Konica Minolta bizhub 42/36 Specifications

bizhub 42/36 General Specifications
Product Name bizhub 36/42
Type Desktop
Scan Resolution 600 x 600dpi
Print Resolution 4,800 equiv. x 600dpi (600 x 600dpi x 3 bit)
Memory Capacity 1.5GB
Original Type Sheets, Books (2-page spreads), Objects (up to 3kg)
Max. Original Size A4 or Legal (216mm x 356mm)
Output Size Paper Size Tray 2 / 3: A4, B5, A5
Bypass Tray: A4, B5, A5, B6, A6, Postcard (100mm x 148mm)
Width: 90mm – 297mm, Length: 140 – 356mm
Image Loss Max. 4.2mm or less for top edge, Max. 3.0mm or less for bottom edge,
Max. 3.0mm or less for right/left edges
Warm-Up Time 45 sec. or less (when main power on)
(23°C, at rated voltage) 35 sec. or less (when starting from Sleep Mode)
1
First Copy Time 8.7 sec. * , ADF 7.9 sec.
Continuous Copy Monoplex 42 cpm / 36 cpm (thick paper ½: 12.5 cpm)
Speed Duplex 42 cpm / 36 cpm
Copy Fixed Original Size 100.0% ± less than 0.5%
Magnification Scaling Up 115.4%, 122.4%, 129.4%, 141.4%, 154.5%, 163.1%, 200.0%
Scaling 50.0%, 60.7%, 64.7%, 70.7%, 78.5%, 81.6%, 86.6%
Down
Free Settings Hand-placed copies: 25% – x400%
ADF copies: 25% – x200%
Paper Capacity 2
Main Unit Tray: 500 sheets (80g/m ) x 2 tiers (universal size)
Note: Optional additional 2-tiered
Multi Bypass: 150 sheet, 80g/m 2
Paper Weight* 2 Main Unit: 60 – 90g/m 2 , Multi Bypass: 60 – 210g/m 2
1 – 999 sheets
Multiple Copy
Regular
Output Levels 250 sheets
Paper
Thick 10 sheets
Paper
OHP Film 1 sheet
Power Requirements AC100V 15A (50/60Hz)
Max. Power Consumption 1.5kW or less
Dimensions [W] x [D] x [H] 558mm x 632mm x 807mm (ADF included)
Max. Space Occupied 1,173mm x 753mm x 1,134mm
[W] x [D] x [H] (with the FS-529 Finisher and bypass tray pulled out)
Weight Approx. 63kg
*1: A4 crosswise, when scanned from platen glass, in magnification, or from main unit tray.
*2: Depending on print environment, print quality may be affected.
ADF Specifications (Standard)
Document Feeding Type Automatic Duplexing Document Feeder
Monoplex 2
Document Regular Paper (50 – 128g/m )
2
Types Duplex / Mixed Regular Paper (50 – 128g/m )
Document Monoplex / Duplex A4 or Legal (216mm x 356mm) [Max. 1,000mm in Fax Mode]
Size Mixed Mixed with legal size only
Document Stacking Capacity Monoplex/Duplex: Max. 50 sheets or less (80g/m 2 )
Document Exchange Speed 30 sheets (A4), 31 sheets (letter)
Power Requirements Shared with main unit
Printer Specifications (Standard)
Type Embedded
Print Speed Shared with main unit
Resolution 4,800 equiv. x 600dpi (600 x 600dpi x 3 bit)
Memory Capacity 1.5GB
PDL PostScript 3 compatible (3016), PCL6 (XL3.0), PCL5e/c,
PDF1.7/JPEG/TIFF/XPS1.0 Direct print
Internal PCL 80 European fonts
PS
Fonts 137 European Type1 fonts
Protocol TCP/IP, IPX/SPX (NDS compatible), SMB (NetBEUI), UDP, AppleTalk
Supported OS PCL Windows XP / XP x64 / Vista / Vista x64 / 7 / 7 x64 / Server2003 /
Server 2003 x64 / Server2008 / Server2008 x64 / Server 2008 R2
PS Windows XP / XP x64 / Vista / Vista x64 / 7 / 7 x64 / Server2003 /
Server 2003 x64 / Server2008 / Server2008 x64 / Server 2008 R2
Mac OS (10.2.8, 10.3.9, 10.4, 10.5, 10.6) [Includes Intel Macs]
XPS Windows Vista / Vista x64 / 7 / 7 x64 / Server2008 / Server2008 x64 /
Server 2008 R2
Interface Ethernet (1000Base-T/100Base-TX/10Base-T)
USB 2.0
http://www.bizhub42.com
For more detailed information,
please visit the bizhub Website at
Product appearance, configuration and/or specifications
are subject to change without notice.
KONICA MINOLTA, the KONICA MINOLTA logo and symbol mark,
and "The essentials of imaging" are registered trademarks or
Ecology & Environment
trademarks of KONICA MINOLTA HOLDINGS, INC.
bizhub, bizhub PRO, bizhub PRESS, Magicolor, PagePro,
KONICA MINOLTA products are designed with the environment in mind.
PageScope, Simitri, Simitri HD, Simitri HD+, Simitri with Biomass,
• Energy Star
Emperon, S.E.A.D., S.E.A.D.II, Printgroove and Konica Minolta
• RoHS Compliance
Optimised Print Services and their respective logos are registered
trademarks or trademarks of KONICA MINOLTA BUSINESS • WEEE Compliance
TECHNOLOGIES, INC.
All other brands and product names are registered trademarks or
trademarks of their respective companies or organisations.
Requirements for safe use
• Please read and follow the instruction manual to ensure safe operation.
• Only operate using appropriate power supply and voltage.
• Connecting the earth wire to an inappropriate place may cause explosion or electric shock. Please connect accordingly (Taiwan and the Philippines only).
Scanning Function Specifications (Standard)
Type Full-Colour Scanner
Scanning Size Max. A4 or Legal
Scanning Resolution 150/200/300/600dpi
Scanning Speed 30spm (A4, 300dpi), 31spm (letter, 300dpi)
Interface Ethernet (1000Base-T/100Base-TX/10Base-T)
Protocol TCP/IP (FTP, SMB, SMTP, WebDAV, WSD-Scan)
Output Format TIFF, PDF, Compact PDF, JPEG, XPS
Fax Specifications (Optional)
Communication ECM / Super G3
Compatible Lines Subscription phone line (PSTN), PBX
Sending Resolution
Standard: 200 x 100dpi (8dot/mm x 3.85line/mm )
Fine: 200 x 200dpi (8dot/mm x 7.7line/mm )
Super Fine: 400x400dpi (16dot/mm x 15.4line/mm)
Sending resolution depends on the capabilities of the recipient's fax device.
Sending Speed
2.4kbps – 33.6kpbs
Compression MH, MR, MMR, JBIG
Sending Paper Size Platen Glass: Max. A4, Legal
ADF: 215.9mm x 1,000mm
Recording Paper Size Max. A4, Legal
Documents exceeding 1,000mm cannot be received.
Following page division settings, recorded documents up to 1,000mm are
recorded.
Sending Speed 3 pages / sec.
Abbr. Dials 2,000 (max. number of recipient contacts)
400 (max. number of programme registrants)
Programme Dials
Group Registration 100 (max. number of group registrants)
Simultaneous Recipients Max. 500
Note: Times based on A4 document containing 700 characters (standard internal testing document), sent in standard
resolution in Super G3 (ITUT v.34 std., 336kbps or higher) using JBIG compression.
Internet Fax Function Specifications (Optional)
Protocol Internet Fax (simple mode9, TCP/IP, SMTP, POP3)
Sending Paper Size A4
Resolution Sending Standard: 200 x 100dpi
Fine: 200 x 200dpi
Receiving 200 x 100dpi, 204 x 98dpi (80 x 38.5dot/cm)
200 x 200dpi, 204 x 196dpi (80 x 377dot/cm)
200 x 300dpi
200 x 400dpi, 204 x 391dpi (80 x 154dot/cm)
400 x 100dpi, 408 x 391dpi (160 x 154dot/cm)
Data Format Monochrome TIFF
Registered Recipients Max. 2,000
Simultaneous Recipients Max. 500
Data Compression Formats Sending: TIFF-S (MH), Receiving: TIFF-S (MH), TIFF-F (MR/MMR)
System Configurations
WT-501 Working Table
Documents can be placed here
FS-529 Inner Finisher
temporarily. Also, this is where
Printed documents can be sorted the AU-201 Authentication Unit
and/or grouped during output, is placed.
and 2-point stapling is possible.
(MK-601 FS Installation Kit required)
PC-211 2-tiered Paper DK-511 Copy Desk
Feeding Cabinet
By using the copy desk, the main
The upper and lower tiers unit can be placed on the floor.
can store up to 1000 sheets.
• Eco-friendly Toners
• Production at ISO Certified Factories
From consulting, system design, to operations, Konica Minolta offers
total support to optimise your office output environment.
http://www.biz.konicaminolta.com/services/ops
9251-3200-01 Printed in Japan
