo CD/MP3 Line input Laney-designed digital reverb Insert-type FX Loop (0dBu, -10dBu, Bypass) Illuminated cover/underside 8 Ohms, 16 Ohms Loudspeaker Outputs 1M Ohm/47pF...
  • Page 9 UK - where the sound of metal guitar was born, comes the IRONHEART. With molten metal flowing through its circuits, IRONHEART continues the legacy passed on by previous Laney amps such as KLIPP and AOR, and hits you hard between the eyes like a power hammer from hell.

  • Page 10: Front Panel Controls

    FRONT PANEL CONTROLS 15W INPUT: 1/4" mono jack socket. Connect your guitar here to get full volume output. Use only high quality guitar cable. <1W INPUT: 1/4" mono jack socket. Connecting your guitar here switches the output stage to under 1W. This allows you to drive the output stage hard at bedroom volume levels.
  • Page 11 Midway (0) is a good starting point. Both the Tone and Dynamics controls depend greatly on the speaker cabinet connected to the amplifier. REVERB: Controls the level of the built in Laney-designed digital reverb. Always switch off...

  • Page 12: Rear Panel Controls

    REAR PANEL CONTROLS LZB1 2 3 4 Spare fuse located in the fuse drawer. MAINS INLET SOCKET: Make sure the voltage indicated on the rear panel is correct for your country! MAINS FUSE: This drawer contains the main safety fuse for the unit. The fuse protects the amplifier from damage in the event of fault by disconnecting the mains power supply.
  • Page 13 FOOTSWITCH SOCKET: Use a stereo tip-switched footswitch (such as the Laney FS2) to enable the Pre-Boost circuit (tip) and reverb (ring). Note: The Pre-Boost switch on the front panel must be set to On in order to use the footswitch.

  • Page 14: Quick Start Settings

    QUICK START SETTINGS CLEAN CRUNCH LEAD METAL...

  • Page 15: User Settings

    USER SETTINGS...
  • Page 16 TUBE AMP TIPS Tube amplifiers generally sound much warmer/sweeter than solid state transistor amplifiers but they also need a little more respect due to the fragile glass tubes. The IRT15H head uses three 12AX7 preamp tubes, and 2 EL84 output tubes which should give you years of trouble free service, however like all tube amps;...

  • Page 17: Block Diagram

    BLOCK DIAGRAM FX SEND FX RETURN INPUT <1W DRIVE VOLUME Pre-Boost DI OUT BYPASS 0dBu REVERB MUTE -10dBu PHONES FOOTSWITCH CD/MP3 IN (3.5mm) 16Ohms 8Ohms DYNAMICS TONE POWER EXTERNAL LOUDSPEAKER 8-16 OHMS...

  • Page 18: Sample Setups

    SAMPLE SETUPS FX Unit LZB1 2 3 4 RECORD OUT IRT212...
  • Page 19 NOTES...
