JUKI DLU-5494N-7/IP-100C Installation Manual

Sewing machine
Hide thumbs Also See for DLU-5494N-7/IP-100C:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Handbook
ENGLISH
INSTALLATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for JUKI DLU-5494N-7/IP-100C

Summary of Contents for JUKI DLU-5494N-7/IP-100C

  • Page 1 ENGLISH INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    CONTENTS 1. CHECK AT THE BEGINNING ..............1 (1) Control box to be used..................... 1 (2) List of parts to be used .................... 1 2. SETUP OF THE HARDWEAR ..............1 (1) Attaching the circuit board ..................1 3. SETUP OF THE SOFTWARE ..............3 (1) Checking procedure of the software version............

  • Page 3: Check At The Beginning

    Fig. A is after "02". If the number is before it, the control box cannot be used. (2) List of parts to be used On the occasion of using DLU-5494N-7/IP-100C, check that the products (parts) below are on hand. 1. DLU-5494N-7 machine head 2. IP-100C panel 3.
  • Page 4 3. Insert EPF p.c.b. A (asm.) 1 to connector CN47 3 of the main unit as illustrated. Cau tion Do not forcibly press the circuit board. 4. Securely fix EPF p.c.b. A (asm.) 1 to the control box main unit using three screws 4 supplied with the unit as accessories.

  • Page 5: Setup Of The Software

    3. SETUP OF THE SOFTWARE There are cases where the software in the state of delivery may be unadaptable. Perform checking and updating of the software following the procedure below. (1) Checking procedure of the software version Turn ON the power, and press switch 1 for three seconds. Normal screen <Information switch>...

  • Page 6: Rewriting Procedure Of The Software By Means Of Ip-100

    (2) Rewriting procedure of the software by means of IP-100 From here, the rewriting procedure of the various kinds of software by utilizing IP-100 is explained. Start the work in the state that the smart media is inserted into IP-100. Cau tion When the smart media is not inserted, IP-100 does not work properly.

  • Page 7: Rewriting Procedure Of The Software Of Ip-100

    Data classification selection pop-up The common procedure is up to here. Then read the description below following the object to be rewritten. Rewriting the software of IP-100 : refer to "3. (2) 2) Rewriting procedure of the software of IP-100". Rewriting of the software of main shaft : refer to "3.

  • Page 8: Rewriting Procedure Of The Software Of Main Shaft

    Program selection screen IP-100 When the screen has changed to the aforementioned program selection screen, press switch 1 and repeat the selection operation until the programs of "IP-100-SC" and "01-02-0100" are selected. When the programs are displayed from the beginning, it is not necessary to perform the selection operation. When the preparation is ready, press switch 2 to start writing.
  • Page 9 Press switch 1 in the data classification selection pop-up to select the rewriting of software of main shaft. Then press switch 2 to execute reading. During reading data screen State that the program is read from the smart media. Do not perform the panel operation. Program selection screen Main shaft When the screen has changed to the aforementioned program selection screen, press switch 1 and repeat the selection operation until the programs of "SC-910A"...
