RACK MOUNT INSTALLATION, OCTEL OVERTURE 300

The Octel Overture 300 can be installed in a 19-inch rack. Figure 4-9 illustrates a rack-mount installation.
10 mounting screws
(supplied in Overture
Rack Mount Kit)
2 rack mounting brackets,
one each side (supplied in
Overture Rack Mount Kit)
8 mounting screws
(supplied by rack manufacturer)
Figure 4-9 Octel Overture 200/300 Cabinet Installed in 19-Inch Rack
Octel Overture 200/300 Serenade 3.0
OCTEL OVERTURE 300
2 support rails
(supplied by rack manufacturer)
PB60014–01
