Generac Power Systems Stationary emergency generator Owner's Manual page 57

EXPLODED VIEW: EV ENCLOSURE C2
DRAWING #: 0H0004
ITEM PART#
(2)1 0G00450AL0R
(1)2 0C2454
(2)3 0F58490AL0R
4 087233
(1)5 0E3257
(2)6 0F58520AL0R
(2)7 0F98330AL0R
(2)8 0F58510AL0R
9 049813
(1)10 077992
(2)11 0F98350AL0R
12 0F2786
13 0F2785
14 0F3364
15 0F4880
16 0F5049
17 0F4487A
18 022473
19 022097
20 022127
21 0F3072
22 078115
23 0G5892
24 0G5892A
25 0F5048D
26 0E5968
27 0G5892D
28 0G5892C
29 0F4051C
30 0F3890B
31 0F4051B
32 0F3890
33 078115A
34 0G5892E
35 042568
36 0912970094
37 022447
38 0G5892B
39 0F8869D
40 0E5298L
41 066760
42 0H1208A
0H1208B
49 0H0412
50 0C8566
(1)ENCLOSURE NOTE: PANELS THAT FASTEN TO THE BASEFRAME (EXCEPT ITEM 1) AMUST BE SECURED USING I/N 2 & 5 (THREAD FORMING FASTENERS)
AND I/N 10 (LOCK NUT). LOCK NUT IS TO BE INSTALLED AFTER THREAD FORMING FASTENER HAS PENETRATED THROUGH EXTRUSIONS IN ENCLOSURE
PANELS. ALL PANEL TO PANEL CONNECTIONS TO INCLUDE AT LEAST ONE CONNECTION POINT USING I/N 5 (THREAD FORMING FASTENER).
(2) SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR)
MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM.
•
CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM FOR CORRECT MATERIAL
•
AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).
REVISION: J-1396-F
DATE: 1/23/12
QTY. DESCRIPTION
1 REAR WRAP C2 CPL
44 SCREW THF M6-1 X 16 N WA Z/JS
2 DOOR C2
2 RIVET POP .1875 X .450 SS
10 SCREW TH-FRM M6 W/CAP SHKPRF W
2 DISCHARGE DUCT LH & RH SIDE C2
2 FRONT CORNERS C2
1 DISCHARGE CENTER DUCT C2
2 NUT HEX M6 X 1.0 G8 YEL CHR
17 NUT HEX LOCK M6-1.0 SS NY INS
1 ROOF C2
2 SLITTER C4
1 SPLITTER LOWER C4
1 SPLITTER STINGER C2
2 SUPPORT SPLITTER LH C2
2 TAB PULL
1 ASSEMBLY COVER ACCESS
7 WASHER FLAT 1/4-M6 ZINC
5 WASHER LOCK M6-1/4
1 NUT HEX 1/4-20 STEEL
10 INSULATION RETAINMENT HANGER
26 WASHER SELF LOCKING DOME #4-40
2 INSULATION DOOR C2
1 INSULATION ROOF TOP
2 VISE-ACTION LATCH SLOTTED CIR
1 GASKET EXTRUDED TRIM (328" LG)
2 INSULATION SPLITTER
2 INSULATION SPLITTER
2 INSULATION DUCT
4 RETAINER INSULATION (820)
2 INSULATION DUCT SIDES
4 RETAINER INSULATION (450)
6 WASHER SELF LOCKING DOME #8-32
1 INSULATION LOWER SPLITTER
2 SCREW HHC M6-1.0 X 20 G8.8
2 ASSY WIRE 14 AWG 34.8" GRN/YEL
2 WASHER SHAKEPROOF INT 1/4
1 INSULATION REAR WRAP
1 KEY VISE-ACTION LATCH SLOT CIR
1 FOAM 300 X 300 THERMAL ACO (APPLIES TO 4.2L UNITS ONLY)
1 STRIP SEALANT 1/8 X 1 (44.52"LG)
1 RF COVER PLATE-PLASTIC-BISQUE
1 RF COVER PLATE-PLASTIC-GREY
4 NUT U M6-1.0 GEOMET
4 SCREW HHFC M6-1.0 X 20 G8.8
GROUP F
