Resume Function

This washing machine provides resume function, which could save program operation status upon unexpected outage
or loosing plug during washing, when power is restored, this machine could work continuously according to the original
program after "Power" key is pressed.
Eccentric Protection
In the event that clothing is not uniformly distributed during dewatering, this machine will shake and scatter the clothing
again and dewater them until they are distributed evenly. If the clothing hasn't been distributed evenly within the specified
time, the machine won't begin dewatering in order to avoid sharply vibration, and meanwhile send "Unb" alarm. Now you
shall check whether there are any wound-up or tied-off clothing in it, and arrange them again, and then select "Separate
Dewatering" program to dewater them. When there is little clothing, the machine may not dewater or reach max rotation
speed due to eccentric protection, then some clothing could be added into the machine to do the dewatering; in addition,
it is normal that longer time is required when the washing machine distribute and shake and scatter clothing again.
Buzz Mute Function
Hold down "Tem." key and "Speed" key at the same time for 3 sec, buzzes (excluding alarm) for all programs could be
canceled with "bEEP oFF" displayed on the screen; hold down above keys for 3 sec again, buzzes for all programs
could be restored with "bEEP on" displayed on the screen.
Memory Program
(for the type with this program)
Select "Memory" program and set each washing parameter as necessary, which will be saved after washing program
finished. If the user wants to wash with the same setting, the "Memory" program could be directly selected (the program
doesn't save such functions as Powerful Cleaning, Appointment, High Water Level and Load Gear).
Air Washing
(for the type with drying function)
This function is applicable to get rid of bad smell from clothing. When the inner drum slowly rotates, the flowing hot air
could bring smell from clothing.
Please turn on the tap of washing machine and ensure the correct connection during air washing.
If some special smells due to heavy containment have not been removed completely, please wash it by water, or send
to a laundry for dry cleaning so as to reach the cleaning effect as required.
Manually Select Clothing Gear Function
When the washing machine with drying function is used to wash clothing, after the program is started, the machine will
automatically weigh the clothing in the drum. If you want to cancel this function, when " " is displayed on the display area
for remaining time, you could turn around the program selection knob to "AL-1", "AL-2", "AL-3", "AL-4" or "
which " " indicates automatic weighing. For manual selected gear, if there is much clothing in the drum, it is
recommended to select "AL-3" or "AL-4"; if there is less clothing in it, select "AL-1" or "AL-2".
If the present programs contain drying function, the gear of "AL-4" can't be selected by hand.
If only drying function of the present programs can be selected, and the display area for other function keys do not light,
the clothing gear can't be selected by hand.
Note: for the washing machine without drying function, please see the introductions to Load keys in "Instructions to
Control Panel and Program" on Page 11 for detail operation of manual selection of clothing gear.
Note:
For energy test program of the drying type, please select "Cotton + Washing 50min + Rinsing 3 times
+ Spinning 6min + 60°+ Max Speed + Powerful Cleaning ", and meanwhile select max load level "AL-4" by
hand.
For energy test program of the non-drying type, please select "Cotton + Washing 50min + Rinsing 3
times + Spinning 6min + 60°+ Max Speed + Powerful Cleaning ", and meanwhile select max load level "L-4"
by hand.
16
4. Name of Components (Accessories)
Top panel
Control panel
Washing powder
dispenser box
Side panel
Door handle
Door
Door glass
Drainage filter cover
", among
Adjustable foot (4 in total)
This picture is for reference only. Since our products are subject to futher modification and
expansion, the machine you purchased may have discrepancies with those in above picture in
the appearnce, color and functions.
Display screen
Power
Start/Pause
Knob
Door lock
Window gasket
Emergency gate for door lock
Handle of drawer
Drawer
