Specifications

VX-1000ci Projector:
Projector Type:
Native Resolution:
Aspect Ratio:
Video Standards:
DTV Compatibility:
Scan Frequency:
Picture Size:
Throw Distance:
Horizontal/Vertical Offset: Horizontal: 0, Vertical +/- 50%
Light Output:
Contrast Ratio:
Lamp:
Lamp Life:
Inputs:
12V Output:
Power Requirements:
Operating Environment:

Dimensions:

Regulatory Approvals:
Limited Warranty:
Digital Light Processing™ (DLP)™, Single HD2 DMD Chip
1280 x 720 (Designed for 16:9 screens only)
Determined by supplied processor
NTSC, PAL
480p, 720p, 1080i
Horizontal: 15-81 KHz, Vertical: 43-100 Hz
Recommended Width: 72-96 in.
Maximum Width: 200 in. wide (16:9 screen)
Minimum: Zoom 1.85 x screen width
Maximum: Zoom 2.40 x screen width
1500 ANSI Lumens
CSMS Specifications:
Home Theater Calibration: 418-600 ANSI Lumens
Foot-Lamberts: 15.6-22.4
(Variable depending on RVR calibration)
2500:1 to 3000:1
CSMS Contrast Ratio: 177:1 to 178:1
(Variable depending on RVR calibration)
250W NSH
o
2000 hours @ 6500 Kelvin
Projector: (1) RGB HV, (1) DVI w/HDCP, (1) RS-232
Controller: (1) Composite, (1) S-Video, (1) Component, and
(1) Pass-through
See Controller for specifications
115V AC, 50/60 Hz 100-240V AC, 375W
40°- 95° F, (5°- 35° C), 0%-90% Humidity (non-condensing)
Width: 20 7/8 in. (530.20 mm)
Depth: 21 5/8 in. (550.20 mm)
Height: 6 1/2 in. (165.10 mm), with feet 8 1/4 in. (209.50 mm)
Weight: 50 lbs. (22.7 kg), (includes lens)
Complies with FCC Class B, CE, C-Tick
Projector: (2) Two year parts and labor from the date of delivery to the
end user
Lamp Warranty: 1000 hours or (6) six months, which ever comes first.
