Konica Minolta bizhub 42 Specification & Installation Manual

Konica Minolta bizhub 42/36
Specification & Installation Guide
bizhub 42/36 Specifications
Type Monochrome Laser MFP
Document Holder Stationary (mirror scanning)
Types: Sheets, books (page spreads),
3-dimensional objects
Size: Maximum 8.5" x 14"
Photoconductor Organic Photoconductor
Luminous Source White inert gas fluorescent lamp
Copying System Laser electrostatic copy method
Developing System Dry-type dual-component HMT
developing method
Fusing System Roller fusing system
Resolution Scanning: Up to 600 dpi x 600 dpi
Copying/Printing: 4800 (equivalent) x 600
dpi
Paper Plain Paper: 60-90 gsm
Thick Paper 1: 91-150 gsm*
Thick Paper 2: 151-210 gsm*
Duplexing: 60-90 gsm
Laser-quality labels*, envelopes**,
letterhead, recycled paper
* Can only be fed through the bypass tray (up to 20 sheets)
** Can only be fed through the bypass tray (up to 10
envelopes)
Paper Tray Sizes Bypass Tray: 5.5" x 8.5" to 8.5" x 14"
Tray 2 & 3: 5.5" x 8.5" to 8.5" x 11"
Tray 4 & 5: (Option): 5.5" x 8.5" to 8.5" x 14"
Paper Tray Capacity Bypass Tray: 150 sheets
Tray 2 & 3: 500 sheets each
Tray 4 & 5: (Option): 500 sheets each
Paper Output 250 sheets (face down)
Capacity
Warm-up Time 45 seconds
Image Loss Width Position
Leading edge
Trailing edge
Right edge
Left edge
First Copy/Print bizhub 42
8.7 sec. or less
from platen
7.9 sec. or less
from ADF
Print/Copy Speed bizhub 42
42 ppm single-sided 36 ppm single-sided
42 ppm double-sided 36 ppm double-sided
Multiple Copies 1-999
Magnification Ratios Platen: Reduce/Enlarge: 25%–400%*
RADF: Reduce/Enlarge: 25%–200%*
*0.1% increments
Copy Print
0.165" 0.165"
0.165" 0.118"
0.165" 0.118"
0.165" 0.118"
bizhub 36
8.8 sec. or less
from platen
7.9 sec. or less
from ADF
bizhub 36
Power Requirements 120V/60Hz @ 15A(110V)
Power Consumption 1.5kW or less (max.)
Dimensions (WxDxH) 21.9" x 24.8" x 31.7"
Memory 1.5 GB RAM (320 GB HDD)
Weight Approx. 139 lbs.

Duty Cycle

bizhub 42/36: Up to 150,000 monthly
Maximum monthly copy/print volume supported under vendor
supplied service. Defines the upper end of the expected
customer volume for the device. Customers should consider
multiple machines if average approaches duty cycle on
a continual basis.

Basic Configuration

08/15/2012
1
