Innovaphone IP305 Datasheet

Housing

Size: 210 x 134 x 32 mm
1 HE for 19" systems
Weight: 660 g

Interfaces

2 x ISDN BRI: TE and NT mode for trunk
interface
2 x Ethernet: RJ 45 interface 10/100-BASE-TX
(auto negotiation), Power over Ethernet
(802.3af, Class 2)
Slot for Compact Flash Cards Type I

Hardware

Power supply:
Power over Ethernet (802.3af, Class 2)
or
external power supply
Power consumption: see wiki-article
„HowTo:Power Consumption"
Digital Signal Processor (DSP)
for codecs up to four voice channels
16 MB SDRAM, 8 MB Flash
Operation temperature: 0 °C to +45 °C,
Humidity: 10% to 90%
(not condensed)
Storage temperature: -10 °C to +70 °C

innovaphone PBX

Platform for up to 50 registrations
Order number: 01-00305-001
Tel +49 7031 7 30 09-0 | Fax +49 70 31 7 30 09-99 | info@innovaphone.com | www.innovaphone.com
Errors and omissions excepted. All information, technical specifications and delivery times may be subject to change.
Original: ds_IP305_en, issue: 07/2013, Copyright © 2000-2013 innovaphone® AG
innovaphone® AG | Böblinger Straße 76 | 71065 Sindelfingen
innovaphone IP305
V o I P g a t e w a y f o r t w o I S D N B R I i n t e r f a c e s
a n d p l a t f o r m f o r i n n o v a p h o n e P B X

VoIP protocols

H.323 version 5
SIP version 2, conform RFC 3261
SIP over UDP, TCP, TLS, SIPS
RTP, SRTP, RTCP
T.38 (Fax)

Voice Codecs

G.711 A-law / µ-law,
G.729AB,
VAD, CNG,
Dynamic Jitter Buffering
Echo Compensation: G.168
Network
• PPPoE, manual or automatic connection
after boot
• PPTP Tunneling up to 32 tunnels
simultaneously, encoding via MPPE
• NAT, H.323-NAT
• RSTP, IEEE 802.1x
VLAN-ID (DHCP and LLDP/MED support)
• NTP support
ISDN
• Routing VOIP-ISDN, ISDN-ISDN, VOIP-VOIP
• Automatic dial tone European and US
Standard
• ENUM for H.323 and SIP protocols
• Protokolle EDSS1, QSIG
• Plays recorded messages deposed on CF
card or on a web server

Administration

Password protected administration via web-
browser, Kerberos server
Log and trace files, Display of interface and
connection status, Ping – connection test for
Internet Protocol, Sending SNMP Traps
Save and reload config files, Boot code and
firmware update via HTML upload, Automatic
update via update server
Data sheet
