3. Remove the USB board (4) and cable.
Reverse this procedure to install the USB board.

Power connector cable

Description
Power connector cable
Before removing the power connector cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
●
Optical drive (see
●
Hard drive (see
●
Keyboard (see
●
Top cover (see
●
USB board (see
Battery on page 47), and then remove the following components:
Optical drive on page
Hard drive on page 51)
Keyboard on page 57)
Top cover on page 61)
USB board on page 74)
49)
Component replacement procedures
Spare part number
641394-001
75
