2.4 RS232 Console Port Wiring

Pin
1
Internal Connection
2
Transmit Data
3
Receive Data
4
Internal Connection
5
6
Internal Connection
7
Internal Connection
8
Internal Connection
9
No Connection
©
2007 RuggedCom Inc. All rights reserved
Signal
Ground
13
Rev100
