Ibanez IBZ10A Parts List

ITEM NUMBER

3200186 AA
3200002 AA
3200188 AA
3200189 AA
3200190 AA
3200191 AA
3200004 AA
3200003 AA
3200194 AA
3200009 AA
3200010 AA
3200011 AA
3200198 AA
3200199 AA
3200200 AA
3200017 AA
3200119 AA
3200013 AA
3200014 AA
3200015 AA
3200055 AA
3200123 AA
3200025 AA
3200026 AA
3200027 AA
3200211 AA
3200028 AA
3200029 AA
3200031 AA
3200033 AA
3200216 AA
3200217 AA
3200218 AA
3200219 AA
3200220 AA
3200221 AA
3200085 AA
3200223 AA
3200224 AA
3200089 AA
3200226 AA
3200227 AA
3200093 AA
3200094 AA
3200230 AA
3200096 AA
3200097 AA
3200098 AA
3200099 AA
3200100 AA
3200236 AA
3200102 AA
3200103 AA
3200104 AA
3200240 AA
3200106 AA
3200107 AA
3200108 AA
3200109 AA
IBZ10A PARTS LIST
Description
01 POWER IC TDA2040A
01 OP AMP IC NJM 4558D
01 IC LM358
01 IC MN3207
01 IC MN3102
01 IC KIA78LS05 BP
01 TRANSISTOR KTC3198GR
01 TRANSISTOR KTC1027-Y
01 TRANSISTOR KTA1023-Y
01 RECTIFIER DIODE 1N4004
01 SWITCHING DIODE 1N4148
01 ZENER DIODE 15V/0.5W(IN965B) D13,14
01 LED KLR124
01 VOLUME POT VS16P1100C15B5K
01 VOLUME POT VS16P1100C15B10K VR1
01 VOLUME POT VS16P1100C15A50K VR5
01 VOLUME POT VS16P1100 A100K
01 PHONE JACK W201M
01 PHONE JACK W201S
01 PUSH SWITCH JPS2251
01 POWER SWITCH JRS-1102A
01 C.F. RESISTOR 1 OHM 1/4W
01 C.F. RESISTOR 220 OHM 1/4W
01 C.F. RESISTOR 1 KOHM 1/4W
01 C.F. RESISTOR 2.2 KOHM 1/4W
01 C.F. RESISTOR 2.4 KOHM 1/4W
01 C.F. RESISTOR 2.7 KOHM 1/4W
01 C.F. RESISTOR 3.3 KOHM 1/4W
01 C.F. RESISTOR 4.7 KOHM 1/4W
01 C.F. RESISTOR 10 KOHM 1/4W
01 C.F. RESISTOR 12 KOHM 1/4W
01 CABINET ASS'Y PB 15T IBZ10A
01 MAIN CHASSIS EGI1.0T
01 FRONT PANEL PVC0.5T
01 CAUTION LABEL IBZ10A
01 CORNER IBZ10A
01 FOOT ASS'Y TB25
01 HANDLE ASS'Y SW25DX
01 CONTROL KNOB LIGHT BROWN
01 HEAT SINK AL 2.5T
01 LOGO (SPAGHETTI)
01 INSTRUCTION MANUAL IBZ10A
01 STAR WASHER DIA4 CHASSIS GND
01 GND LABEL
01 SPEAKER LABEL
01 INNER CARTON DW1 IBZ10
01 INNER CARTON DW1 IBZ3
01 OUT CARTON DW1 IBZ10
01 OUT CARTON DW1 IBZ3
01 PAD DW1
01 SCREW1 TAPPING DIA4X10L,BH,BK
01 SCREW2 TAPPING DIA3X10 W/WASHER HEAT SINK+CHASSIS:2,PCB+HEAT SINK:2
01 SCREW3 MACHING M3X10L,BH
01 SCREW4 TAPPING DIA3.5X10,TH,BK
01 SCREW5 TIPPING1W DIA4X25,W/WASHER CHASSIS
01 SCREW6 MACHING M4X25,OV BK
01 SCREW7 TAPPING DIA2.6X10,OV,BK
01 SCREW8 TAPPING DIA3.5X30,TH,BK
01 SCREW9 TAPPING DIA3.5X25,TH,BK

REMARK

IC3
IC1,2
IC4
IC5
IC6
IC7
Q1,2,3
Q4
Q5
D1,2,9,10,11,12
D3,4,5,6,7,8
LED15
VR4
VR2,3
J1
J2
SW1
R14
R7
R13
R44,48
R31
R33,35
R25
R6,24,38,46,47
R11,21,22,32
R10
CHASSIS GND:1,TRANSFORMER:2
TR+HEAT SINK
CORNER
HANDLE
LOGO
BAFFLE
BACK COVER

Q'TY

1
2
1
1
1
1
3
1
1
6
6
2
1
1
1
1
2
1
1
1
1
1
1
1
2
1
2
1
5
4
1
1
1
1
1
8
4
1
5
1
1
1
1
1
1
1
1
1
1
2
3
4
2
16
4
2
2
4
5
